Designed for long-haul fuel transport with mechanical suspension and JOST landing gear, it is certified under CCC and ISO standards. The trailer is manufactured in Shandong, China, and is available for export with a 12-month warranty from supply date.
Stock number held for this listing: 10602
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Use | TruckTrailer |
|---|---|
| Size | 12980*2500*3900mm |
| Color | Custom'sRequirement |
| Suspension | Mechanical |
| Material | Steel |
| Certification | CCC,ISO |
| Axle | 20tFUWA/BPW |
| Tire | 10.00R20/11.00R20/12R22.5 |
| Type | Semi-Trailer |
| Trailer Model | HYD153264546 |
| Overall Dimensions L x W x H | 12980 x 2500 x 3900 mm |
| Number of Axles | 3 |
| Wheelbase | 7200+1310+1310 mm |
| Tread Front/Back | 2040/2040/2040 mm |
| Front Overhang | - |
| Rear Overhang | 1410 mm |
| Suspension Type | Mechanical |
| Axle Type | 20t FUWA/BPW |
| Tyre Size | 10.00R20 / 11.00R20 / 12R22.5 |
| Tank Material | Stainless Steel |
| Tank Thickness | 5 mm |
| Main Beam Height | 500 mm |
| Landing Gear | JOST |
| King Pin Size | 2" (50mm) or 3.5" (90mm) |
| Brake System | WABCO RE6 Relay Valve |
| Certifications | CCC, ISO |
| 2-axle fuel trailer | The 3-axle unit supports higher GVW and better load distribution, but has higher purchase and fuel cost |
|---|---|
| Aluminium tank trailer | Stainless steel offers better durability and lower long-term maintenance, but is heavier than aluminium |
| Hydraulic suspension trailer | Mechanical suspension is simpler, cheaper to maintain, and more reliable in remote areas without repair access |
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
NEW 2019 China 40000L Fuel Oil Tank Semi Trailer Manufacturer 3 axle oil/ fuel tank trailer tri- axle fuel tanker truck trailer Product Description Products name tank trailer volume (L) 45000 G.V.W (kg) 40000 Mass in working order (kg) 11590 Rated loading (kg) 28000 Overall dimension (mm) 12980*2500*3900 Number of axles (mm) 3 Wheel base (mm) 7200+1310+1310 tread Front wheel (mm) - Back wheel (mm) 2040/2040/2040 Front overhang/rear overhang -/1410 Number of plate spring ( front/back ) -/8/8/8 Axle 3*13T FUWA Specification of tire 12*11.00R20 material Stainless steel Tank Thickness 5 mm Production cycle Around 25 business days Warranty 12 month, from the date of supply Packaging & Shipping Packaging: Nude packing.To save the freight cost, the best way is 3 sets stick togather.Or One 40HQ can load 2 sets. Shipping: Transport by break bulk carrier RORO or Containerized. Our Services Company
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
It is a new trailer manufactured in 2019, built to order with a 12-month warranty from the date of supply.
Production cycle is around 25 business days after confirmation of the specification and receipt of the 30% down payment.
Yes. We supply common parts like tyres, brake linings, king pins, and tank fittings. They can be ordered separately or consolidated with the trailer.
We ship by break bulk carrier RoRo for full trailers. One 40HQ container can carry two trailers when stacked, but RoRo is more common for this size.
Commercial invoice, packing list, bill of lading, certificate of origin, and CCC/ISO certification documents are provided as standard.
Send the destination and quantity. A written specification, landed cost and shipping option comes back.
