A 3-axle gooseneck lowboy semi-trailer with a 13000mm length, 3000mm width and 3100mm height, built for transporting heavy equipment such as excavators, cranes and diggers. The chassis uses high tensile Q345 steel with an I-beam design, featuring 20mm top and bottom plates, 14mm middle plate and 5mm checkered floor plate. It is available with FUWA, HJ or BPW axles, 12R22.5 Double Star or Triangle brand tyres, and can be fitted with manual or hydraulic ladder. The trailer is painted with high-grade polyurethane and shipped by container, bulk cargo or RoRo.
Stock number held for this listing: 10483
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Use | OtherTrailers |
|---|---|
| Size | 13000*3000*3100mm |
| Material | Steel |
| Paint | HighGradePolyurethanepaint |
| Axle | FUWA/HJ/BPWbrandoptional |
| Tire | 12R22.5Doublestar,Trianglebrandoptional |
| Function | Transportheavydutyequipment |
| Ladder | ManualorHydraulicType |
| Packing | bycontainer/bulkship/ro-roship |
| Certificate | ISO9001:2008,CCC |
| Trailer Model | 3 Axle Gooseneck Lowboy Low Bed Semi Trailer |
| Dimensions L x W x H | 13000 x 3000 x 3100 mm |
| Payload Capacity | 50-80 T |
| Chassis Material | High tensile Q345 steel |
| Top Plate Thickness | 20 mm |
| Middle Plate Thickness | 14 mm |
| Floor Plate Thickness | 5 mm |
| Floor Type | Checkered plate |
| Axle Brand | FUWA / HJ / BPW (optional) |
| Axle Rating | 13/16 T per axle |
| Tyre Size | 12R22.5 Double Star or Triangle brand optional |
| Tyre Count | 12 pieces |
| Wheel Rim Size | 8.0-20, 8.5-20, 8.25-22.5, 9.0-22.5 |
| Suspension Type | Mechanical or Air suspension |
| Leaf Spring | 10 pcs * 90 * 13 mm |
| Kingpin Type | JOST 2" / 3.5" bolt-in or welding type |
| 2-axle lowboy trailer | The 3-axle model supports higher payloads and better weight distribution on soft or uneven ground, but has higher purchase and maintenance cost |
|---|---|
| Air suspension | Mechanical suspension is simpler and cheaper to maintain, but air suspension offers better ride quality on long hauls |
| Standard flatbed trailer | Gooseneck design lowers the load centre and improves stability for tall or heavy equipment, but reduces ground clearance at the front |
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
3 Axle 40FT 50T 60T 100T Used New Gooseneck Lowboy Low Bed Semi Trailer Dimensions Lowbed Truck Trailer For Sale Product Description 3 Axle Low Bed Semi Trailer Size 13700*3100*1700mm Payload 50-80T Chassis Heavy duty and extra durability designed I beam; opting for high tensile steel Q345, welded by automatic submerged- a rc processes. Top plate/bottom plate:20mm middle plate:14mm Floor 5mm Checkered plate Side beam #25 channel steel Cross member #14 channel steel Ladder Mechanical Ladder or Hydraulic Type Axle 3 A xle FUWA/HJ/BPW brand 13/16T Tire 11.00R20, 12.00R20, 11R22.5, 12R22.5, 315/80R22.5 D ouble star 12 pieces Wheel rim 8.0-20, 8.5-20, 8.25-22.5, 9.0-22.5 12 pieces Suspension Mechanical suspension or Air suspension Leaf spring 10 pcs*90*13mm Kingpin JOST 2"/3.5" bolt-in king pin or welding type Landing gear JOST two-speed, manual operating, heavy duty landing gear Twist lock n
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
Both new and used trailers are available. We provide photos, axle numbers and chassis history before you confirm the order.
20 workdays after receipt of 30% T/T down payment. We confirm the exact date in writing with the proforma invoice.
Yes. Axles, tyres, kingpins and suspension components are stocked and can be shipped with the trailer or separately.
All three options are available. We quote landed cost for each method so you can compare based on your destination and logistics plan.
Commercial invoice, packing list, bill of lading, certificate of origin, and ISO9001:2008 and CCC certificates as standard.
Yes. Appoint SGS, BV or your own agent and we will arrange access at the yard before loading.
Send the destination and quantity. A written specification, landed cost and shipping option comes back.
