A 3-axle heavy-duty low bed semi trailer with a 50-60 ton payload capacity, built on a 13000 x 3000 x 1250mm steel frame using Q345B material. It features three 13-ton Fuwa-brand axles, leaf spring suspension, ABS braking, and hydraulic lift systems for loading heavy machinery. Designed for transporting industrial equipment, mining gear, and construction plant across rough terrain and long hauls where ground clearance and stability are critical.
Stock number held for this listing: 10361
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Use | TruckTrailer |
|---|---|
| Size | 13000*3000*1250mm |
| Color | Option |
| Suspension | LeafSpringSuspension |
| Dimensions | 13000*3000*1250mm |
| Material | Steel |
| Certification | ISOCCC |
| Axle | 13TonFuwaBrand |
| Tyre | 1200R20or12R22.5 |
| Function | LowbedTrailer |
| Type | Semi-Trailer |
| Trailer Model | Shengxing Factory 3 Axles Heavy Duty Lowbed Semi Trailer |
| Axle Number | 3 |
| Axle Capacity | 13 Ton per Axle |
| Max Payload | 50-60 Tons |
| Dimensions L x W x H | 13000 x 3000 x 1250 mm |
| Deck Height | 1250 mm |
| Brake System | ABS |
| Tyre Size | 1200R20 or 12R22.5 |
| Hydraulic Lift | Yes |
| Place of Origin | Shandong, China (Mainland) |
| Trailer Type | Semi-Trailer |
| Tons Place of Origin | Shandong, China (Mainland) |
| Product Name | Shengxing Factory 3 Axles Heavy Duty |
| Lowbed Semi Trailer Axle | 13 |
| Ton Fuwa Brand Function | Lowbed |
| 2-axle low bed trailer | The 3-axle version supports higher payloads and better weight distribution but requires more space for turning and storage |
|---|---|
| Pneumatic suspension trailer | Leaf spring suspension is more robust and cheaper to maintain in dusty or off-road environments |
| Non-hydraulic trailer | Hydraulic lift allows self-loading without external cranes, reducing handling time and risk |
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
3axle 60 tons Low Bed Semi Trailer with Hydraulic lifts for Carrying Heavy Machinery Product Information Product Name Factory 3 Axles Heavy Duty Lowbed Semi Trailer Type Semi-Trailer Material Steel Q345 B Certificate ISO CCC Size 13000*3000*1250mm Max Loading Capacity 50-60 Tons Brand Sea Lion Function Lowbed Trailer Axle 13 Ton Fuwa Brand Axle Number 3 Axles Brake System ABS Tyre 1200R20 or 12R22.5 Origin Shandong, China Suspension Leaf Spring Suspension Accessories Show More Choice Packing & Delivery About Us the factory covers an area of 14,500 square meters, including the plant area of 11,300 square meters, the warehouse area of 900 square meters, and the supporting construction area of 1,200 square meters. We have 160 units advanced large scale equipment, and more than 50 units testing machines. With strong technical force and advanced manufacturing technology, the company is a larg
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
All trailers are new. We supply only factory-built units with full documentation and warranty.
15 workdays after prepayment. Larger orders may require longer lead time depending on production schedule.
Yes. We supply spare axles, tyres, hydraulic cylinders, and suspension components. These can be shipped with the trailer or separately.
We ship by bulk for standard trailers. Container shipment is possible but requires frame modification and is less common.
Commercial invoice, packing list, bill of lading, certificate of origin, and ISO CCC certificate are provided.
Send the destination and quantity. A written specification, landed cost and shipping option comes back.
