A 3-axle lowbed semi-trailer with a 60-ton payload capacity, built on a steel ladder frame chassis with leaf spring suspension and 13-ton Fuwa-brand axles. The trailer measures 13000 x 3000 x 1250 mm and features a double circuit brake system with ABS, a 2" or 3.5" king pin, and 12R22.5 or 1200R20 tyres. It is designed for transporting heavy-duty equipment such as mining machinery, construction cranes, and industrial generators across rugged terrain and long hauls in emerging markets.
Stock number held for this listing: 10126
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Use | TruckTrailer |
|---|---|
| Size | 13000*3000*1250mm |
| Color | Optional |
| Suspension | LeafSpringSuspension |
| Material | Steel |
| Certification | ISOCCC |
| Axle | 13TonFuwaBrand |
| Tire | 12R22.5or1200R20 |
| Function | TransportHeavyDutyEquipment |
| Type | Semi-Trailer |
| Capacity | 40-60Tons |
| Brake | DoubleCircuitBrakeSystemwithABS |
| Trailer Model | 3 Axles Lowbed Semi Trailer |
| Dimensions L x W x H | 13000 x 3000 x 1250 mm |
| Max Payload | 60 Tons |
| Axle Count | 3 |
| Axle Capacity | 13 Ton |
| Axle Brand | Fuwa |
| Brake System | Double Circuit with ABS |
| King Pin Size | 2" or 3.5" |
| Tyre Size | 12R22.5 or 1200R20 |
| Deck Height | 1250 mm |
| Tool Box | One Piece |
| Place of Origin | Shandong, China (Mainland) |
| Trailer Type | Semi-Trailer |
| Tons Place of Origin | Shandong, China (Mainland) |
| 2-axle 40-ton lowbed trailer | The 3-axle unit supports 60 tons and distributes weight better on soft ground, but costs more in fuel and maintenance |
|---|---|
| Pneumatic suspension trailer | Leaf spring is cheaper and easier to service in remote areas, but offers less ride comfort on long hauls |
| Higher deck height trailer | This 1250mm deck reduces loading angle and is better for heavy machinery, but limits clearance under low bridges |
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
3 Axles 60 Tons Lowbed Semi Trailer Product Description 3 Axles 60 Tons Lowbed Semi Trailer Packaging & Shipping Our Services We supply 100% original spare parts. and 24 hours aftersales quick service Company Information
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
All trailers are new. We supply only 100% original units with full factory documentation and no prior use.
Units in stock can be loaded within 5-7 days. Custom builds depend on the plant schedule and are confirmed in writing with the proforma invoice.
Yes. We supply 100% original spare parts including axle components, brake pads, king pins, and tyres for this model.
Trailer can be shipped by container if disassembled. RoRo is standard for full units. We quote both options for landed cost comparison.
Commercial invoice, packing list, bill of lading, certificate of origin, and ISO CCC certificate are included. Pre-shipment inspection certificates are available upon request.
Send the destination and quantity. A written specification, landed cost and shipping option comes back.
