A 3-axle semi-low bed trailer designed for transporting heavy excavators and construction machinery, with a 50-ton maximum payload capacity. Built on a steel Q345 B chassis, it features three 13-ton Fuwa-brand axles, leaf spring suspension, and ABS braking. The trailer measures 13000 x 3000 x 1250mm and is manufactured in Shandong, China. It is suitable for long-haul transport of heavy equipment where ground clearance and load distribution are critical.
Stock number held for this listing: 10349
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Use | TruckTrailer |
|---|---|
| Size | 13000*3000*1250mm |
| Color | Option |
| Suspension | LeafSpringSuspension |
| Dimensions | 13000*3000*1250mm |
| Material | Steel |
| Certification | ISOCCC |
| Axle | 13TonFuwaBrand |
| Tyre | 1200R20or12R22.5 |
| Function | LowbedTrailer |
| Type | Semi-Trailer |
| Trailer Model | 3 Axles 50 Tons Heavy Excavator Transport Semi Low Bed Truck Trailer |
| Dimensions L x W x H | 13000 x 3000 x 1250 mm |
| Max Payload | 50 Tons |
| Axle Number | 3 |
| Axle Capacity | 13 Ton |
| Axle Brand | Fuwa |
| Brake System | ABS |
| Tyre Size | 1200R20 or 12R22.5 |
| Loading Capacity | 50 Tons |
| Place of Origin | Shandong, China (Mainland) |
| Trailer Type | Semi-Trailer |
| Tons Place of Origin | Shandong, China (Mainland) |
| Bed Truck Trailer Axle | 13 |
| Ton Fuwa Brand Function | Lowbed |
| Trailer Suspension | Leaf Spring |
| 2-axle low bed trailer | The 3-axle version handles heavier loads and complies with axle weight limits in regulated markets, but has higher shipping cost and complexity |
|---|---|
| Air suspension trailer | Leaf spring suspension is more robust and lower maintenance, but offers less ride comfort on rough roads |
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
3 Axles 50 Tons Heavy Excavator Transport Semi Low Bed Truck Trailer 3 Axles 50 Tons Excavator Transporter Low Bed Semi Trailer Product Information Product Name 3 Axles 50 Tons Excavator Transporter Low Bed Truck Trailer Type Semi-Trailer Material Steel Q345 B Certificate ISO CCC Size 13000*3000*1250mm Max Loading Capacity 50 Tons Brand Shengxing Function Lowbed Trailer Axle 13 Ton Fuwa Brand Axle Number 3 Axles Brake System ABS Tyre 1200R20 or 12R22.5 Origin Shandong, China Suspension Leaf Spring Suspension Accessories Show More Choice Packing & Delivery About Us the factory covers an area of 14,500 square meters, including the plant area of 11,300 square meters, the warehouse area of 900 square meters, and the supporting construction area of 1,200 square meters. We have 160 units advanced large scale equipment, and more than 50 units testing machines. With strong technical force and ad
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
All trailers are new and built to order. We provide photos and videos of the final build before shipment.
Delivery is 15 workdays after prepayment. Larger orders may require additional time based on production schedule.
Yes. Fuwa axles, leaf springs, tyres, and brake components are available for future replacement orders.
We ship by bulk (RoRo) for most orders. Container shipping is possible but requires deck lowering and may affect load capacity.
Commercial invoice, packing list, bill of lading, certificate of origin, and ISO CCC certificate are provided with every shipment.
