A 3-axle heavy cargo low bed semi-trailer with leaf spring suspension, built for transporting oversized or heavy industrial equipment. The trailer measures 13000 x 3000 x 1250mm with a 50-ton maximum payload capacity. It uses three 13-ton Fuwa-brand axles, 1200R20 or 12R22.5 tyres, and features an ABS brake system. The frame is constructed from Q345B steel and is certified under ISO CCC for export to African markets.
Stock number held for this listing: 10345
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Use | TruckTrailer |
|---|---|
| Size | 13000*3000*1250mm |
| Color | Option |
| Suspension | LeafSpringSuspension |
| Dimensions | 13000*3000*1250mm |
| Material | Steel |
| Certification | ISOCCC |
| Axle | 13TonFuwaBrand |
| Tyre | 1200R20or12R22.5 |
| Function | LowbedTrailer |
| Type | Semi-Trailer |
| Trailer Model | 3 Axle Heavy Cargo Low Bed Trailer |
| Dimensions L x W x H | 13000 x 3000 x 1250 mm |
| Max Payload | 50 Tons |
| Axle Number | 3 |
| Axle Capacity | 13 Ton per Axle |
| Axle Brand | Fuwa |
| Suspension Type | Leaf Spring |
| Brake System | ABS |
| Tyre Size | 1200R20 or 12R22.5 |
| Frame Material | Q345B Steel |
| Origin | Shandong, China (Mainland) |
| Trailer Type | Semi-Trailer |
| Tons Place of Origin | Shandong, China (Mainland) |
| Suspension to Africa Axle | 13 |
| Ton Fuwa Brand Function | Lowbed |
| 2-axle low bed trailer | The 3-axle unit supports 50 tons with better axle load distribution but requires more space and has higher shipping cost |
|---|---|
| Air suspension trailer | Leaf spring suspension is more durable and lower maintenance in dusty or off-road environments, but offers less ride comfort |
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
3 Axle Heavy Cargo Low Bed Trailer With Leaf Spring Suspension To Africa Product Information Product Name 3 Axle Heavy Cargo Low Bed Trailer With Leaf Spring Suspension To Africa Type Semi-Trailer Material Steel Q345 B Certificate ISO CCC Size 13000*3000*1250mm Max Loading Capacity 50 Tons Brand Shengxing Function Lowbed Trailer Axle 13 Ton Fuwa Brand Axle Number 3 Axles Brake System ABS Tyre 1200R20 or 12R22.5 Origin Shandong, China Suspension Leaf Spring Suspension Accessories Show More Choice Packing & Delivery About Us the factory covers an area of 14,500 square meters, including the plant area of 11,300 square meters, the warehouse area of 900 square meters, and the supporting construction area of 1,200 square meters. We have 160 units advanced large scale equipment, and more than 50 units testing machines. With strong technical force and advanced manufacturing technology, the compa
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
All trailers are new and built to order. We provide photos and video of the unit before shipment.
15 workdays after receipt of prepayment. Larger orders may require adjustment based on production schedule.
Yes. We supply Fuwa axles, leaf springs, tyres, and ABS components separately. These can be shipped with or after the trailer.
We offer both. Bulk shipping is standard for trailers. Container shipment is possible but requires lowering the cab and may affect loading height.
Commercial invoice, packing list, bill of lading, certificate of origin, and ISO CCC certificate are provided.
Send the destination and quantity. A written specification, landed cost and shipping option comes back.
