Anish Kapoor's Concave Mirror Sculpture at the Exhibition Center of Art Fish Scales Concave Sculpture
Concave mirror sculptures formed from multiple stainless steel plates, hand welded and mirror polished to create a seamless reflective surface. The fish scale pattern is achieved through water pressure forming and manual shaping, resulting in a curved, inward-facing surface that reflects the viewer and surrounding space in shifting, dynamic ways. Made to order in Shenzhen, China, with diameters from 300 mm to 3000 mm and wall thickness from 1 mm to 6 mm.
Key Benefits
- Concave shape creates dynamic reflections that change with viewer position and movement
- Hand welded and mirror polished with no visible seams for a continuous reflective surface
- Available in AISI 201, 304, and 316 stainless steel for different environmental conditions
- Custom curvature and height to match architectural or design intent
- Diameter range from 300 mm to 3000 mm allows integration into large interior spaces
- Pre-welded mounting points and bases available to reduce on-site work
Problems It Solves
- Flat mirrors lack depth and visual engagement; a concave form creates dynamic, shifting reflections
- Mass-produced mirrors have visible seams or joints; hand welding and polishing hide the join
- Off-the-shelf mirrors do not match custom architectural curves or site-specific dimensions
- Site welding or drilling on a finished mirror surface damages the finish and requires rework
- Multiple suppliers are needed for different sizes and finishes, increasing cost and inconsistency
- Lack of a unified reflective surface in modular mirror installations; this sculpture integrates all elements
Application Scenarios
Interior focal points in hotel lobbies, exhibition halls, and art galleries
Wall installations in private homes and luxury residences where reflective surfaces enhance space
Art installations in public spaces that invite viewer interaction through reflection
Architectural features in commercial buildings where the sculpture becomes part of the design language
Commissions for art exhibitions or cultural centers with a modern, reflective aesthetic
Integration into interior design schemes where the sculpture acts as a mirror and sculptural element
Who It Is For
- Interior designers specifying reflective art for high-end residential or commercial spaces
- Hotel and property developers commissioning unique interior features for branding
- Art curators and exhibition organizers needing custom mirror sculptures for display
- Architects integrating sculptural elements into building interiors without structural load
- Public art commissioners seeking interactive, reflective installations for urban spaces
- Importers and installers who need a ready-to-mount sculpture with consistent finish
Technical Features
- Multiple stainless steel plates formed using water pressure and hand shaping to achieve concave curvature
- Plates welded together with seam ground and blended to be invisible under mirror polish
- Mirror polished to a high-gloss finish with no visible seams or weld marks
- Curvature and height designed to your specifications, not limited to standard shapes
- Available in AISI 201, 304, and 316 stainless steel for different exposure conditions
- Wall thickness from 1 mm to 6 mm to balance weight and rigidity for large pieces
- Mounting points, pedestals, or flanges can be welded before final polish
- Custom size from 300 mm to 3000 mm diameter, not limited to standard sizes
Specifications and Materials
| Material | AISI 201, AISI 304, AISI 316 stainless steel |
|---|---|
| Diameter Range | 300 mm to 3000 mm |
| Wall Thickness | 1 mm to 6 mm |
| Forming Method | Water pressure forming and hand shaping |
| Standard Finish | Mirror polished |
| Optional Finishes | Brushed, matt, vacuum metallising, electroplating |
| Secondary Operations | Welding, drilling, thread tapping, pedestal or base welding |
| Lead Time | 15 to 30 days after deposit received |
| Packing | Wooden stand or wooden case, foam padding inside |
| Payment Terms | T/T, 50% deposit and 50% balance before shipping |
| Place of Origin | Shenzhen, China |
| Size Range | 300mm to 3000mm |
Materials
- AISI 201 stainless steel, suitable for indoor use and non-corrosive environments
- AISI 304 stainless steel, standard for indoor and general outdoor use
- AISI 316 stainless steel, recommended for coastal, poolside or high-salt exposure
Customization
- Any diameter from 300 mm to 3000 mm, not limited to standard sizes
- Wall thickness selected based on structural needs and weight constraints
- Curvature and height designed to your exact specifications
- Mounting base, flange, or pedestal welded in the correct position
- Custom finish: mirror, brushed, matt, vacuum metallised, or electroplated
- Multiple pieces in a set can be polished in the same batch for consistent finish
How It Is Made
- Step 1Steel plate cut to size based on design and curvature data
- Step 2Plates formed using water pressure and hand shaping to achieve concave fish scale pattern
- Step 3Individual plates fitted and welded together with precision seam alignment
- Step 4Welds ground and blended until no visible joint remains under reflection
- Step 5Holes drilled and threads tapped, mounting bases or flanges welded on
- Step 6Mirror polished through progressive grits to achieve a seamless reflective surface
- Step 7Optional finishes applied: brushed, matt, vacuum metallising, or electroplating
- Step 8Protective film applied, foam wrapped, and placed on wooden stand or in wooden case
Quality Control and Use
Quality Control
- Seam inspected under reflected light to ensure no flat spots or weld marks remain
- Diameter and curvature checked against design drawings before polishing
- Thread holes gauged for pitch and depth after tapping
- Finished sculpture kept under protective film until packing
- Photographs of the completed piece sent for approval before balance payment
Use Guide
- Specify diameter, wall thickness, finish, and mounting method when requesting a quote
- Send the base or mounting detail so the pedestal is welded in the correct position
- Use 316 stainless steel for coastal or high-salt environments
- Keep the protective film on until the sculpture is mounted and the site is clean
- Clean with soft cloth and water; avoid wire brushes or chloride cleaners
Compared With The Alternatives
| Alternative | How this product compares |
|---|---|
| Flat mirror panels | Concave form creates dynamic, shifting reflections; flat mirrors offer static reflection |
| Cast or molded mirror panels | Hand formed plates allow custom curvature and no mold lines; cast forms are limited to standard shapes |
| Acrylic or glass concave mirrors | Stainless steel is durable and scratch resistant; acrylic yellows and fractures over time |
| Pre-fabricated modular mirror walls | This sculpture is a single unit with integrated form and finish; modular systems have visible joints and inconsistent polish |
Related Products
Interior Decoration SculptureOriginal Design Weight Lifting Gold Colour Metal Statues Furnishing Articles
View Details
Interior Decoration SculptureHot Sell Rose Gold Metal Statues Ornament Hotel Room Office's Desk and Giving Gifts Best Choice Art Works
View Details
Interior Decoration SculptureBlack Metal Statues Ornament for Home Office Desk Giving Gifts Best Choice Art Works
View Details
Interior Decoration SculptureOriginal Design Polishing Metal Stainless Steel Sphere Art Office Desk Decorative Sculpture
View DetailsGuides That Help You Specify This
Mirror Polishing Explained for Stainless Steel Sculpture
Why the quality of a mirror finish is decided during welding and fixing, long before the piece reaches the polishing shop.
How a Stainless Steel Water Drop or Fountain Sculpture Works
How a watertight sculpture is built, where the flow tube runs, and what your water feature contractor needs from us.
Questions About Anish Kapoor's Concave Mirror Sculpture at the Exhibition Center of Art Fish Scales Concave Sculpture
What is the smallest diameter you can make?
300 mm on standard tooling. Custom sizes below 300 mm are possible with a new tooling setup.
How long does delivery take?
15 to 30 days after deposit received. Larger or complex shapes may take closer to 30 days.
Can you use 316 stainless steel?
Yes. AISI 316 is available for coastal, poolside, or high-salt exposure.
Can you weld a base before polishing?
Yes. Mounting bases, flanges, or pedestals can be welded before final polish to avoid site work.
How are large sculptures packed?
Foam wrapped and placed on a wooden stand inside a wooden case for sea freight.
What payment terms do you use?
T/T with 50% deposit and 50% balance before shipping. Photographs of the finished piece are sent before final payment.
Get a Price on Anish Kapoor's Concave Mirror Sculpture at the Exhibition Center of Art Fish Scales Concave Sculpture
Send the size, finish and fixing you need and we will come back with a price and a lead time for Anish Kapoor's Concave Mirror Sculpture at the Exhibition Center of Art Fish Scales Concave Sculpture.
