Crane Radio Remote Control F24-10D
The F24-10D is a double speed radio remote control for cranes and mobile lifting equipment, supplied as a matched transmitter and receiver pair. Ten function buttons provide double speed control across multiple motions, allowing p
What The Crane Radio Remote Control F24-10D Is For
The F24-10D is a double speed radio remote control for cranes and mobile lifting equipment, supplied as a matched transmitter and receiver pair. Ten function buttons provide double speed control across multiple motions, allowing precise load positioning without a cab or pendant cable. The system operates up to 100 metres with 160 available channels across two frequency bands, and both units are rated IP65 for use in dusty, wet, or outdoor environments. Receiver voltage is built to order from AC380V down to AC/DC12V, so it integrates directly into existing control panels without a transformer.
What You Get From This Unit
- Operator can stand where the load is visible instead of beside the machine or in a cab
- Double speed on all ten function buttons enables fast travel and slow approach without extra hardware
- IP65 protection on transmitter and receiver allows operation in rain, dust, and wash-down areas
- Receiver voltage matched to panel eliminates need for a control transformer
- Over 4.3 billion unique ID codes and 160 channels prevent interference between nearby cranes
Crane Radio Remote Control F24-10D As Supplied
Where This Model Is Used
- Overhead and bridge cranes in fabrication shops with limited cab visibility
- Gantry cranes and mobile lifting equipment operating outdoors in rain or dust
- Electric carts and hoists used in wet or dirty environments where pendant cables fail
- Retrofit of existing crane controls without changing the motor contactor panel
- Railroad yard operations where multiple cranes work in close proximity
Buyers This Model Suits
- Crane and hoist OEMs integrating remote controls into new machine builds
- Maintenance teams replacing a failed or damaged pendant control station
- Equipment dealers stocking a control unit that fits multiple voltage systems
- Traders sourcing a radio control set from China with low MOQ and fast delivery
What Goes Wrong Without It
- Operator must walk with the load while holding a pendant cable that snags on structures
- Cab operator cannot see the hook and relies on hand signals from a second person
- Existing panel runs AC110V and a standard 24V receiver would require an extra transformer
- Two cranes in the same bay respond to the same transmitter due to poor channel separation
- Pendant cable and plug fail repeatedly in wet or dusty environments
How The Unit Is Built
- 10 push buttons: 10 double speed function buttons, 1 emergency stop, 1 on/off switch
- Crystal plug-in frequency generation across 160 channels at 0.2675 MHz spacing
- 17 control motions from the ten double speed buttons
- Transmitter LED flashes green during operation if battery power is sufficient and red when depleted
- Glass fibre housing on both transmitter and receiver for impact resistance
- Operating frequency available at 310.0325–331.165 MHz or 426–445 MHz
- Control distance up to 100 metres
Data From The Original Product Sheet
| Model | F24-10D |
|---|---|
| Configuration | 1 transmitter with 1 receiver |
| Speed | Double speed |
| Function buttons | 10 |
| Control distance | Up to 100 m |
| Operating frequency | 310.0325–331.165 MHz or 426–445 MHz |
| Channels | 160 |
| Channel spacing | 0.2675 MHz |
| Control motions | 17 |
| Unique ID codes | Over 4.3 billion |
| Enclosure protection | IP65 |
| Working temperature | -35 C to +80 C |
| Transmitter voltage | DC3V (AA batteries) |
| Receiver power | AC380V / 220V / 110V / 48V / 36V / 24V or AC/DC12V |
| Output capacity | Full sealed relay output, 5 A |
| Housing material | Glass fibre |
| Colour | Yellow |
| Warranty | 1 year |
What The Housing And Contacts Are Made Of
- Glass fibre transmitter and receiver housings for impact resistance on a shop floor
- Sealed relay contacts rated 5 A so the receiver switches contactor coils directly
How This Unit Is Made
Step 1
Boards are populated on the SMT line and soldered on the automatic wave soldering machine
Step 2
Transmitter and receiver are paired to a unique ID code and channel before assembly
Step 3
Each set is function tested against the ordered receiver voltage before packing
Step 4
S/N and channel are printed on the back of both units so a replacement can be matched later
What Is Checked Before It Ships
- Raw material through finished product is inspected step by step on the production line
- Working process follows ISO9001:2008
- Every set is powered up and each motion is checked before it leaves the line
- 12 month warranty from delivery
What Can Be Changed On Your Order
- Receiver voltage selected from the listed range at order time
- Button text supplied as arrow tips or as your own English labels
- Two transmitters paired to one receiver, or a spare transmitter added to the set
- Own brand and label printing accepted on OEM orders
How It Compares With The Alternatives
| Wired pendant control station | Radio removes the trailing cable but adds batteries to change and a receiver to wire in; a pendant is cheaper and never needs pairing |
|---|---|
| F24-8D with eight buttons | The 10D adds two more double speed motions; if the machine only has hoist, long travel and cross travel the 8D is the cheaper fit |
| Joystick sets such as F24-60 | Push buttons are faster to train an operator on; a joystick gives proportional control that push buttons cannot |
Getting It Onto The Machine
- Confirm the control voltage on the existing crane panel before ordering the receiver
- Count the motions the machine actually needs, then choose the button count with one spare
- Mount the receiver inside the panel with the 1 m cable running to the contactor terminals
- Watch the transmitter LED: slow red flashing means change the two batteries
- Record the S/N and channel from the back of both units so a lost transmitter can be replaced without changing the receiver
Other Models In This Series
Industries Cases And Guides For This Model
Overhead and Bridge Cranes
Industry application
Electric Hoists and Winches
Industry application
Construction Equipment
Industry application
DC24V F24-12S Truck Wireless Remote Control For An Australian Buyer
Case study
F21-2S Up and Down Remote Control For Chain Hoists
Case study
Four Advantages Of Using A Wireless Controller
Technical guide
How To Choose The Receiver Voltage For A Crane Radio Control
Technical guide
What Does IP65 Mean On A Crane Remote Control
Technical guide
Retrofit A Pendant Crane To Radio Control
Solution
Replace A Lost Or Broken Transmitter
Solution
Catalogue And Datasheets
Download center
Frequently Asked Questions
What is the minimum order quantity?
One set. A single sample is available so you can test it on the machine before committing to volume.
How long is delivery?
Around 2-4 days for a sample order and about 7 days for a small volume order, then 3-8 days by FedEx or DHL.
Which receiver voltage should I order?
Match the control voltage on the crane panel. The receiver is built for AC380V, 220V, 110V, 48V, 36V, 24V or AC/DC12V, so tell us the panel voltage with the order.
Can I get a replacement transmitter only?
Yes. Send the S/N and CH printed on the back of your receiver and we build a new transmitter on the same channel, so the receiver stays in place.
Will two cranes in the same bay interfere?
Each set is coded with one of over 4.3 billion unique ID codes and runs on 160 channels, so a transmitter only answers its own paired receiver.
Can the button text be changed?
Yes. Arrow tips are standard and your own English button text and brand can be printed on OEM orders.
How is it packed?
One set per box at 46 x 24.4 x 14.8 cm, six sets per carton at 76.3 x 49.3 x 33 cm.
