Controls For Electric Hoists and Winches
Electric hoists and winches benefit from wireless control when the operator needs to move freely or when the pendant cable interferes with the load path. Acontrol provides F21 series radio remotes and AR1-C, AR1-F, AR1-Y and XAC pendant sta
What Electric Hoists and Winches Need From A Control
Electric hoists and winches benefit from wireless control when the operator needs to move freely or when the pendant cable interferes with the load path. Acontrol provides F21 series radio remotes and AR1-C, AR1-F, AR1-Y and XAC pendant stations designed for hoist duty, with voltage compatibility built into the receiver and button counts matched to the motion list of the machine.
What Goes Wrong On These Machines
- The pendant cable gets caught on the hoist frame or load during operation
- Battery-powered remotes fail unexpectedly during a lift
- A replacement control from the hoist manufacturer takes weeks to arrive
- The control voltage does not match the hoist panel, requiring an external transformer
- Two hoists in the same area use the same frequency and interfere with each other
What The Control Has To Do
- A control unit that works with the existing hoist panel voltage without rewiring
- Emergency stop that cuts power directly at the contactor, not through the PLC
- IP65 rating for use on outdoor winches, in wash-down areas or dusty environments
- Button count from 2 to 12 to match the number of hoist motions exactly
- Single piece supply for a breakdown or small volume repeat order
Models That Suit This Duty
Where These Controls Are Fitted
- Electric chain hoists in a maintenance bay where the operator moves around the load
- Wire rope hoists on a mobile platform used in construction or shipyard work
- Hydraulic winches on a mobile crane used in mining or forestry
- Wire rope winches on a dockside gantry for container handling
- Hoist winches on a mobile service cart in a factory workshop
From Enquiry To Machine
Step 1
Send the hoist voltage, motion list, speed type and environment with the enquiry
Step 2
A model is proposed from the F21 or AR1 series based on button count, IP rating and voltage
Step 3
One sample ships in 2-4 days for fit and function test on the actual hoist
Step 4
Volume order is built with confirmed voltage, button text and brand printing, about 7 days
Step 5
S/N and channel are recorded so a replacement transmitter can be matched later
Lead Times And Terms
- Sample delivery 2-4 days, small volume orders around 7 days
- FedEx or DHL door to door in 3-8 days with a tracking number
- Trade terms EXW or FOB; prices exclude VAT and import tariff
- 12 month warranty from delivery
- Reply within 8 hours Monday to Saturday
Cases Solutions And Guides
F21-2S Up and Down Remote Control For Chain Hoists
Case study
Retrofit A Pendant Crane To Radio Control
Solution
OEM And Private Label Control Units
Solution
Four Advantages Of Using A Wireless Controller
Technical guide
What Does IP65 Mean On A Crane Remote Control
Technical guide
Pendant Control Or Radio Remote Control For Your Crane
Technical guide
Frequently Asked Questions
Can I use a radio remote on my electric hoist?
Yes. The F21-2S model is designed for 500kg to 7500kg hoists with single or two speed control and IP65 protection.
Does the radio control work through walls or metal structures?
Up to 100 meters line of sight. Signal may weaken in dense metal environments or behind thick walls.
What batteries are used in the transmitter?
Two 1.5 volt AA batteries. A low voltage warning LED alerts when power is dropping.
Can I get a pendant station with mechanical interlock?
Yes. AR1-C, AR1-F, AR1-Y and XAC series pendants include mechanical interlock and emergency stop.
Do you support custom button text?
Yes. OEM orders allow custom English button text and brand printing on the transmitter.
What is the IP rating for outdoor use?
IP65 for the F21 series and AR1-F series, suitable for rain, dust and wash-down environments.
Can I replace a broken transmitter with the same S/N and channel?
Yes. S/N and channel are recorded so a replacement transmitter can be matched exactly.
Specify A Control For Electric Hoists and Winches
Send the machine voltage, the motion list and the environment it works in. A model and a lead time come back the same working day.
