10 ton double girder overhead crane installed in an automotive technology company workshop

Overhead Cranes

10 Ton Overhead Crane

Name: 10 Ton Overhead Crane
Brand: Zhufu Industrial

Request A Quote Email Your Specification

Overview Key Benefits Applications Specifications Manufacturing Customisation Comparison Use Guide FAQ

Product Overview

A 10 ton double beam overhead crane built to your bay rather than to a catalogue model. Two builds are offered: a light double beam version for general construction and industrial lifting, and a winch version for heavier, more continuous duty. Both span up to 49 metres with lifting heights of 30 or 40 metres, and both are supplied with a European style electric wire rope hoist, gearbox, motor and frequency converter for controlled lifting and travel.

Key Benefits

Span and hook height are set from your building, not from a fixed model list
Frequency converter control gives smooth start and stop so loads do not swing into racking
European style wire rope hoist keeps the trolley compact and the hook higher under the roof
Wireless, cab or handheld control so the operator can stand where the load is visible
CE certified, with the certification stated by the manufacturer for this crane range

Problems It Solves

A crane bought on tonnage alone that turns out to be the wrong span for the finished building
Jerky control that makes precise placement slow and unsafe
Hook height lost to a bulky trolley so the load cannot clear machinery
Operators forced into a fixed cab position with poor sight of the load

Where It Is Used

Applications And Buyers

Application Scenarios

Moving heavy construction materials around a site or yard
Feeding and unloading machines in a manufacturing bay
Lifting machine assemblies at a heavy equipment repair station
Handling mining materials and machinery
Positioning generators, transformers and other components in power plants

Who It Is For

Fabrication and manufacturing plants fitting out a new bay
Maintenance workshops that lift machine assemblies rather than production parts
Contractors and site operators handling precast and steel sections
Mining and power facilities with occasional heavy component moves

Technical Features And Specifications

Technical Features

Double beam bridge construction
European style electric wire rope hoist
Gearbox, motor and frequency converter as core drive components
Lifting speed range 0.4 to 16 m per minute on the light build and up to 20 m per minute on the winch build
Wireless remote, cabin or handheld pendant control options

Specifications
Rated Capacity	10 ton
Capacity Range Available	5 to 100 ton (light build), 5 to 360 ton (winch build)
Max Span	0 to 49 m
Max Lifting Height	30 m or 40 m
Lifting Speed	0.4 to 16 m/min (light), 0.4 to 20 m/min (winch)
Core Components	Gearbox, motor, frequency converter
Control Options	Wireless, cab, handheld
Crane Type	Double beam bridge crane
Place of Origin	Henan, China
Warranty	1 year

How It Is Made And Checked

Materials Process And Quality Control

Certifications Stated By The Manufacturer

Manufacturing Process

Structural fabrication
Girder welding
Assembly
Load testing

Quality Control

Specification agreed in writing before production starts
First article or sample approved against the agreed specification
Goods inspected and photographed at the factory before loading
Inspection report sent to you before the container sails

Customisation Options

What Can Be Varied

Span set to your rail centre distance up to 49 m
Lifting height specified at 30 m or 40 m
Light or winch build depending on duty
Control method chosen per operator position
Capacity uprated within the 5 to 360 ton range of the same series

Compared With The Alternatives

Single girder overhead crane	The double beam build carries more hook height and heavier loads on the same runway, at higher structural load and cost.
Jib crane	A jib crane serves one machine or work station; this crane serves the whole bay, which is why the two are usually bought together rather than instead of each other.
Gantry crane	A gantry carries its own legs and needs no runway, but takes floor space; this crane needs a runway and leaves the floor clear.

Use Guide

Confirm rail centre distance on the finished building before ordering, not from the design drawing
Measure hook height to the highest point the hook must reach with the load attached
State lifts per hour and shift pattern so the duty class matches real use
Keep the frequency converter parameters as commissioned rather than raising speeds later

Questions

Questions Buyers Ask About This Product

What span can this 10 ton crane cover?

Up to 49 metres. Send the rail centre distance in your building and the crane is built to that figure.

What lifting height is available?

30 metres or 40 metres, specified per order.

Is it certified?

The manufacturer states CE and ISO certification for this crane range. Certificates are sent with the quotation on request.

Can it be controlled remotely?

Yes. Wireless remote, cabin and handheld pendant control are all available.

Where is it made and what warranty applies?

The crane is produced in Henan, China and carries a one year warranty.
