Die Cast Zinc Alloy Bag Strap D Ring
A 25 mm inner width D ring in die cast zinc alloy, with 19 mm, 32 mm and 38 mm produced from the same family. Twenty five millimetres is the main strap anchor size on most crossbody bags, so this ring is normally ordered alongside the 25 mm swivel hook. Minimum 1,000 pieces, mixable at 500 per colour.
The 25 mm strap anchor, the ring that pairs with the 25 mm crossbody snap hook.
| Size | 25 mm( 19 mm/25 mm/32 mm/38 mm, custom sizes available) |
|---|---|
| Material | Zinc alloy |
| Finishes | Rainbow/Gold/Rose Gold/Nickel/Gunmetal/Antique Brass and others |
| Typical Use | Dog Collar, Purse, Wallet, Bag, Backpack, Belt, and others |
| Minimum Order | 1000 pcs(can mix two colors, 500 pcs/color) |
| Sampling Time | 1 to 3 days |
Problems It Solves
- A D ring with a weak straight bar opens out under a diagonal pull and drops the strap
- Rings with a visible parting line spoil an otherwise clean leather panel
- Mixed suppliers mean the ring gold and the hook gold do not match on the same bag
Key Benefits
- The straight bar is the thickest section, which is where the anchor tab load goes
- Polished before plating so the flat face reads as a finished trim part
- Cast in a size ladder so one shape covers several strap widths in one order
Application Scenarios
- Strap anchor points sewn into a leather or webbing tab
- Backpack side compression and accessory attachment points
- Dog collar D ring for a lead or an ID tag
- Belt and harness junctions on apparel
Who It Is For
- Handbag and backpack factories anchoring detachable straps
- Pet product brands fitting a lead attachment point to a collar
- Leather goods workshops matching trim across a collection
How This Part Is Produced
Six steps inside one factory, from the mould to the packed carton.
Technical Features
- Zinc alloy die cast or iron stamped and formed, depending on the size and price point
- Straight bar section thicker than the curve to take the tab load
- Plated in the same colour set as our hooks, sliders and buckles
Quality Control
- Incoming zinc, brass, iron and stainless material checked against the grade ordered
- First article from each mould compared with the approved sample before the run starts
- Dimensional check on inner width and thickness during casting and stamping
- Plating thickness and colour compared against the approved colour plate
- Spring and swivel action tested by hand on hooks, snaps and side release buckles
- Counted, bagged and cartoned with the order's own packing list
Customisation Options
- Size or inner width changed on an existing catalogue style with no mould fee
- Finish chosen from nickel, gunmetal, black nickel, gold, light gold, rose gold, antique brass and rainbow
- Logo etched or embossed where the part has a flat large enough to carry it
- Painted or enamel colour where a plated metal tone will not match the brand colour
- Free 3D design from a photo or a physical sample if you have no drawing
The factory states that this item is produced as an eco-friendly part to ISO 9001, SGS and RoHS requirements. We do not hold a certificate scan for this specific SKU on the website, so ask for the current certificates by email or WhatsApp before you place a compliance-critical order.
Photographs of This Item
Every image is a photograph of the part itself, taken from the manufacturer's own product record rather than a rendering.
Use Guide
- Take the inner width from the webbing or tab width, not from the finished ring size
- Orient the straight bar so the pull is across it, never along the open curve
- Box stitch the tab so the ring cannot rotate out of the seam
| Compared with | What changes |
|---|---|
| O ring | An O ring lets a strap swing in any direction, while a D ring keeps the pull square to the panel |
| Rectangle ring | A rectangle ring stacks two webbing layers neatly, but a D ring gives a cleaner look on a narrow tab |
| Welded wire D ring | Welded wire is stronger for its weight but the weld is visible and plates unevenly |
Related Reading
Industries
Solutions
Questions About This Item
Sizing, finish, minimum order and lead time on this part.
Should I Buy Zinc Alloy or Iron D Rings
Zinc alloy gives the cleaner cast face and a better plated finish, while stamped iron is cheaper at larger sizes. Both are in the catalogue in the same colour range.
Ask for a Sample of the Die Cast Zinc Alloy Bag Strap D Ring
Stock samples are free and you pay only the courier. Sampling time is 1 to 3 days, and we will confirm the MOQ and the plated finish in writing before production.
