Smart Home Security Cameras · WF-360MOC
360 Panoramic Ceiling WiFi Camera WF-360MOC
A ceiling mounted fisheye camera with a 185 degree F2.2 1.29mm lens on a progressive scan CMOS sensor, running at 25fps. It covers a whole room from one point, with software dewarping and two way audio in the app. It weighs 150g and is not concealed.
- 185 degree fisheye covers an entire room from one ceiling position
- Software dewarping in the app turns the circular image into usable views
- Two way audio so the camera can be spoken through
- Progressive scan CMOS at 25fps at maximum resolution
One year warranty · PayPal, T/T or Western Union · DHL, UPS, FedEx or EMS
Who It Is For
- Homes and small shops covering a whole floor from one fitting
- Landlords fitting a visible camera in a shared area
- Distributors serving the smart home channel
Problems It Solves
- Full room coverage normally needs two or three cameras and two or three cable runs
- Corner mounted cameras leave a blind spot directly beneath them
- A camera that cannot be spoken through cannot be used to intervene
Application Scenarios
- An open plan living area covered from the ceiling rose
- A small retail floor from one central point
- An office covering desks and the entrance together
- A stairwell or landing where a corner mount would miss the approach
Specifications
WF-360MOC Technical Data
Taken from the factory specification sheet. Anything the sheet does not state is left out rather than estimated, and the FAQ below says which figures are still being confirmed.
| Micro SD Card Capacity | Video Surveillance Storage |
|---|---|
| 16GB | Estimated to 1 day of video surveillance |
| 32GB | Estimated 2 to 3 days of video surveillance |
| 64GB | Estimated 5 to 7 days of video surveillance |
| 128GB | Estimated 10 to 14 days of video surveillance |
| Weight | 150g |
| Power Supply | 100～240V AC，50～60Hz |
| Power consumption | < 6W |
| Field of View | 360 deg |
| Image Sensor | Progressive Scan CMOS |
| Angle of View | 180 deg hemisphere |
| Lens | 185 deg / F2.2 / 1.29mm Fisheye Lens |
| Two Way Audio | Supported |
| Motion Detection | Supported |
| Advance Event Management | Triggered by motion, notifications broadcast to App |
| SD Card | Supports Up to 128 GB Micro SD Card (TF Card) |
| Protocol Supported | Wifi (IEEE802.11 a/b/g/n ) |
| Frequency | 2.4GHz～2.4835 GHz |
| Video Codec | H.264 |
| Audio Codec | AAC |
| Resolution | 1280×720 (1.0 MP) 1280×960 (1.3 MP) 1920×1080 (2.0 MP) 1792×1536 (3.0 MP) |
| Video Stream 1 (HD) | 1280×720 (1.0 MP) 1280×960 (1.3 MP) 1920×1080 (2.0 MP) 1792×1536 (3.0 MP) |
| Video Stream 2 (Fluency) | 640 × 480 640 × 480 640 × 480 704 × 576 |
| Frame Rate | 25 FPS at maximum resolution |
| Operating Temperature | -15 to 50°C |
| Storage Temperature | -15 to 50°C |
| Operating Humidity | 10% to 95% with no condensation |
Comparison
How It Differs From The Closest Alternatives
Compared With The WF-360BUB bulb camera
The bulb version screws into a lamp holder for permanent power. This model is a dedicated ceiling fitting.
Compared With The WF-1080WCL weather clock
The clock is 175 degrees and concealed. This is 185 degrees and openly visible.
Use Guide
Getting The Unit Into Service
- Charge or connect power first. Battery models should be fully charged before the first placement; mains models simply run from the socket.
- Fit a micro SD card within the stated limit. Fitting a card larger than the model supports will not work, and cards are not supplied unless the specification says otherwise.
- Place for the lens, then check the frame. Set the unit where it needs to see, record a short test clip and review it before leaving it in position.
- Check the legal position before use. Recording rules differ by country and by room, and audio is usually regulated more tightly than video.
Customisation
OEM And ODM Options
- Housing printing with your own logo and artwork
- Printed manual and insert in your own wording
- Retail packaging produced to your artwork
- Plug type, colour and card capacity variations where the model allows
Related Products
Other Models Buyers Compare With This One
WiFi Hidden Cameras
WiFi Weather Station Clock Camera WF-1080WCL
175 degree view angle covers a whole room from a single shelf
WF-1080WCL
Specifications
Smart Home Security Cameras
360 Panoramic Bulb Camera B22 WF-360BUC
Fits markets that use a bayonet rather than a screw lamp base
WF-360BUC
Specifications
Smart Home Security Cameras
WiFi Table Lamp Baby Monitor WF-720TLC
A lamp is welcome in a nursery in a way a camera housing is not
WF-720TLC
Specifications
Guides About This Kind Of Camera
Design Guide
Lens View Angle Guide For Covert Cameras
From a 50 degree pen to a 185 degree ceiling fisheye. How to pick a view angle for the room rather than for the specification sheet.
Industries Buying This Model
Security Product Distributors
One Supplier Covering A Whole Covert Camera Catalogue
Property Managers And Short Stay Hosts
Check An Unoccupied Property Without Driving To It
Logistics And Warehouse Operators
Cover A Loading Bay Or An Aisle Without Running Cable
Lawful Use Only
WOWLIVE products are supplied for lawful security and property protection. Laws on recording people, and on recording audio in particular, differ between countries and between rooms in the same building. Recording in places where people reasonably expect privacy, such as bathrooms, changing rooms and bedrooms that are not your own, is a criminal offence in most jurisdictions. Buyers and resellers are responsible for checking the rules that apply where the goods are used and sold, including any import, notification and signage requirements. We will not supply orders intended for unlawful surveillance.
Questions
WF-360MOC Questions
Is this camera concealed?
No. This family is visible by design. Use the WiFi or DVR families for concealed units.
What resolution options are there?
1280x720 at 1.0MP, 1280x960 at 1.3MP and a 1920 mode, at up to 25fps.
Is a memory card supplied?
No. The card slot is for local video storage and cards are bought separately.
Does it do two way audio?
Yes, through the mobile app.
Get Pricing On The WF-360MOC
Send us the quantity and destination country for the 360 Panoramic Ceiling WiFi Camera WF-360MOC and we will come back with a price, a lead time and a shipping option.
