Custom-Made Tipper Trailer from SINOHENG
Custom tipper from 30 to 100 tons in U-shape or square body
Looking for a powerful and structurally reliable Tipper Trailer for bulk material transportation? SINOHENG offers you the customized Tipper Trailer, which is specially designed for transporting heavy loads such as sand, gravel, coal, and construction waste, and is adaptable to various complex road conditions and harsh working environments.
- Size
- 9900*2500*4000
- Max Payload
- 30T,40T, 50T, 60T, 70T, 80T, 90T, 100T
- Curb Weight
- 9.5T
- Volume
- 40 cubic meters
Built at SINOHENG Trailer Factory, Jinan, Shandong, China. Exported to 30+ countries across Southeast Asia, Africa, the Middle East and South America.
Operators This Trailer Is Built Around
- Bulk material fleets specifying body shape and payload to their own duty cycle
- Contractors working harsh road conditions where a standard tipper is not enough
Problems It Solves
Standard bodies suit neither sticky nor bulky material
U-shaped bodies optimise material flow, square bodies maximise loading space, and both are built here.
Payload classes vary across a fleet
Eight payload steps from 30 to 100 tons so each unit matches the work it is bought for.
What You Get For the Money
40 m³ body at 60 ton loading capacity
The standard configuration, built from high-strength steel with an efficient hydraulic lifting system.
WABCO brake chambers
Standard braking components with 12R22.5 tyres.
Built for harsh conditions
Specified for sand, gravel, coal and construction waste on complex road surfaces.
Technical Description
Technical Construction
Our dump trailer is made of high-strength steel and has a solid and durable structure. Equipped with an efficient hydraulic lifting system, the unloading is fast and stable, significantly enhancing the transportation efficiency. Whether you need U-shaped carriages to optimize material flow or square structures to expand loading space, we can customize them according to your transportation requirements.
Build and Finish
With years of export experience and a deep understanding of global market demands, SINOHENG trailers have been widely exported to Africa, Southeast Asia, the Middle East, and other regions, and are highly trusted by customers. We always adhere to performance, safety, and service life as the core, providing customers with more valuable transportation solutions.
Operating Detail
SINOHENG Trailer Factory is an enterprise specializing in the production and sales of trailers, dedicated to providing customers with high-quality and high-performance trailer products. We use high-strength steel and optimized design to ensure that the products maintain high load-bearing capacity while being lightweight, meeting customers’ dual demands for transportation efficiency and cost control.
Manufacturing Notes
Our products are not only popular across the country but also exported in bulk to over 30 countries and regions in Southeast Asia, Africa, the Middle East, South America, etc., earning the trust of customers worldwide. Moreover, we offer comprehensive after-sales service to ensure you have no worries. Choosing SINOHENG means choosing quality, choosing professionalism, and choosing peace of mind.
Custom-Made Tipper Trailer from SINOHENG Specification Sheet
Figures below are the published specification for the standard build. Anything not listed is confirmed on the approval drawing before production, and we mark unknowns as TBC rather than estimating them.
| Size | 9900*2500*4000 |
|---|---|
| Max Payload | 30T,40T, 50T, 60T, 70T, 80T, 90T, 100T |
| Curb Weight | 9.5T |
| Volume | 40 cubic meters |
| Loading Capacity | 60T |
| Landing Gear | 28T |
| Material | Steel |
| Leaf Spring | 90(W)mm*13(Thick)mm*10 Layer |
| Brake Chamber | WABCO |
| Tire | 12R22.5 |
This Build in the Factory
How It Compares
This is the configurable option in our tipper range. If you want a fully published fixed specification, take the 42 m³ U-type or the 24 m³ rear dump instead.
Operating Notes
- Tip on level ground with the tractor in line.
- Never drive with the body raised.
- Inspect hydraulic hoses and cylinder pins weekly in heavy duty use.
Every vehicle ships with an illustrated operation manual covering coupling, braking and turning technique.
Other Builds Worth Comparing
3 Axle 24 CBM Rear Dump Semi Trailer (front lifting system)
24 m³ rear tipper with front lifting cylinder on a 9.3 m chassis
View specification →
40m³U-type Tipping Trailer supplier in China
40 m³ U-type tipper with VICT700L body and lifting air suspension axle
View specification →
42m³ 3 Axles U-type Dump Trailer For Sale
42 m³ U-type tipper with ROCKY450 body for sand coal and ore
View specification →
Heavy Duty 50Ton Dump Semi Trailer for Sale
50 ton rear tipper with 40 m³ body on 16 ton axles
View specification →Questions About This Trailer
U-shape or square body?
U-shape for sticky or fine material that hangs up in corners. Square for maximum volume with free-flowing, dry material. Tell us what you haul and we will recommend one.
How do I choose the payload class?
From your legal axle loads and the density of your material. Buying more tonnage than you can legally carry only adds tare weight.
Can I specify the hydraulic brand?
Yes, tell us which hydraulic system your workshops already service and we will quote it.
Do you ship to my country?
SINOHENG exports in bulk to 30+ countries and regions across Southeast Asia, Africa, the Middle East and South America. Send your destination port with the enquiry and we will quote delivery with the trailer.
Ask for a Drawing Before You Commit
We confirm dimensions, axle loads and coupling height on an approval drawing before any steel is cut, so the trailer is legal and couples to your tractors.
