LED RV Lights 12 Inch 32W 3 200 LM 6 000K
The SLL-12X-32 is a 12 inch LED scene light designed for low-profile installation in RVs, trailers, trucks, and off-road vehicles where space is limited and lighting must withstand dust, water, and temperature extremes. Thirty-two 1W Osram LEDs deliver 2,560 effective lumens with a wide 90° flood beam, illuminating the interior or immediate surroundings without glare. The die-cast aluminium housing is sealed to IP67 and coated with durable UV-resistant polyester powder, ensuring long-term performance in harsh environments.
- Wide 90° flood beam spreads 2,560 effective lumens evenly across the interior space of an RV or trailer
- IP67 sealing prevents dust and water ingress during cleaning or exposure to rain and snow
- 32W total power draw with 32×1W Osram LEDs provides high output without overloading a 12V or 24V system
- Operating range of 9 to 32V DC allows use on both 12V and 24V vehicles without voltage regulation
- Overvoltage and overheat protection prevent damage from electrical surges or blocked airflow
Where This Lamp Is Used
- Interior ambient lighting in RVs and motorhomes during evening use or camping
- Roof or side panel lighting on trailers and utility trucks where low profile is required
- Scene lighting for outdoor events or off-road vehicle setups where wide coverage is needed
- Lighting for storage compartments, cabinets, or under-seat areas in mobile units
- Replacement for halogen or fluorescent fixtures that burn out quickly or draw too much power
Who It Is For
- Distributors of RV and trailer accessories needing a reliable, low-profile LED light
- Machinery OEMs fitting interior lighting on mobile units with limited mounting space
- Fleet operators upgrading interior lighting on service trucks and utility vehicles
- 4x4 accessory brands building a private label scene lighting range for off-road use
- RV owners replacing halogen lights that fail under vibration or heat
Problems It Solves
- Halogen lights in RVs burn out quickly and draw excessive current, stressing the vehicle’s electrical system
- Non-sealed LED lights fog up or fail when exposed to dust and moisture during cleaning
- Narrow beam lights leave corners of an RV interior dark, reducing usability at night
- Lights with no overvoltage protection can be damaged by alternator spikes during engine start
- Painted metal housings degrade under UV exposure and salt spray in coastal or winter environments
Technical Features
- Thirty-two 1W Osram LEDs with a raw output of 3,200 lumens and 2,560 effective lumens
- Wide 90° flood beam angle for even illumination across the interior or immediate area
- Die-cast aluminium housing with durable UV-resistant polyester powder coating
- Anti-UV polycarbonate lens resists yellowing and scratches from cleaning or contact
- IP67 waterproof and dustproof sealing with a gasketed cable entry and sealed housing
- Overvoltage and overheat protection circuits prevent damage from electrical faults
- Operating voltage range of 9 to 32V DC compatible with 12V and 24V systems
- Operating temperature range from -40 to +85 degrees Celsius for use in extreme climates
- 32W maximum power draw with a real power consumption of 32W at 12V
- Bare wire lead of 40cm standard, with connector options available on request
Technical Specification
Values taken from the original factory specification for this model. Fields the factory sheet does not state are left out rather than estimated.
| Part Number | SLL-12X-32 |
|---|---|
| Size | 12 inch |
| Max Power | 32W |
| Real Power | 32W |
| LED | 32 pcs x 1W Osram |
| Raw Lumen | 3200 lm |
| Effective Lumen | 2560 lm |
| Beam Pattern | Flood |
| Beam Angle | 90 degrees |
| Colour Temperature | 6000K |
| Operating Voltage | 9 - 32V DC |
| Housing Material | Die-cast aluminium, UV-resistant polyester powder coating |
| Lens Material | Anti-UV polycarbonate |
| Waterproof Rating | IP67 |
| Operating Temperature | -40 to +85 degrees Celsius |
| Electrical Connection | Bare wire 40cm, connector available on request |
Materials Used
- Die-cast aluminium housing with UV-resistant polyester powder coating
- Anti-UV polycarbonate lens with scratch-resistant surface
- Silicone rubber gasket for IP67 sealing
- Internal overvoltage and overheat protection circuitry
- Bare wire lead with 40cm length, shielded for electrical stability
How This Lamp Is Built
Die casting of the aluminium housing and heat sink
Powder coating with UV-resistant polyester finish
LED board assembly with 32×1W Osram emitters
Lens bonding and gasket sealing to achieve IP67 rating
Quality Control on This Model
- Photometric output verified in an integrating sphere for lumen accuracy
- Sealing verified against the IP67 rating using water spray and dust exposure tests
- Vibration testing on a vibration test machine to simulate vehicle-mounted service
- Salt spray corrosion testing on the housing coating and internal components
- High and low temperature alternating humidity testing across the -40 to +85 degrees Celsius range
Customisation Options
- Deutsch connector or other terminal type instead of the standard 40cm bare wire lead
- Alternative cable length to match a specific vehicle harness
- Private label logo on the housing and printed carton
- Mixed cartons combining this light with other SUNLITEC models for trial orders
- Flood beam pattern available only; spot beam not offered as an option
How It Compares With the Alternatives
| Round 12 inch LED light | The square body fits flush in narrow roof or wall spaces where a round housing would protrude |
|---|---|
| Spot beam version of the same lamp | Flood covers the full interior area evenly while spot concentrates light on a single point |
| Smaller 8 inch LED light | Higher output and wider beam but requires more mounting space and a flat surface |
How to Fit and Use It
- Leave a drip loop in the 40cm lead to prevent water from running into the gland
- Aim the flood beam at the interior area to be lit and avoid direct eye exposure
- Clean the polycarbonate lens with water and a soft cloth only—avoid solvents that degrade the coating
Questions About This Model
Can I order a sample before placing a bulk order
Yes. Sample orders are welcome and mixed samples of different models in one shipment are accepted.
What is the lead time
Sample orders normally take around 3 to 7 working days. Bulk lead time depends on the model and the quantity ordered.
Do you have a minimum order quantity
There is an MOQ for standard orders, but smaller orders are also accepted, which suits distributors testing a new model.
How is the lamp shipped
Samples usually go by DHL, UPS, FedEx or TNT in around 4 to 7 days. Bulk orders ship by air in about 7 to 15 days or by sea in about 15 to 30 days.
Will this lamp work on both 12V and 24V machines
Yes. The operating range is 9 to 32V DC, so the same part number can be fitted to 12V and 24V vehicles.
Can you supply the lamp with our own brand
Yes. OEM and ODM service is available, including a private label logo on the housing and printed cartons.
Is it approved for use in vehicles on public roads
The lamp is CE and RoHS compliant and carries IP67 sealing, but it is not specifically certified for road use beyond EMC and safety standards.
Get a Price on LED RV Lights 12 Inch 32W 3 200 LM 6 000K
Send the quantity, the destination port and any branding requirement. You will get pricing, packing data and the production lead time.
