LED Machine Work Light
The SLL-0602-16 is a 6 inch LED machine work light designed for consistent illumination on heavy machinery operating in harsh conditions. It delivers 1440 effective lumens across a wide flood beam pattern, ensuring visibility across the entire work zone without hot spots.
- 1440 effective lumens spread evenly across a wide flood beam, eliminating dark edges around the machine
- IP68 sealing and a durable polycarbonate lens prevent water and dust ingress during pressure washing
- 9 to 32V DC operating range allows the same part number to be used on 12V and 24V fleets, reducing SKU count
- Overvoltage and overheat protection prevent failure during electrical spikes or prolonged high-load operation
- 50000 hour lifespan reduces replacement frequency and maintenance downtime on night-shift or remote machines
Where This Lamp Is Used
- Front and side work lighting on forklifts and loaders operating in dimly lit warehouses or outdoor yards
- Cab and deck lighting on excavators and engineering vehicles during night shifts or low-light conditions
- Auxiliary lighting on mining support vehicles where vibration and dust degrade standard sealed lamps
- Loading bay and trailer bed lighting on tipper trucks and service vehicles that operate in wet or dusty environments
- Machine-mounted lighting on cranes and vessels where consistent illumination is needed during maintenance or night operations
Who It Is For
- Distributors sourcing 12V and 24V vehicle lighting with a single part number for both systems
- Machinery OEMs integrating work lights into production lines and needing a repeatable mounting pattern
- Fleet operators replacing halogen lights that fail after a few hundred hours under vibration
- 4x4 and industrial accessory brands developing a private label work light range with consistent performance
- Equipment dealers fitting lighting on machines sold to mining, agriculture, or construction clients
Problems It Solves
- Halogen work lights burn out quickly under vibration and draw excessive current from the vehicle’s electrical system
- Cheap sealed lamps fail after a few wash cycles due to water ingress through the cable entry or lens seal
- Narrow beam lamps create a bright spot but leave the edges of the work area in shadow
- Mild steel brackets rust within weeks on machines washed daily with water or cleaning agents
- Lights without overvoltage protection fail during alternator spikes or sudden voltage drops in heavy machinery
Technical Features
- Sixteen 1W Osram LEDs with a real power draw of 16W and 1600 raw lumens
- Wide flood beam pattern with 1440 effective lumens and a 1 lux reading at 50 meters
- Semi-gloss black powder coating over the full housing and stud mount
- Bare wire lead of 40cm as standard with Deutsch connector available on request
- Overvoltage and overheat protection built into the driver circuit
- Operating window of -40 to +85 degrees Celsius, suitable for extreme climates
- IP68 sealing with a sealed cable gland and silicone gasket to prevent water and dust ingress
Technical Specification
Values taken from the original factory specification for this model. Fields the factory sheet does not state are left out rather than estimated.
| Part Number | SLL-0602-16 |
|---|---|
| Max Power | 16W |
| Real Power | 16W |
| LED | 16 pcs x 1W Osram |
| Theoretical Lumen | 1600 lm |
| Beam Pattern | Wide Flood |
| 1 Lux Reading | Wide Flood 50 meters |
| Colour Temperature | 6000K |
| Operating Voltage | 9-32V DC |
| Lens Material | Anti-scratch PC |
| Waterproof Rating | IP68 |
| Operating Temperature | -40 to +85 degrees Celsius |
| Electrical Connection | Bare wire 40cm, Deutsch connector available |
| Certification | CE, RoHS |
Materials Used
- Anti-scratch UV resistant polycarbonate lens
- Silicone rubber gasket and sealed cable entry gland
- Semi-gloss black powder coating
How This Lamp Is Built
Die casting of the aluminium housing and heat sink
Powder coating in semi-gloss black
LED board assembly with Osram emitters
Lens bonding and gasket sealing
Quality Control on This Model
- Photometric output verified in an integrating sphere
- Sealing verified against the IP68 rating before shipment
- Vibration testing on a vibration test machine to simulate machine-mounted service
- Salt spray corrosion testing on housing coating and stainless steel stud mount
- High and low temperature alternating humidity testing across the -40 to +85 degrees Celsius range
Customisation Options
- Deutsch DT connector instead of the standard 40cm bare wire lead
- Spot beam optics in place of the wide flood pattern
- Private label logo on the housing and printed carton
- Alternative cable length for a specific machine harness
- Mixed cartons combining this lamp with other SUNLITEC models for trial orders
How It Compares With the Alternatives
| Round 6 inch work lamp | The square body fits a flat mounting surface and provides more LED area behind the same footprint |
|---|---|
| Spot beam version of the same lamp | Wide flood covers the near work area evenly while spot reaches further ahead but leaves the machine edges dark |
| Smaller 4 inch work lamp | Higher output and wider beam coverage on larger machines where a 4 inch body would not illuminate the full work zone |
How to Fit and Use It
- Leave a drip loop in the 40cm lead so water runs away from the gland rather than into it
- Aim the wide flood beam at the working area close to the machine and use a spot lamp separately for distance
- Clean the PC lens with water and a soft cloth only, since solvents will haze the anti-scratch coating
Questions About This Model
Can I order a sample before placing a bulk order
Yes. Sample orders are welcome and mixed samples of different models in one shipment are accepted.
What is the lead time
Sample orders normally take around 3 to 7 working days. Bulk lead time depends on the model and the quantity ordered.
Do you have a minimum order quantity
There is an MOQ for standard orders, but smaller orders are also accepted, which suits distributors testing a new model.
How is the lamp shipped
Samples usually go by DHL, UPS, FedEx or TNT in around 4 to 7 days. Bulk orders ship by air in about 7 to 15 days or by sea in about 15 to 30 days.
Will this lamp work on both 12V and 24V machines
Yes. The operating range is 9 to 32V DC, so the same part number can be fitted to 12V and 24V vehicles.
Can you supply the lamp with our own brand
Yes. OEM and ODM service is available, including a private label logo on the housing and printed cartons.
Is it approved for road going machines
The lamp is CE and RoHS compliant, and carries IP68 sealing and ECE R10 approval for electromagnetic compatibility.
Get a Price on LED Machine Work Light
Send the quantity, the destination port and any branding requirement. You will get pricing, packing data and the production lead time.
