LED Lights for Work
The SLL-0802-16H is a 3 inch square LED work light designed for machines that operate in dark, dusty or wet environments where reliable illumination is critical. Sixteen 1W Osram LEDs deliver 1,920 total lumens with a wide flood beam pattern, ensuring the entire work zone is visible without hot spots. The die-cast aluminium housing with IP68 sealing and overvoltage and overheat protection ensures long-term performance under vibration and harsh conditions on forklifts, excavators and utility vehicles.
- 16 x 1W Osram LEDs provide 1,920 total lumens with a wide flood beam for even coverage across the work area
- IP68 sealing prevents water and dust ingress during pressure washing or outdoor operation
- Overvoltage and overheat protection extend service life in unstable electrical environments
- 9 to 32V DC operation allows use on both 12V and 24V machines without changing part numbers
- Die-cast aluminium housing with durable UV-resistant polyester powder coating resists corrosion and impact
Where This Lamp Is Used
- Front and side work lighting on forklifts operating in dim warehouse aisles
- Cab and boom lighting on excavators and loaders during night shift operations
- Auxiliary lighting on service trucks and utility vehicles used in remote or poorly lit areas
- Machine deck and platform lighting on engineering vehicles and cranes
- Lighting for maintenance crews working on mining machinery in low-light conditions
Who It Is For
- Distributors of vehicle lighting needing one part number to serve both 12V and 24V fleets
- Machinery OEMs fitting work lights on production lines with consistent mounting patterns
- Fleet operators replacing halogen lamps that fail under vibration or after a few wash cycles
- 4x4 and industrial accessory brands building a private label work light range with consistent performance
Problems It Solves
- Halogen work lamps burn out quickly under vibration and draw excessive current from the vehicle’s electrical system
- Cheap sealed lights let water in through the cable entry and fog up after a few cleaning cycles
- Narrow beam lamps create bright spots but leave the edges of the work zone in shadow
- Non-IP68 rated lights fail after exposure to rain, dust or pressure washing on daily-use machines
- Lamps without overvoltage protection are damaged by voltage spikes in older or unregulated vehicle systems
Technical Features
- Sixteen 1W Osram LEDs with a total output of 1,920 lumens
- Wide flood beam pattern with effective coverage across the immediate work area
- Semi-gloss black UV-resistant polyester powder coating on the full housing
- Bare wire lead of 40cm as standard with Deutsch connector available on request
- Overvoltage and overheat protection built into the internal circuitry
- Operating voltage range of 9 to 32V DC compatible with 12V and 24V systems
- Operating temperature range from -40 to +85 degrees Celsius
- Rated for more than 50,000 hours of continuous operation
Technical Specification
Values taken from the original factory specification for this model. Fields the factory sheet does not state are left out rather than estimated.
| Part Number | SLL-0802-16H |
|---|---|
| Max Power | 16W |
| Real Power | 16W |
| LED | 16 pcs x 1W Osram |
| Beam Pattern | Wide Flood |
| Colour Temperature | 6000K |
| Operating Voltage | 9-32V DC |
| Lens Material | Anti-reflective PC |
| Waterproof Rating | IP68 |
| Operating Temperature | -40 to +85 degrees Celsius |
| Electrical Connection | Bare wire 40cm, Deutsch connector available |
Materials Used
- Anti-reflective UV-resistant polycarbonate lens
- Silicone rubber gasket and sealed cable entry gland
- Semi-gloss black UV-resistant polyester powder coating
How This Lamp Is Built
Die casting of the aluminium housing and heat sink
Powder coating in semi-gloss black
LED board assembly with Osram emitters
Lens bonding and gasket sealing
Quality Control on This Model
- Photometric output verified in an integrating sphere
- Sealing verified against the IP68 rating before shipment
- Vibration testing on a vibration test machine to reproduce machine mounted service
- Salt spray corrosion testing on housing coating and stainless bracket
- High and low temperature alternating humidity testing across the -40 to +85 degrees Celsius window
Customisation Options
- Deutsch DT connector instead of the standard 40cm bare wire lead
- Spot beam optics in place of the wide flood pattern
- Private label logo on the housing and printed carton
- Alternative cable length for a specific machine harness
- Mixed cartons combining this lamp with other SUNLITEC models for trial orders
How It Compares With the Alternatives
| Round 3 inch work lamp | The square body puts more LED area behind the same mounting footprint but needs a flat surface for the bottom bracket |
|---|---|
| Spot beam version of the same lamp | Wide flood covers the near working area evenly while spot reaches further ahead but leaves the machine edges dark |
| Larger 4 inch work lamp | Lower output but fits tight spaces like cab pillars and guard rails where a 4 inch body will not clear |
How to Fit and Use It
- Leave a drip loop in the 40cm lead so water runs away from the gland rather than into it
- Aim the wide flood beam at the immediate work area close to the machine and use a spot lamp separately for distance
- Clean the PC lens with water and a soft cloth only, since solvents will haze the anti-reflective coating
Questions About This Model
Can I order a sample before placing a bulk order
Yes. Sample orders are welcome and mixed samples of different models in one shipment are accepted.
What is the lead time
Sample orders normally take around 3 to 7 working days. Bulk lead time depends on the model and the quantity ordered.
Do you have a minimum order quantity
There is an MOQ for standard orders, but smaller orders are also accepted, which suits distributors testing a new model.
How is the lamp shipped
Samples usually go by DHL, UPS, FedEx or TNT in around 4 to 7 days. Bulk orders ship by air in about 7 to 15 days or by sea in about 15 to 30 days.
Will this lamp work on both 12V and 24V machines
Yes. The operating range is 9 to 32V DC, so the same part number can be fitted to 12V and 24V vehicles.
Can you supply the lamp with our own brand
Yes. OEM and ODM service is available, including a private label logo on the housing and printed cartons.
Is it approved for road going machines
The lamp is CE and RoHS compliant and carries ECE R10 approval for electromagnetic compatibility, together with an IP68 sealing rating.
