High Power Compact Light 15W
The SLL-9015 is a high power compact 15W LED work light designed for machines that operate in low light, dusty, wet or vibrating conditions. One CREE 15W LED delivers 1200 effective lumens in either flood or spot beam, providing clear visibility across the immediate work zone without requiring a large mounting footprint. The die-cast aluminium housing with UV resistant powder coating and IP68 sealing ensures long life in harsh environments, while overvoltage and overheat protection prevent electrical damage during unstable power supply. This light is suitable for fitting on vehicles and machinery where space is limited but reliable illumination is critical.
- 15W CREE LED delivers 1200 effective lumens in flood or spot beam for clear visibility in dark or dusty work zones
- IP68 sealing and a durable polycarbonate lens prevent water and dust ingress during washing or outdoor use
- Overvoltage and overheat protection safeguard the LED and driver during unstable power supply on vehicles
- 9 to 32V DC operation allows use on both 12V and 24V systems without changing part numbers
- Die-cast aluminium housing with UV resistant powder coating resists corrosion and fading over time
Where This Lamp Is Used
- Side and rear work lighting on forklifts and compact loaders in warehouse night shifts
- Auxiliary lighting on excavators and engineering vehicles operating in muddy or wet conditions
- Cab roof and dashboard lighting on utility trucks and service vehicles used after dark
- Mounting on the front or side of mining support vehicles where vibration damages standard lamps
- Installation on small off-road vehicles or trailers where space limits the size of the light
Who It Is For
- Distributors of compact vehicle lighting needing one part number for 12V and 24V fleets
- Machinery OEMs fitting work lights on production lines with limited mounting space
- Fleet operators replacing halogen lights that fail under vibration or in wet environments
- 4x4 accessory brands building a private label compact light range with beam options
- Equipment dealers fitting lights on small vehicles or trailers where size and weight matter
Problems It Solves
- Halogen work lights burn out quickly under vibration and draw excessive current from the vehicle’s electrical system
- Compact lights with poor sealing let water in during pressure washing, causing fogging and early failure
- Lights without overvoltage protection fail when the alternator spikes during engine start
- Narrow beam lights leave the immediate work edge dark, while wide beam lights lack reach
- Painted metal housings fade or peel in UV exposure, reducing both appearance and protection
Technical Features
- One CREE 15W LED with a real output of 1200 effective lumens
- Beam pattern selectable as flood or spot, depending on application needs
- Die-cast aluminium housing with semi-gloss UV resistant polyester powder coating
- Anti-UV, impact-resistant polycarbonate lens with scratch-resistant surface
- IP68 sealing rating with sealed cable entry and gasket to prevent water and dust ingress
- Overvoltage protection and overheat protection built into the driver circuit
- Operating voltage range of 9 to 32V DC for compatibility with 12V and 24V systems
- Operating temperature range from -40 to +60 degrees Celsius
- Lifespan rated at more than 50,000 hours
- Compact size suitable for tight mounting spaces on small vehicles and machinery
Technical Specification
Values taken from the original factory specification for this model. Fields the factory sheet does not state are left out rather than estimated.
| Part Number | SLL-9015 |
|---|---|
| LED | 1 x 15W CREE |
| Beam Pattern | Flood or Spot (optional) |
| Operating Voltage | 9 – 32V DC |
| Operating Temperature | -40 to +60 degrees Celsius |
| Colour Temperature | 6000K |
| Waterproof Rating | IP68 |
| Housing Material | Die-cast aluminium |
| Lens Material | Durable polycarbonate |
| Coating | UV resistant polyester powder coating |
| Protection | Overvoltage and overheat protection |
Materials Used
- Die-cast aluminium housing
- UV resistant polyester powder coating
- Durable polycarbonate lens
- Silicone rubber gasket
- Sealed cable entry gland
- Internal driver with overvoltage and overheat protection
How This Lamp Is Built
Die casting of the aluminium housing and heat sink
Powder coating with UV resistant polyester finish
LED board assembly with a single CREE 15W emitter
Lens bonding and gasket sealing
Quality Control on This Model
- Photometric output verified in an integrating sphere
- Sealing verified against the IP68 rating using a pressure test
- Vibration testing on a vibration test machine to simulate machine-mounted service
- Salt spray corrosion testing on the powder coating and housing
- High and low temperature alternating humidity testing across the -40 to +60 degrees Celsius range
Customisation Options
- Option to select flood or spot beam pattern at time of order
- Private label logo on the housing and printed carton
- Alternative cable length to match specific machine harnesses
- Deutsch connector instead of standard bare wire lead
- Mixed cartons combining this light with other SUNLITEC models for trial orders
How It Compares With the Alternatives
| Standard 15W LED with plastic housing | Die-cast aluminium housing resists impact and heat better than plastic |
|---|---|
| Round compact light | Square design fits flush on flat surfaces and provides more mounting stability |
| Larger 20W LED work light | Same lumen output in a smaller footprint, ideal for tight spaces |
How to Fit and Use It
- Mount on a flat surface using the standard bracket or adapt to existing mounting points
- Wire through a fused feed sized for the current draw at 12V or 24V, ensuring the cable entry points downward
- Leave a drip loop in the cable to prevent water from running into the gland
- Choose flood beam for near work area coverage or spot beam for longer reach
- Clean the polycarbonate lens with water and a soft cloth only to preserve the scratch-resistant coating
Questions About This Model
Can I order a sample before placing a bulk order
Yes. Sample orders are welcome and mixed samples of different models in one shipment are accepted.
What is the lead time
Sample orders normally take around 3 to 7 working days. Bulk lead time depends on the model and the quantity ordered.
Do you have a minimum order quantity
There is an MOQ for standard orders, but smaller orders are also accepted, which suits distributors testing a new model.
How is the lamp shipped
Samples usually go by DHL, UPS, FedEx or TNT in around 4 to 7 days. Bulk orders ship by air in about 7 to 15 days or by sea in about 15 to 30 days.
Will this lamp work on both 12V and 24V machines
Yes. The operating range is 9 to 32V DC, so the same part number can be fitted to 12V and 24V vehicles.
Can you supply the lamp with our own brand
Yes. OEM and ODM service is available, including a private label logo on the housing and printed cartons.
Is it approved for road going machines
The lamp is CE and RoHS compliant and carries IP68 sealing, but ECE R10 approval is not listed for this model.
Get a Price on High Power Compact Light 15W
Send the quantity, the destination port and any branding requirement. You will get pricing, packing data and the production lead time.
