Best LED Work Light
The SLL-0806-24 is a 3 inch square LED work light designed for vehicles and machinery that operate in harsh conditions with no tolerance for failure. It delivers 2400 effective lumens across a wide flood beam pattern, ensuring consistent illumination across the immediate work zone without hot spots. The die-cast aluminium housing with UV-resistant polyester powder coating and polycarbonate lens resists corrosion, impact and UV degradation. Certified to E-mark, CE, RoHS and CISPR25/Class 3, it meets electrical interference and environmental standards required for use on public roads and in industrial environments.
- 2400 effective lumens spread evenly across a wide flood beam, eliminating dark edges around the machine
- IP68 sealing and a durable polycarbonate lens prevent water and dust ingress during pressure washing and outdoor use
- E-mark approval ensures compatibility with road-going vehicles and avoids rejection during inspection
- 9 to 32V DC operation supports both 12V and 24V systems, reducing the number of SKUs needed for fleet inventory
- Overvoltage and overheat protection prevent damage from electrical surges and prolonged high-temperature operation
Where This Lamp Is Used
- Front and side work lighting on off-road vehicles and utility trucks operating in low visibility
- Cab and roof lighting on full size SUVs and 4x4s used in remote or rural areas
- Auxiliary lighting on excavators and cranes during night construction or maintenance tasks
- Deck and platform lighting on service vehicles and mobile repair units
- Forklift and engineering vehicle lighting where vibration and dust degrade standard sealed lamps
Who It Is For
- Distributors of vehicle lighting needing one part number to serve both 12V and 24V fleets
- Machinery OEMs integrating work lights into production line builds with consistent mounting and electrical specs
- Fleet operators replacing halogen lamps that fail within months under vibration and heat
- 4x4 accessory brands developing a private label work light range with proven reliability
Problems It Solves
- Halogen work lights burn out quickly under vibration and draw excessive current from the vehicle’s electrical system
- Cheap sealed lamps allow water to enter through the cable gland and fog up after a few wash cycles
- Uncertified auxiliary lighting can fail an E-mark or road inspection on machines used on public roads
- Narrow beam lamps create a bright spot but leave the working edge of the machine in shadow
- Painted metal brackets corrode within weeks on machines exposed to salt, moisture or fertiliser residue
Technical Features
- 24 pcs x 1W Osram LEDs with a real power draw of 24W and a maximum rating of 24W
- Semi-gloss black powder coating over the full housing and bracket
- Bare wire lead of 40cm as standard with a Deutsch connector available on request
- EMC protected wiring and an operating window of -40 to +85 degrees Celsius
- Overvoltage and overheat protection built into the internal circuitry
Technical Specification
Values taken from the original factory specification for this model. Fields the factory sheet does not state are left out rather than estimated.
| Part Number | SLL-0806-24 |
|---|---|
| Max Power | 24W |
| Real Power | 24W |
| LED | 24 pcs x 1W Osram |
| Beam Pattern | Flood |
| Colour Temperature | 6000K |
| Operating Voltage | 9-32V DC |
| Lens Material | Anti-scratch PC |
| Waterproof Rating | IP68 |
| Operating Temperature | -40 to +85 degrees Celsius |
| Electrical Connection | Bare wire 40cm, Deutsch connector available |
| Certification | E-mark, CE, RoHS, EMC, CISPR25/Class 3 |
Materials Used
- Anti-scratch UV resistant polycarbonate lens
- Silicone rubber gasket and sealed cable entry gland
- Semi-gloss black powder coating
How This Lamp Is Built
Die casting of the aluminium housing and heat sink
Powder coating in semi-gloss black
LED board assembly with Osram emitters
Lens bonding and gasket sealing
Quality Control on This Model
- Photometric output verified in an integrating sphere
- Sealing verified against the IP68 rating before shipment
- Vibration testing on a vibration test machine to reproduce machine mounted service
- Salt spray corrosion testing on housing coating and stainless bracket
- High and low temperature alternating humidity testing across the -40 to +85 degrees Celsius window
Customisation Options
- Deutsch DT connector instead of the standard 40cm bare wire lead
- Spot beam optics in place of the flood pattern
- Private label logo on the housing and printed carton
- Alternative cable length for a specific machine harness
- Mixed cartons combining this lamp with other SUNLITEC models for trial orders
How It Compares With the Alternatives
| Round 3 inch work lamp | The square body fits the same mounting footprint but provides more LED area and better heat dissipation |
|---|---|
| Spot beam version of the same lamp | Flood covers the near working area evenly while spot reaches further ahead but leaves the machine edges dark |
| Larger 4 inch work lamp | Lower output but fits tight spaces like cab pillars and guard rails where a 4 inch body will not clear |
How to Fit and Use It
- Leave a drip loop in the 40cm lead so water runs away from the gland rather than into it
- Aim the flood beam at the working area close to the machine and use a spot lamp separately for distance
- Clean the PC lens with water and a soft cloth only, since solvents will haze the anti-scratch coating
Questions About This Model
Can I order a sample before placing a bulk order
Yes. Sample orders are welcome and mixed samples of different models in one shipment are accepted.
What is the lead time
Sample orders normally take around 3 to 7 working days. Bulk lead time depends on the model and the quantity ordered.
Do you have a minimum order quantity
There is an MOQ for standard orders, but smaller orders are also accepted, which suits distributors testing a new model.
How is the lamp shipped
Samples usually go by DHL, UPS, FedEx or TNT in around 4 to 7 days. Bulk orders ship by air in about 7 to 15 days or by sea in about 15 to 30 days.
Will this lamp work on both 12V and 24V machines
Yes. The operating range is 9 to 32V DC, so the same part number can be fitted to 12V and 24V vehicles.
Can you supply the lamp with our own brand
Yes. OEM and ODM service is available, including a private label logo on the housing and printed cartons.
Is it approved for road going machines
The lamp is E-mark approved, CE and RoHS compliant, and meets CISPR25/Class 3 EMC standards for electromagnetic compatibility.
Get a Price on Best LED Work Light
Send the quantity, the destination port and any branding requirement. You will get pricing, packing data and the production lead time.
