The Sinotruk mini jetting truck is a 4x2 chassis mounted vacuum and jetting unit designed for clearing blockages in sewer lines and pumping out fecal waste. It combines high-pressure jetting to dislodge debris with powerful vacuum suction to remove sludge and water from manholes. Built on a Sinotruk HOWO chassis, it is used by municipal sanitation departments, waste contractors, and environmental service providers in regions with limited access to large-scale cleaning equipment. The truck operates in urban and rural areas where pipeline blockages require rapid response and high-efficiency cleaning without the need for heavy infrastructure.
| Chassis | Sinotruk HOWO 4x2 |
|---|---|
| Overall Dimensions | 5900 x 2200 x 2600 mm |
| GVW | 7300 kg |
| Mass in Working Order | 4000 kg |
| Tank Capacity | 4 cbm |
| Tank Material | 5mm high-quality carbon steel |
| Tank Structure | Welded, cylindrical, vacuum tank |
| Vacuum Pump Flow | 45 L/s |
| Vacuum Pump Speed | 500~800 r/min |
| Vacuum Pump Shaft Power | 4 kW |
| Max Vacuum Degree | 15 kPa |
| Suction Time | ≤ 5 minutes |
| Effective Suction Range | ≥ 8 meters |
| Dump Angle | ≥ 45 degrees |
| High-Pressure Pump Brand | Tianjin Tongjie standard, Germany Pinfu optional |
| Vacuum Pump Brand | Veyron standard, Shandong water ring pump optional |
| Drive Method | Chassis engine + sandwich power take-off |
| Production Time | 20 days |
| Lead Time | 7 to 30 days after order confirmation |
| Shipping Mode | Ro-ro, bulk ship or container from China main port |
| 6x4 jetting truck with 8 cbm tank | Higher capacity and better off-road performance but requires more space and higher fuel cost |
|---|---|
| Standard vacuum truck without jetting | Cannot clear blockages in pipelines but better for dry sludge and routine pumping |
| Used imported jetting truck | Lower upfront cost but longer lead time for parts and no local technical support |
Production time is 20 days. Total delivery time is 7 to 30 days after order confirmation, depending on shipping mode and chassis availability.
Yes. The standard tank is 5mm carbon steel. Stainless steel is available as an optional upgrade. Specify your waste type and storage duration for material recommendation.
T/T with 30 percent deposit and 70 percent before delivery. We send photos and videos of the finished truck before you pay the balance.
Yes. The standard pump is Tianjin Tongjie. Germany Pinfu brand is available as an optional upgrade. Confirm your pressure and flow needs at order stage.
By Ro-ro, bulk ship, or container from a China main port. Trade terms are EXW, FOB, CFR, or CIF.
The whole vehicle is guaranteed for one year. Core parts are covered for two years. We provide 15 years of spare parts and technical support with overseas engineer visits available.
Yes. We manufacture to customer supplied drawings and specifications. Provide your layout, tank dimensions, and equipment list at order stage.
Send us your destination port and we will quote price, lead time and freight.
