Home/ All Trucks/ Sinotruk Sewer Jetting Truck/Sinotruck howo 22cbm vacuum jetter truck Somalia

Sinotruk Sewer Jetting Truck

Sinotruck howo 22cbm vacuum jetter truck Somalia

Name: Sinotruck howo 22cbm vacuum jetter truck Somalia
Brand: Sinotruk HOWO

The Sinotruk HOWO 22cbm vacuum jetter truck is a 12,000 litre combined sewer cleaning vehicle built on a 4x2 chassis with a 371 HP diesel engine and 10-speed manual gearbox. It is designed for municipal sanitation departments and waste contractors that need to clear blockages in sewage pipelines using high-pressure jetting and then remove debris and sludge via powerful vacuum suction. The truck operates in urban and rural environments where sewer access is limited and maintenance cycles must be fast and reliable. It is deployed in regions like Somalia where infrastructure is underdeveloped and waterborne waste must be managed without reliance on centralised treatment plants.

Request A Quote Email Specification

Key Benefits

12,000 litre Q235 high tension steel tank with 5mm thickness resists corrosion and deformation under repeated loading
Italian brand Jurop PN84D vacuum pump achieves -0.092 MPa vacuum pressure for rapid sludge removal
High-pressure jetting system with 5 metre rubber hose clears blockages in pipelines up to 150 mm diameter
Middle tipper dumping system with hydraulic rear door and middle lift allows full tank discharge without manual handling
Reinforced diaphragm clutch and ZF 8118 power steering ensure reliable operation on rough and unpaved access roads
100% custom-built to customer specifications including tank capacity, colour, and logo, with no minimum order requirement

Buyer Profile

Who It Is for

Municipal sanitation and public works departments in developing countries
Waste and drainage contractors serving urban and rural communities
Port and industrial park operators managing on-site waste and drainage systems
Contractors supplying turnkey sanitation services to government or private clients
Government procurement agencies equipping new sanitation fleets for regional or national programs

Operating Problems

Problems It Solves

Sewer blockages caused by grease, debris, or tree roots that prevent flow in aging or undersized pipelines
Slow and inefficient manual cleaning that requires multiple crew members and long turnaround times
Lack of reliable vacuum capacity in low-cost or second-hand trucks that fail under repeated use
Inadequate jetting pressure that cannot clear hardened sludge or scale in older pipes
Poor tank durability in low-grade steel that develops leaks after 12 months of service
Long lead times for imported trucks with no local support or spare parts availability

Where It Works

Application Scenarios

Municipal sanitation departments in developing cities with limited sewer infrastructure and no central treatment plants
Waste contractors operating in remote or rural areas where access roads are unpaved and maintenance windows are short
Port and industrial zone operators managing on-site sewage lines that require frequent cleaning without external support
Emergency response teams clearing blockages after heavy rains or flooding in urban drainage systems
Contractors maintaining septic systems and drainage networks in agricultural and livestock zones
Government agencies upgrading sanitation services in regions with high population density and poor sewer coverage

Engineering

Technical Features

High-efficiency Italian brand Jurop PN84D vacuum suction pump with -0.092 MPa vacuum pressure
5 metre high-pressure rubber hose with quick-connect fittings for jetting into sewer manholes
Middle tipper dumping system with hydraulic rear door and middle lift for full tank discharge
Water-gas and oil-gas separators prevent contamination of the vacuum system and extend pump life
Four-way valve and anti-overflow warning device protect the pump and tank from overfilling
Dual circuit compressed air brakes with spring energy parking brake and engine exhaust valve auxiliary brake ensure safe operation

Specifications

Technical Data


Chassis	Sinotruk HOWO 4x2
Engine	SINO Truck Diesel WD615.46, 371 HP, Euro II
Gearbox	HW13710, 10 forwards & 2 reverse
Overall Size	9300 x 2500 x 3500 mm
Wheelbase	4300+1350 mm
Curb Weight	9500 kg
Loading Weight	10,000 kg
Tank Capacity	12,000 L
Tank Material	Q235 high tension steel, 5 mm body and end plate
Vacuum Pump	Italian brand Jurop PN84D
Vacuum Pressure	-0.092 MPa
Jetting Hose	5 metre rubber pipe
Dumping System	Middle tipper, hydraulic controlled rear door and middle lift
Cabin	HW76 Standard Cabin, RHD, 1 Sleeper, Air Conditioner, 3 Passengers
Clutch	Reinforced diaphragm, 430 mm diameter
Steering	ZF 8118, power steering with hydraulic assistance
Tires	11R22.5, all tubeless, 6 pieces with 1 spare
Brakes	Dual circuit compressed air, spring energy parking, engine exhaust valve auxiliary
Production Time	20 days
Lead Time	20 days after advance payment

Build Materials

Materials

Q235 high tension steel tank body and end plates, 5 mm thick for structural integrity
Italian brand Jurop PN84D vacuum pump with corrosion-resistant internal components
5 metre high-pressure rubber hose with reinforced lining for repeated use
Aluminium alloy fittings and stainless steel valves for corrosion resistance in wet environments
Reinforced diaphragm clutch with 430 mm diameter for high torque transmission
Hydraulic system with sealed actuators and anti-leak seals for long-term reliability

How It Is Built

Manufacturing Process

Chassis is received from Sinotruk and wheelbase is verified against the tank drawing
Tank shell is cut, rolled, and welded with internal clapboards to control surge and prevent deformation
Tank is pressure tested and leak tested before leaving the welding shop
Vacuum pump, jetting system, and piping are installed and aligned to the driveline
Middle tipper system, hydraulic doors, and dumping mechanism are assembled onto the subframe
Cabin and body are mounted, and all electrical and hydraulic systems are connected
Final assembly includes tank coating, cabin interior fit-out, and system integration testing
Truck is tested on the factory apron for vacuum performance, jetting pressure, and dumping function

Testing

Quality Control

Every truck is 100 percent tested before delivery
Vacuum system tested to -0.092 MPa under full load conditions
Jetting hose and connections tested for leaks at 1.5 times working pressure
Hydraulic systems tested for smooth operation and no external leakage
Photos and videos of the finished truck are sent to the buyer before balance payment
In-house testing for pressure vessel projects including non-destructive testing and heat treatment

Build to Order

Customization Options

Tank capacity from 3,000 L to 30,000 L available to match site requirements
Tank material can be changed from Q235 carbon steel to stainless steel on request
Left or right hand drive chassis to match local traffic regulations
Tank colour and logo applied free of charge based on customer design
Cabin configuration adjusted for sleeper, air conditioning, and passenger count
Jetting and vacuum system layout modified to customer’s access and operation preferences

Comparison

How It Compares With the Alternatives

6x4 vacuum truck with 8,000 L tank	Higher capacity and better stability on rough terrain but requires more space to turn in narrow urban streets
Basic suction truck without jetting	Cannot clear blockages on its own but is simpler to maintain and lower in initial cost
Used imported vacuum truck	Lower upfront cost but lacks spare parts availability and technical support after 5 years
