180sqm Transparent Glass LED Screen in Belgium

180sqm · Model MSR-TG-3 · Belgium · Delivered April 2019

Product Model	MSR-TG-3
Screen Size	180sqm
Location	Belgium
Delivered	April 2019
Product Supplied	Transparent Glass LED Screen
Sector	Retail and Shopping Malls

Who It Was For

Client Background

The buyer is not named in our project records. What is documented is the screen itself: a 180sqm transparent glass LED screen supplied on MSR-TG-3 cabinets for a project in Belgium, delivered in April 2019. A transparent glass screen of this size is typically purchased by a retail chain, shopping mall operator, or facade integrator rather than a venue or rental company.

Challenge

The Project Challenge

Install a 180sqm LED screen on a glass facade without blocking the view through the glass, while ensuring the screen remains structurally stable and maintains consistent brightness and colour across the entire surface.

Pain Points

Customer Pain Points

A glass facade project requires transparency so the storefront remains visible during daylight and at night
Rear service access is needed because the screen is mounted against a wall with no rear access
Cabinets must maintain a high transparent ratio to avoid obstructing the view through the glass
The screen must be built to custom sizes to fit the architectural dimensions of the facade
Cabinets must be lightweight enough to meet structural load limits of the building

Solution

Our Solution

The screen was supplied on MSR-TG-3 cabinets with a die-cast aluminium and acrylic cabinet structure, designed for a high transparent ratio and custom size integration. The cabinets feature rear service access, a pixel pitch of 2.5mm, 3.91mm, 7.8mm, or 10.4mm, and are built to be mounted directly onto glass facades without obstructing the view.

How It Was Built

Manufacturing Process

SMT placement and reflow soldering of the LED modules
Soldering inspection and module ageing test before assembly
Cabinet assembly with high transparent ratio design and custom size integration
Screen installation test with cabinets built up as a wall in the factory
Screen ageing test to ensure brightness and colour consistency across cabinets before shipment

Supply Chain

Supply Chain Coordination

Cabinets were packed with spare modules, receiving cards, and power supplies to allow for on-site repairs without waiting for a second shipment.

Testing

Quality Control

Modules passed soldering inspection and an ageing test. Cabinets were built up as a wall in the factory for a screen installation test and a screen ageing test, which ensures brightness and colour match across all cabinets before shipping.

Result

Final Result

Documented delivery: 180sqm of MSR-TG-3 transparent glass LED screen, supplied for a project in Belgium, delivered in April 2019.

Benefit

Customer Benefit

Rear service access allows maintenance without removing the screen from the facade, and the high transparent ratio ensures the glass remains visible during both day and night, preserving the architectural integrity of the storefront.
