Fiber laser welding machine
The handheld fiber laser welding machine replaces traditional argon and electric welding for thin metal sheets. Available with 1000 W, 1500 W, 2000 W or 3000 W laser sources, it welds materials between 0.3 mm and 5 mm thick.
Product Overview
What This Machine Is Built To Do
The handheld fiber laser welding machine replaces traditional argon and electric welding for thin metal sheets. Available with 1000 W, 1500 W, 2000 W or 3000 W laser sources, it welds materials between 0.3 mm and 5 mm thick. The double wobble handheld head expands the tolerance range for fit-up gaps, allowing operators to weld complex shapes without a master welder. With a 10 m fiber cable and water cooling, it handles large workpieces and long-distance welding tasks. The machine operates at 400-500 mm/s welding speed, reducing the need for post-weld grinding and minimizing heat-affected zones on stainless steel, iron, and aluminum.
- Welds 0.3 to 5 mm metal plates with a small heat-affected area to prevent deformation
- Double wobble head expands tolerance range, making fit-up gaps easier to bridge
- Operates 2 to 10 times faster than traditional argon or electric welding methods
- Simple operation allows staff to produce beautiful seams without a master welder certificate
- Smooth welding seams reduce or eliminate the need for subsequent grinding processes
- 10 m fiber cable provides flexibility for welding large or irregular workpieces
Where It Is Used
Application Scenarios
- Fabricating stainless steel door and window guardrails where aesthetics matter
- Assembling kitchen and bathroom cabinets with complex irregular welding paths
- Welding elevator components, shelves, and oven structures
- Repairing or joining copper parts and optoelectronic communication devices
- Joining thin iron or aluminum plates in lighting and molding industries
Buyer Fit
Who It Is For
- Sheet metal fabricators replacing TIG or MIG setups for thin plate work
- Signage and advertising workshops welding stainless steel letters and frames
- Hardware manufacturers needing fast, clean welds on small metal components
- Machine dealers looking for a versatile handheld welding solution for dealers
Process Problems
Problems It Solves
- Traditional welding causes deformation, blackening, and back-side traces on thin sheets
- Argon and electric welding require skilled master welders to achieve clean seams
- Post-weld grinding consumes significant time and labor costs on every part
- Fixed optical path machines cannot reach long-distance or large workpieces easily
- Small laser spots in standard welding require precise fit-up which slows production
Engineering
Technical Features
- Double wobble handheld laser head for wider weld width and better shape
- Continuous wave laser source with 1064-1090 nm wavelength
- Water cooling chiller integrated into the system for stable operation
- Auto feeder included for consistent wire supply during welding
- Red light positioning system for accurate weld placement
- Adjustable laser spot size from 0.2 mm to 5 mm
Specifications
Published Figures For Fiber laser welding machine
Every value below is taken from the machine data sheet. Where a range is given the exact figure depends on the model and power you order.
| Laser Power | 2000 W (1000 W/1500 W/3000 W available) |
|---|---|
| Laser Wavelength | 1064-1090 nm |
| Fiber Cable Length | 10 m |
| Work Mode | Continuous |
| Welding Speed | 400-500 mm/s |
| Cooling Method | Water cooling chiller |
| Welding Thickness | 0.3-5 mm |
| Welding Beam Width | <=1.5 mm |
| Laser Source Service Time | 100,000 hours |
| Work Voltage | 380 V |
| Rated Power | 10 kW (chiller included) |
| Laser Spot Size | 0.2-5 mm |
| Laser Head | Double wobble |
| Auto Feeder | Yes |
| Positioning | Red light position |
Materials
Materials It Handles
- Stainless steel plate
- Iron plate
- Aluminum plate
- Copper parts
- Other metal materials
Working Process
From File To Finished Part
Connect the fiber laser source to the handheld welding gun and chiller
Set the laser power and spot size according to material thickness
Load welding wire into the auto feeder if required
Use the red light position to guide the weld seam on the workpiece
Move the handheld gun along the joint at 400-500 mm/s speed
Inspect the smooth welding seam and clean the work area
Quality Control
Quality Control Before Shipment
- Laser source tested for continuous operation and 100,000 hour service life
- Welding beam width checked to ensure it remains <=1.5 mm
- Spot size verified across the 0.2-5 mm adjustable range
- Chiller and water cooling system tested for stable temperature control
Options
Customisation Options
- Select laser power from 1000 W, 1500 W, 2000 W or 3000 W options
- Configure voltage for your local industrial standard
- English user manuals and video guidance provided for operation
Comparison
How It Compares With The Alternatives
| Traditional Argon Welding | Fiber laser welding is 2-10 times faster and produces less deformation on thin sheets |
|---|---|
| Electric Welding | Laser welding requires no master welder certificate and eliminates post-weld grinding |
| Fixed Optical Path Laser Welder | Handheld model with 10 m cable allows flexible welding of large and irregular workpieces |
Operating Notes
Use Guide
- Ensure the water chiller is filled and running before starting the laser
- Adjust the laser spot size to match the joint gap for better tolerance
- Maintain a consistent welding speed of 400-500 mm/s for uniform seams
- Clean the lens and nozzle regularly to prevent power loss from spatter
- Use the red light position to visualize the weld path before triggering
Buyer Questions
Fiber laser welding machine FAQ
What is the maximum welding thickness?
The machine is rated for welding materials between 0.3 mm and 5 mm thick.
Do I need a skilled welder to operate it?
No, the operation is simple and allows you to weld beautiful products without a master welder certificate.
How long is the fiber cable?
The fiber cable length is 10 meters, providing flexibility for moving around the workpiece.
What laser power options are available?
The standard model is 2000 W, but 1000 W, 1500 W and 3000 W options are also available.
Does it require grinding after welding?
The welding seam is smooth and beautiful, which reduces the subsequent grinding process significantly.
What is the service life of the laser source?
The fiber laser source has a service time of 100,000 hours.
