HMI Touchscreen Operator Station
Touchscreen operator station for cold storage rooms. Real-time temperature, humidity, alarm log, defrost timer override, multi-language interface.
- 7" – 15" Colour HMI
What The HMI Touchscreen Operator Station Does
Howcool's HMI (Human-Machine Interface) operator station provides a clear, full-colour touchscreen for cold-room operators to monitor temperature, humidity, alarms, and equipment status — without entering the plant room. Built on Weintek, Schneider Magelis, or Siemens KTP series touchscreens; pre-configured with Howcool's standard screen set in 8 languages (English, Chinese, Russian, Arabic, Spanish, French, Portuguese, Indonesian).
Real-time display shows current room temperature for up to 16 zones, set-point, deviation alarms, compressor status (run/stop/fault), defrost timer countdown, and equipment operating hours. Operators can change set-points (password-protected), reset alarms, force a manual defrost, or download a 30-day data log to USB. Connects to the main PLC cabinet via Ethernet or RS-485.
HMI touchscreen operator station — 7-15 inch colour displays from Weintek, Schneider Magelis, or Siemens KTP. Multi-language (EN/ZH/RU/AR/ES/FR/PT/ID), 16-zone display, 30-day data log to USB. HACCP-ready audit trail.
Why Buyers Choose This Model
Multi-Language Touchscreen
Pre-configured in 8 languages: EN, ZH, RU, AR, ES, FR, PT, ID. Operator selects language at login. RTL (right-to-left) layout for Arabic.
16-Zone Real-Time Display
Display 16 cold-room zones on one screen. Temperature, humidity, compressor status, defrost status, alarms — all visible at a glance.
30-Day Data Log to USB
Continuous data logging at 1-minute intervals. Export full 30-day log to USB stick for HACCP / GDP audit purposes.
Password-Protected Operations
Three access levels: Operator (view + reset alarms), Supervisor (change set-points), Engineer (full configuration). Audit trail of every change.
Electrical Control System Failure Modes
Excursions found too late
Remote monitoring with SMS and email alarms raises the alert when the temperature moves, not at shift change.
Manual operation errors
Integrated PLC cabinets sequence compressors, defrost and fans automatically, with N+1 standby logic.
Audit evidence
HMI touchscreen operation with logged temperature and humidity history; on our Wuhan project, 400+ sensors are logged through the building control system.
Technical Data
Values below are the manufacturer's standard range. Anything not listed is confirmed against your heat load calculation before order.
| Display Size | 7" / 10" / 12" / 15" colour touchscreen |
|---|---|
| Brand | Weintek / Schneider Magelis / Siemens KTP |
| Resolution | 800×480 (7") up to 1024×768 (15") |
| Languages | EN / ZH / RU / AR / ES / FR / PT / ID |
| Zones Displayed | Up to 16 cold-room zones |
| Data Log | 30-day, 1-minute intervals, USB export |
| Communication | Ethernet / RS-485 to main PLC |
| Power Supply | 24V DC (powered from PLC cabinet) |
|---|---|
| Mounting | Panel-mount, wall-mount or pedestal |
| IP Rating | IP65 (front face) / IP20 (rear) |
| Production Lead Time | 20-30 days after deposit |
| Warranty | 2 years on touchscreen unit |
| Certification | ISO 9001, CE |
| Origin | Beijing, China |
HMI Touchscreen Operator Station In Production And On Site
Sectors Using This Equipment
Cold Chain Logistics
A distribution cold store is judged on pallet movements, not on storage volume. Dock design, door speed and racking layout decide...
Pharmaceutical and Biotech
In pharmaceutical storage the temperature record is part of the product. A chamber that held its set point but cannot prove it...
Industrial and Special
Some cold rooms are not about food at all. Lithium battery storage, nuclear plant supplies, laboratory reagents and industrial...
HMI Touchscreen Operator Station Questions
What capacity range does the HMI Touchscreen Operator Station cover?
The standard range is 7" – 15" Colour HMI. All models are customised to the calculated heat load of your room or line, so send volume, temperature and product type for exact selection.
What is the production lead time?
20-30 days after deposit. Equipment is packed in export wooden cases.
What warranty applies?
2 years on touchscreen unit, backed by 24/7 remote support. On-site service is available for export projects.
Is the equipment certified?
ISO 9001, CE. Howcool's quality management system is certified to ISO 9001:2015 by CFL Certification Center.
