Remote Monitoring & SMS / Email Alarm System
Cloud-based remote monitoring with SMS + email alarms. Watch your cold storage from anywhere — see all temperatures, get alarms, audit data.
- 24/7 Cloud Monitoring
What The Remote Monitoring & SMS / Email Alarm System Does
Howcool's remote monitoring system extends the PLC and HMI with cloud-based 24/7 monitoring. A gateway connects to the on-site PLC via Ethernet or 4G LTE and pushes real-time data to our secure cloud platform. Owners, managers, and Howcool's after-sales team can view all temperatures, compressor status, and alarms from any web browser or mobile app — no special software installation required.
Alarm escalation is fully configurable: temperature excursions trigger an SMS within 30 seconds to up to 5 recipients in priority order, with email backup. If the first recipient doesn't acknowledge within a configurable time (e.g. 5 minutes), the alarm escalates to the next recipient. Howcool's after-sales team can be added as a watchdog — we'll call you if you miss an alarm. HACCP and GDP-compliant data retention for 5 years.
Cloud-based remote monitoring system with SMS + email alarm escalation. 24/7 watchdog service from Howcool's after-sales team. HACCP and GDP-compliant 5-year data retention. Works from any web browser or mobile app.
Why Buyers Choose This Model
Cloud Dashboard from Anywhere
View all temperatures, compressor status, alarms from any browser or mobile app. No special software installation required.
30-Second SMS Alarm
Temperature excursions, power failures, equipment faults — SMS within 30 seconds to up to 5 recipients in priority order with escalation.
Howcool 24/7 Watchdog
Add Howcool's after-sales team as a watchdog recipient. If you miss an alarm, we call you. Available worldwide.
HACCP / GDP Data Retention
5-year temperature data retention with tamper-evident audit trail. Pre-formatted reports for HACCP, GDP, FDA, and CFDA audits.
Electrical Control System Failure Modes
Excursions found too late
Remote monitoring with SMS and email alarms raises the alert when the temperature moves, not at shift change.
Manual operation errors
Integrated PLC cabinets sequence compressors, defrost and fans automatically, with N+1 standby logic.
Audit evidence
HMI touchscreen operation with logged temperature and humidity history; on our Wuhan project, 400+ sensors are logged through the building control system.
Technical Data
Values below are the manufacturer's standard range. Anything not listed is confirmed against your heat load calculation before order.
| Connectivity | Ethernet (LAN) + 4G LTE (cellular backup) |
|---|---|
| Data Sample Rate | 1 minute (configurable to 10 seconds) |
| Alarm Response | SMS within 30 seconds, email backup |
| Alarm Recipients | Up to 5, with escalation logic |
| Watchdog Service | Optional — Howcool 24/7 monitoring team |
| Data Retention | 5 years, tamper-evident audit trail |
| Mobile App | iOS + Android (free) |
| Web Dashboard | Any modern browser, no plug-in required |
|---|---|
| Compliance Reports | HACCP / GDP / FDA / CFDA pre-formatted |
| Multi-Site View | Manage multiple cold storage sites from one dashboard |
| Production Lead Time | 15-25 days after deposit |
| Service Fee | USD 30-50/month per site (optional) |
| Warranty | 2 years on gateway hardware |
| Origin | Beijing, China |
Remote Monitoring & SMS / Email Alarm System In Production And On Site
Sectors Using This Equipment
Cold Chain Logistics
A distribution cold store is judged on pallet movements, not on storage volume. Dock design, door speed and racking layout decide...
Pharmaceutical and Biotech
In pharmaceutical storage the temperature record is part of the product. A chamber that held its set point but cannot prove it...
Industrial and Special
Some cold rooms are not about food at all. Lithium battery storage, nuclear plant supplies, laboratory reagents and industrial...
Remote Monitoring & SMS / Email Alarm System Questions
What capacity range does the Remote Monitoring & SMS / Email Alarm System cover?
The standard range is 24/7 Cloud Monitoring. All models are customised to the calculated heat load of your room or line, so send volume, temperature and product type for exact selection.
What is the production lead time?
15-25 days after deposit. Equipment is packed in export wooden cases.
What warranty applies?
2 years on gateway hardware, backed by 24/7 remote support. On-site service is available for export projects.
Can this be supplied without an installation contract?
Yes. Equipment can be supplied on its own FOB or CIF, or as part of a turn-key EPC cold storage project where Howcool also handles design, installation and commissioning.
Often Specified Together
Integrated PLC Control Cabinet
Main PLC control cabinet for cold storage installations. Siemens S7-200 SMART PLC, Schneider Electric contactors, CHINT breakers — integrated and factory-tested.
HMI Touchscreen Operator Station
Touchscreen operator station for cold storage rooms. Real-time temperature, humidity, alarm log, defrost timer override, multi-language interface.
High-Speed Roll-Up Door
Engineered to withstand extreme cold. Saves up to 30% in energy costs.
Scroll Outdoor Condensing Unit
Outdoor weather-proof condensing unit with Copeland scroll compressors. Plug-and-play installation for small-to-medium cold rooms.
Facilities Built With This Equipment Family
50,000m³ Cold-Chain Logistics — Wuhan Xinpu Fruit
Two-stage 50,000 m³ cold-chain logistics centre for Wuhan Xinpu Fruit — fruit & meat distribution hub.
Cold-Chain Logistics — Seafood 20,000t
20,000-ton seafood refrigeration project. PIR, Freon, PLC control, electric cold storage doors.
Biomedical Cold Storage — Beijing Yizhuang Biotech Park
GMP-compliant pharmaceutical warehouse. 2-8℃ temperature, 45-75% humidity, redundant refrigeration, 24/7 monitoring.
Request A Quotation For The Remote Monitoring & SMS / Email Alarm System
Tell us the room volume, target temperature and product type and we will confirm the model, capacity and delivered price.
