Embossed Aluminium Floor Panels
Walkable cold-storage floor panels with embossed aluminium tread surface. Forklift-rated insulation for cold room floors.
- Walkable Cold Floor · 100-200mm
What The Embossed Aluminium Floor Panels Does
Insulated cold storage floor panels with embossed aluminium tread surface (top) and pre-painted steel (bottom). Designed to bear forklift traffic, pallet jacks, and worker foot-traffic on the cold side of the cold room. Eliminates the need for poured concrete floor with separate insulation — saving construction time and depth.
Howcool's floor panels use high-density (45-50 kg/m³) PU core with 1.5-2.0 mm checker-plate aluminium top facing. Standard thicknesses 100, 120, 150, 200 mm. Forklift load rating 2000 kg point load with 200 mm thickness. Cam-lock joints allow rapid assembly and replacement of damaged panels without affecting adjacent panels.
Insulated walkable cold storage floor panels with embossed aluminium tread surface. Forklift-rated 2000 kg point load. Replaces poured concrete + insulation — faster construction, lower floor build-up.
Why Buyers Choose This Model
Forklift-Rated
1.5-2.0 mm checker-plate aluminium tread surface. 2000 kg point load capacity (200 mm panel). Replaces concrete + insulation.
Faster Construction
No concrete pour, no separate vapour barrier, no separate insulation layer. Install in 2-3 days vs 7-10 for concrete.
Replaceable Sections
Damaged panels can be replaced individually without disturbing adjacent floor. Critical for 24/7 operations.
Anti-Slip Tread
Diamond or checker-plate embossing provides positive grip even with frost or water on the surface. Worker safety priority.
Cold Room Panels Failure Modes
Heat ingress that never stops
Polyurethane panels with low thermal conductivity in thicknesses from 50 to 200 mm; on our Jeddah design, 150 mm cut summer heat ingress by over 40% against 100 mm.
Fire compliance
PIR fire-rated and rockwool fire-wall panels for sites where the insulation core has to meet building fire codes.
Frost heave under the slab
Embossed aluminium floor panels and insulated floor build-ups with anti-frost-heave heating for freezer rooms.
Technical Data
Values below are the manufacturer's standard range. Anything not listed is confirmed against your heat load calculation before order.
| Core Material | High-density PU, 45-50 kg/m³ |
|---|---|
| Top Facing | 1.5-2.0 mm embossed aluminium (checker / diamond) |
| Bottom Facing | 0.5 mm pre-painted galvanised steel |
| Thickness | 100 / 120 / 150 / 200 mm |
| Forklift Rating | 2000 kg point load (200 mm panel) |
| Joint | Cam-lock with stainless-steel cam |
| Panel Width | 1000 / 1150 / 1200 mm |
| Max Length | 6 m (forklift-rated) |
|---|---|
| Anti-Slip | Checker-plate or diamond tread |
| Production Lead Time | 25-35 days after deposit |
| Warranty | 10 years on panel integrity |
| Certification | ISO 9001, CE |
| Origin | Beijing, China |
Embossed Aluminium Floor Panels In Production And On Site
Sectors Using This Equipment
Food Processing
Processing lines do not wait. When freezing capacity falls behind the kill floor or the packing line, product queues at ambient...
Fruit and Vegetable
Fruit keeps respiring after harvest. Temperature slows it down; controlled atmosphere nearly stops it. The difference between the...
Pharmaceutical and Biotech
In pharmaceutical storage the temperature record is part of the product. A chamber that held its set point but cannot prove it...
Embossed Aluminium Floor Panels Questions
What capacity range does the Embossed Aluminium Floor Panels cover?
The standard range is Walkable Cold Floor · 100-200mm. All models are customised to the calculated heat load of your room or line, so send volume, temperature and product type for exact selection.
What is the production lead time?
25-35 days after deposit. Equipment is packed in export wooden cases.
What warranty applies?
10 years on panel integrity, backed by 24/7 remote support. On-site service is available for export projects.
Is the equipment certified?
ISO 9001, CE. Howcool's quality management system is certified to ISO 9001:2015 by CFL Certification Center.
