Tank Trailers
3 Axle 40000L 45000L 50000L Diesel Oil Fuel Tank Semi Trailer
It features three FUWA axles with 13-ton capacity each, mechanical suspension with 10/10/10 steel springs, and a 12.00R22.5 triangle vacuum tyre configuration. The trailer is designed for oil and fuel transport with two 3-inch discharge holes and a 50# king pin, and is certified under CCC standards.
- Use TruckTrailer
- Size 11200x2480x3360mm
- Color ascustomer'srequiremen
- Suspension Mechanical
- Material Steel
Stock number held for this listing: 10612
Key Benefits
What This Unit Does Well
- Q345B steel tank body with 5mm thickness ensures durability in high-pressure fuel environments
- Three FUWA axles at 13-ton capacity each distribute load evenly across long hauls
- Mechanical suspension with shock absorbers reduces wear on road surfaces and improves stability
- 12.00R22.5 triangle vacuum tyres offer high load capacity and long tread life on rough terrain
- CCC certification supports customs clearance in markets requiring Chinese product compliance
Application Scenarios
Where It Is Used
- Fuel transport between a central depot and remote construction sites with unpaved access roads
- Oil supply chain support for mining or quarry operations where refuelling points are spaced over 200km
- Long-haul fuel delivery in Central Asia or Africa where tankers must carry full loads over extended distances
- Supporting fleet operations for oil and gas contractors needing consistent, high-capacity transport
Fit
Who It Is For
- Fleet owners managing fuel delivery routes with limited access to refuelling infrastructure
- Contractors requiring large-capacity tankers for oil and fuel supply on remote engineering projects
- Machinery dealers stocking semi-trailers for resale in markets with high demand for fuel transport
- Government procurement teams sourcing bulk fuel transport units for logistics or military use
Buyer Pain
Problems It Solves
- Inconsistent tank capacity across suppliers leads to underutilised or overloaded trailers
- Lack of local spare parts for axles and suspension systems causes downtime during long hauls
- Trailer instability on rough roads due to weak suspension or mismatched tyre ratings
- Uncertainty over certification status when importing into markets with strict compliance rules
- Inflexible design prevents adaptation to site-specific loading or discharge requirements
Engineering
Technical Features
- 3-axle semi-trailer with FUWA axles rated at 13 tonnes each
- Mechanical suspension with 10/10/10 steel springs and shock absorbers
- Tank body made of Q345B steel with 5mm thickness and end plates at 6mm
- Discharge system with two 3-inch outlets for rapid fuel transfer
- 50# king pin for secure coupling to tractor heads
- 12.00R22.5 triangle vacuum tyres on 9.00-22.5 Zhengxing rims, 12 tyres total
- Landing gear rated at 28 tonnes, JOST D200 model
- Two tyre carriers and one tool box standard
- CCC certification issued for product compliance
Specification
Specification Table for This Listing
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Use | TruckTrailer |
|---|---|
| Size | 11200x2480x3360mm |
| Color | ascustomer'srequirement |
| Suspension | Mechanical |
| Material | Steel |
| Certification | ccc |
| Axle | FUWAcapacity:13t |
| Type | Semi-Trailer |
| Model | FW5010holes.withshockabsorber |
| Trailer Model | FW5010 holes with shock absorber |
| Outside Size L x W x H | 11200 x 2480 x 3360 mm |
| Body Thickness | 5 mm |
| End Plate Thickness | 6 mm |
| Tyre Specification | 12.00R22.5 (triangle vacuum) |
| Rim Size | 9.00-22.5 Zhengxing |
| Number of Tyres | 12 |
| Wheelbase | 5330+1310+1310 mm |
| Steel Spring Number | 10/10/10 |
| King Pin | 50# |
| Discharge Hole | 2 pieces x 3 inch |
| Landing Gear | 28T JOST D200 |
| Tire Carrier | Two pieces |
| Tool Box | One |
| Max Payload | 45 T |
| Body Weight | 10.8 T |
| Chamber Type | Four double and two single chambers |
Materials
Materials and Build
- Q345B steel for tank body and shifting boards
- 6mm Q345B steel for end plates
- Mechanical suspension with steel springs and shock absorbers
- 12.00R22.5 triangle vacuum tyres on 9.00-22.5 Zhengxing rims
- 50# steel king pin with welded mounting
- Steel frame and chassis with welded joints
Process
How an Order Is Handled
- You send your required tank capacity, discharge hole configuration, and axle preference
- We confirm the model FW5010 with shock absorber and available stock or production lead time
- You confirm the final spec sheet including colour, tyre brand, and discharge hole size before deposit
- Unit is prepared, photographed, and video recorded before loading
- We book RoRo or container shipment and issue export documents including commercial invoice and certificate of origin
Quality Control
Checks Before Loading
- Chassis and axle numbers are photographed and matched to the approved specification sheet
- Suspension and tyre fitment are checked for correct alignment and torque before loading
- Tank welds and seal heads are inspected for leaks using pressure test before shipment
- Loading and lashing photos are sent before the vessel departs
Customisation
What Can Be Changed
- Discharge hole size and number changed to match your pump or pipeline setup
- Tyre brand other than triangle vacuum, if available
- Colour selected from customer's requirement, including custom paint finish
- Additional tool box or tyre carrier added upon request
- King pin size or landing gear upgraded if required for your tractor head
Honest Comparison
How It Compares With the Alternatives
| 2-axle semi-trailer | The 3-axle unit supports higher payload and better weight distribution on long hauls, but costs more in fuel and maintenance |
|---|---|
| Aluminium tank trailer | Steel construction is cheaper and more impact-resistant, but heavier than aluminium for the same capacity |
| Hydraulic suspension trailer | Mechanical suspension is simpler to maintain and more reliable in remote areas, but offers less ride comfort on rough roads |
Use Guide
Using It Well
- Inspect all welds and seal heads before first fill to prevent leaks
- Check tyre pressure weekly and adjust for high-load conditions
- Use only compatible fuel types to avoid internal corrosion in the Q345B tank
- Clean discharge holes and valves after each use to prevent clogging
- Store trailer on level ground with landing gear fully supported to avoid frame stress
Photographs
More Views of This Unit
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
Source Specification
Manufacturer Text We Hold for This Listing
3 Axle 40000L 45000L 50000L Diesel Oil Fuel Tank Semi Trailer Quick Details Use: Truck Trailer, Other Trailers Type: Semi-Trailer Material: Steel Certification: Other Place of Origin: Shandong, China (Mainland) Brand Name: huayuda Model Number: huayuda005 RED: optional upon choice Max Payload: 45T out size:11200x2480x3360mm Packaging Details: nude packing or accordding to customer requirment Delivery Detail: within 13 workdays after receive 30%contract payment Specifications 1.out zise:11200x2480x3360mm 2.tank body: 1)material:Q345B thickness:5mmm 2)end plate thickness:6mm 3)shifting board thickness:5mm Q345B 4.we can produce product accordding to you requirement Trailer name oil tanker semi trailer Delivery time 13 workdays after received your payment in advance Rated loading capacity(T) 45 Body total weight (T) 10.8 Outside size(L*W*H) 11200x2480x3360mm Body thickness 5mm Tanker capaci
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
Related Listings
Other Tank Trailers Buyers Compare With This
Tank Trailers
40000L Oil/Fuel Tanker Transportation Tank Semi Trailer/Truck Trailer
- UseOtherTrailers
- Size13000mm*2500mm*3980mm
- SuspensionMechanicalsuspension
Tank Trailers
Hot Sale 50cbm Dry Bulker Semi Trailer/Bulk Cement Semi Trailer
- UseTruckTrailer
- Size13000*2500*4000mm
- SuspensionMechanicalSuspension
Tank Trailers
China 3 Axle Bulk Cement Steel Material Semi Trailer with Lowest Price
- UseTruckTrailer
- Size13000*2500*4000mm
- SuspensionMechanicalSuspension
Tank Trailers
3 Axle 45cbm Dry Silo Cement Bulker Tank Trailer Truck Semi Trailer Use for Ca
- UseTruckTrailer
- Size13000*2500*3990mm
- ColorOptional
Tank Trailers
3 Axle 40cbm Petrol Tanker Semi Trailer
- UseTruckTrailer
- Size11700*2500*3600mm
- ColorOptinal
Buyer Questions
Questions About This Unit
Is this trailer new or used
All units are new. We source from the manufacturer and confirm the production date and chassis number before shipment.
What is the lead time
13 workdays after receiving 30% advance payment. We confirm the exact delivery date in writing with the proforma invoice.
Can you supply spare parts later
Yes. We can supply replacement tyres, axle components, king pin parts, and discharge valves as needed after delivery.
Do you ship by container or RoRo
RoRo is standard. Container shipment is possible but requires lowering the cab and may affect loading stability; we quote both options.
What documents do I get for customs
Commercial invoice, packing list, bill of lading, certificate of origin, and CCC certificate are included. Additional inspection certificates can be arranged.
