Tank Trailers

Hot Sale Chinese Factory Bulk Cement Steel Material Semi Trailer with V Type

A 11800 x 2500 x 4000mm V-type bulk cement semi-trailer with a 25m3 to 115m3 volume, constructed with Q235A/Q345 steel between 3.5mm and 5mm thick. It features a mechanical suspension, three axles, and optional 12R22.5 tyres. Designed for the transport of bulk cement powder, this trailer addresses the need for efficient and reliable material handling in bulk transport applications.

Use TruckTrailer
Size 11800*2500*4000mm
Color Optional
Suspension MechanicalSuspension
Material Steel

Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 10586

Side view of a white V-type bulk cement semi-trailer

Key Benefits

What This Unit Does Well

Q235A/Q345 steel tank body offers a balance of strength and weight for cement transport
Optional FUWA, BPW or HJ axles provide flexibility to match fleet standards or budget
Mechanical suspension is simpler to maintain and cheaper to replace than air ride
V-type tank design promotes consistent material flow during discharge
25m3 to 115m3 volume range caters to different payload requirements
ISO9001:2008 and CCC certification demonstrate adherence to quality standards

Application Scenarios

Where It Is Used

Transporting cement from a silo to a construction site
Moving fly ash from a power plant to a concrete mixing facility
Hauling lime or other dry bulk powders for industrial applications
Long-distance transport of cement between regional distribution centres
Supplying cement to remote construction projects with limited infrastructure

Fit

Who It Is For

Construction companies needing to transport cement to job sites
Cement plants and distributors requiring a fleet of bulk transport trailers
Agricultural businesses transporting lime or other powdered materials
Logistics companies specialising in bulk material handling
Quarry operators moving dry aggregates and powders

Buyer Pain

Problems It Solves

Inefficient loading and unloading of cement from bags or smaller containers
Damage to cement during transport due to improper containment
High maintenance costs associated with complex suspension systems
Difficulty in finding trailers with the right volume for specific payloads
Concerns about the structural integrity of trailers used for abrasive materials

Engineering

Technical Features

V-type tank design for efficient material flow
Q235A/Q345 steel tank body construction
Mechanical suspension system with leaf springs
FUWA, BPW or HJ axle options
2" or 3.5" JOST king pin
JOST two-speed landing gear

Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

Specification of Hot Sale Chinese Factory Bulk Cement Steel Material Semi Trailer with V Type
Use	TruckTrailer
Size	1180025004000mm
Color	Optional
Suspension	MechanicalSuspension
Material	Steel
Axle	3
Tire	12R22.5optional
Function	TransportBulkCementPowder
Type	Semi-Trailer
Packing	nakedpacking
Certificate	ISO9001:2008,CCC
Trailer Type	Semi-Trailer
Tare Weight	11000KG
Volume	25m3-115m3
Tank Body Material	Q235A/Q345
Tank Body Thickness	3.5mm-5mm
King Pin	2′′(50mm)or3.5′′(90mm) JOST
Landing Gear	JOST Brand Two-speed
Max Payload	60T
Place of Origin	Shandong, China (Mainland)
Brand Name	HYD
CCC Landing Gear	JOST Brand Two-speed
JOST Suspension	Mechanical Suspension

Materials

Materials and Build

Q235A/Q345 steel for the tank body, providing strength and durability
Steel chassis and frame constructed for heavy-duty use
Optional FUWA, BPW or HJ axles made from alloy steel
12R22.5 radial tyres for load capacity and road handling
JOST king pin and landing gear for secure coupling and stability

Process

How an Order Is Handled

You specify the required volume, axle configuration and tyre brand
We confirm availability and pricing based on your specifications
You provide a purchase order and 30% deposit
The trailer is assembled and inspected before shipment
We arrange transport by bulk carrier, RoRo or container

Quality Control

Checks Before Loading

Steel plate thickness is verified before cutting and welding
Welds are inspected for porosity and structural integrity
Axle alignment and tyre pressure are checked before delivery
King pin and landing gear operation are tested
A pre-shipment inspection report with photos is provided

Customisation

What Can Be Changed

Tank volume can be adjusted between 25m3 and 115m3
Axle brand and number can be specified
Tyre brand and size can be selected
Painting colour can be customized
Additional accessories such as toolboxes can be added

Honest Comparison

How It Compares With the Alternatives

Air suspension trailer	Mechanical suspension is cheaper and simpler to maintain, but provides a harsher ride
Smaller volume trailer	Larger volume reduces the number of trips required for a given quantity of cement
Aluminium tank trailer	Steel tanks are heavier but more cost-effective for abrasive materials like cement

Use Guide

Using It Well

Grease wheel bearings and landing gear regularly
Inspect tyre pressure before each trip
Check the air compressor and discharge valve for proper operation
Avoid overloading the trailer beyond its maximum payload capacity
Periodically inspect the tank for signs of corrosion or damage

Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Close-up of the V-shaped tank of the cement trailer

Rear view of the cement trailer showing the discharge valve

Landing gear and kingpin of the cement trailer

Front view of the cement trailer with the towing hitch

Side view of the cement trailer showing the tyre and wheel

Source Specification

Manufacturer Text We Hold for This Listing

Hot sale Chinese factory bulk cement steel material semi trailer with V type Product Description BULK CEMENT SEMI TRAILER Tare weight 11000KG Size According to your request Color Customized Volume 25m3-115m3 Tank body Q235A/Q345 3.5mm-5mm steel sheet V type End plate Q235A/Q345 6mm ball shape Axle 2/3/4 axle FUWA/BPW /HJ brand optional 13T-16T Tire 11.00R20/12.00R20/11R22.5/12R22.5 Tire optional Wheel rim 8.5-20/9.0-20/8.25-22.5/9.0-22.5/9.75 optional Wheelbase 6380+1310+1310 Suspension Mechanical suspension Leaf spring 10pcs ABS 4S/2M KEMI Brand Manhole cover 500mm manhole cover 2 sets Discharge valve 4'' discharge value Discharge pipe 4'' seamless steel tube Air compressor 37KW, 0.2Mpa, 1000r/Min Engine Diesel engine WEICHAI brand 4102 Diesel engine Kingpin JOST 2"/3.5" bolt-in king pin Landing gear JOST two speed landing gear 28T Compartment 1/2/3 Air-charging system 2'' main hole, 2'

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
