Tank Trailers

3 Axle 50T Bulk Cement Tank Semi Trailer-V Shape

A three-axle, 50-tonne capacity bulk cement tank semi-trailer with a V-shaped tank body designed for transporting dry bulk materials like cement, flour, and ore powder. Dimensions are 11800mm long, 2500mm wide, and 4000mm high. It features mechanical suspension and is constructed from steel, with options for tyre size and colour.

Use TruckTrailer
Size 11800*2500*4000mm
Color Optional
Suspension MechanicalSuspension
Material Steel

Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 10585

White three-axle bulk cement tank semi-trailer parked in a yard

Key Benefits

What This Unit Does Well

3-axle design distributes load for compliance with regional weight restrictions
V-shaped tank promotes material discharge and reduces bridging
Optional 12R22.5 tyres provide flexibility for different road conditions
ISO9001:2008 and CCC certifications demonstrate adherence to quality standards
Customizable colour allows for fleet branding and identification
Naked packing reduces shipping costs where permitted by local regulations

Application Scenarios

Where It Is Used

Transporting cement from a silo to a construction site
Hauling fly ash for use in concrete production
Delivering wheat or flour to a food processing plant
Moving lime for soil stabilisation projects
Transporting ore powder from a mine to a processing facility

Fit

Who It Is For

Construction companies needing to move large volumes of cement
Agricultural businesses transporting grain and flour
Mining operations requiring bulk powder transport
Logistics companies specialising in dry bulk material delivery
Cement plants and quarries needing to ship their products

Buyer Pain

Problems It Solves

Inefficient loading and unloading of dry bulk materials
Material bridging and compaction inside the tank
Damage to materials during transport due to inadequate tank design
Difficulty complying with weight restrictions on certain routes
Lack of a reliable and durable trailer for demanding applications

Engineering

Technical Features

Q235A/Q345 steel tank body with 3.5mm-5mm wall thickness
Mechanical suspension with 10 leaf springs
FUWA/BPW/HJ axle options with 13T-16T capacity
JOST 2"/3.5" bolt-in king pin
JOST two-speed landing gear
4'' discharge valve and 4'' seamless steel tube
37KW air compressor with 0.2Mpa pressure

Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

Specification of 3 Axle 50T Bulk Cement Tank Semi Trailer-V Shape
Use	TruckTrailer
Size	1180025004000mm
Color	Optional
Suspension	MechanicalSuspension
Material	Steel
Axle	3
Tire	12R22.5optional
Function	TransportBulkCementPowder
Type	Semi-Trailer
Packing	nakedpacking
Certificate	ISO9001:2008,CCC
Trailer Type	Semi-Trailer
Max Payload	50T
Dimensions L x W x H	1180025004000mm
Tare Weight	11000KG
King Pin	2′′(50mm)or3.5′′(90mm) JOST
Landing Gear	JOST Brand Two-speed
Place of Origin	Shandong, China (Mainland)
Brand Name	HYD
CCC Landing Gear	JOST Brand Two-speed
JOST Suspension	Mechanical Suspension

Materials

Materials and Build

Q235A/Q345 steel for tank body and end plates
Steel chassis with welded construction
FUWA/BPW/HJ axles
12R22.5 radial tyres (optional)
Seamless steel tube for discharge pipe

Process

How an Order Is Handled

You specify the material to be transported and any specific requirements
We confirm the tank volume and trailer dimensions based on your needs
You approve the final specification sheet including colour and axle brand
The trailer is prepared, sandblasted, painted and inspected
We arrange RoRo or container shipment and provide export documents

Quality Control

Checks Before Loading

Chassis and tank are inspected for weld quality and structural integrity
Axle alignment and brake function are tested before shipment
Paint finish is checked for defects and adhesion
Loading is supervised to ensure secure lashing and prevent damage

Customisation

What Can Be Changed

Tank volume can be adjusted to suit specific payload requirements
Colour can be customized for fleet branding
Axle brand can be selected based on preference and availability
Tyre size and brand can be specified
Additional accessories such as ladders or toolboxes can be added

Honest Comparison

How It Compares With the Alternatives

Rigid bulk cement truck	A semi-trailer offers greater flexibility as it can be coupled to different tractors
Smaller capacity tank trailer	A 50T trailer reduces the number of trips needed for large volume transport
Air suspension tank trailer	Mechanical suspension is more robust and requires less maintenance in rough conditions

Use Guide

Using It Well

Regularly inspect the discharge valve for blockages
Check tyre pressure before each journey
Lubricate the axle bearings and suspension components according to the maintenance schedule
Ensure the load is evenly distributed within the tank
Inspect the chassis for cracks or damage

Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Side view of the cement tank trailer showing the V-shaped tank

Rear view of the trailer with discharge valve and mud flaps

Close-up of the trailer's axles and suspension system

Front view of the trailer with the king pin and landing gear

The trailer's discharge valve and pipe system

The trailer's chassis and frame construction

The trailer's air compressor and other components

Source Specification

Manufacturer Text We Hold for This Listing

3 Axle 50T Bulk Cement Tank Semi Trailer-V shape Powder material semi trailer is used for carrying different bulk items like flour, cement, fly ash, wheat, lime, ore powder and other particles. We can make different cement tank semi trailer according to your special requirements, and we can provide you with technical drawings. Product Description BULK CEMENT SEMI TRAILER Tare weight 11000KG Size According to your request Color Customized Volume 25m3-115m3 Tank body Q235A/Q345 3.5mm-5mm steel sheet V type End plate Q235A/Q345 6mm ball shape Axle 2/3/4 axle FUWA/BPW /HJ brand optional 13T-16T Tire 11.00R20/12.00R20/11R22.5/12R22.5 Tire optional Wheel rim 8.5-20/9.0-20/8.25-22.5/9.0-22.5/9.75 optional Wheelbase 6380+1310+1310 Suspension Mechanical suspension Leaf spring 10pcs ABS 4S/2M KEMI Brand Manhole cover 500mm manhole cover 2 sets Discharge valve 4'' discharge value Discharge pipe 4''

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
