Reliable Alumina Crucibles for Muffle Furnace Thermal Experiments
Square alumina crucibles for muffle furnace are specialized containers made from high-purity alumina (Al₂O₃), designed to withstand extreme temperatures and harsh conditions inside muffle furnaces. These crucibles feature a square shape, making them ideal for specific applications where uniform heating, space...
Product Details
Square alumina crucibles for muffle furnace are specialized containers made from high-purity alumina (Al₂O₃), designed to withstand extreme temperatures and harsh conditions inside muffle furnaces.
These crucibles feature a square shape, making them ideal for specific applications where uniform heating, space efficiency, or a stable placement is required.
Alumina Purity: >99%
Maximum temperature resistance: 1750°C
Continuous operating temperature: ≤1600°C
We offer customized services according to your requirements!
How to Use Alumina Crucibles？
1. Before the first use, preheat the crucible in an oven at around 105°C for 120 minutes to remove moisture.
2. Do not directly heat the crucible with gasoline blowtorch, acetylene torch, or alcohol burner to avoid uneven heating and cracking of the product.
3. The heating or cooling rate should not be too fast. The temperature change below 1200°C should be <5°C/minute, and above 1200°C should be ≤4°C/minute.
4. The distance between the product and the heating element (such as carbon tube, silicon molybdenum rod, or heating wire, etc.) should be >2cm.
5. The bottom of large crucibles should preferably not directly contact the bottom of the furnace. It is recommended to use alumina foot pads or other heat-resistant materials to lift the crucible, forming air convection to prolong the service life of the product.
Alumina Crucibles for Muffle Furnace Related Products
Square Crucible with Lid for Muffle Furnace
Curved Muffle Furnace Crucible
Alumina Conical Crucible with Lid
Alumina Kiln Furniture for Muffle Furnace
Ceramic Alumina (Al2O3) Plates with Holes
Specifications
Figures below are the manufacturer data for this model. Anything not listed is confirmed in writing with the quotation rather than estimated here.
| Square Alumina Crucibles for Muffle Furnace (UoM：mm) | |||
|---|---|---|---|
| 20×20×10 | 20×20×17 | 25×15×15 | 30×20×10 |
| 30×20×17 | 30×30×10 | 30×30×20 | 30×30×30 |
| 40×30×20 | 40×30×25 | 40×30×30 | 45×8×6 |
| 45×22×13 | 50×10×10 | 50×20×10 | 50×20×15 |
| 50×20×20 | 50×25×10 | 50×25×20 | 50×25×35 |
| 50×40×10 | 50×40×15 | 50×40×20 | 50×50×10 |
| 50×50×20 | 50×50×25 | 50×50×30 | 60×30×10 |
| 60×30×14 | 60×30×15 | 60×30×20 | 60×30×30 |
| 60×40×20 | 60×60×25 | 65×65×25 | 65×65×30 |
| 65×65×35 | 65×65×65 | 70×70×30 | 75×75×15 |
| 78×38×22 | 80×40×20 | 80×40×30 | 80×40×30 |
| 80×40×40 | 80×40×55 | 80×40×40 | 80×40×55 |
| 80×80×40 | 85×85×40 | 90×60×20 | 90×60×30 |
| 90×60×40 | 90×60×45 | 90×90×30 | 90×90×45 |
| 100×20×20 | 100×30×10 | 100×30×15 | 100×30×20 |
| 100×30×30 | 100×40×15 | 100×40×20 | 100×50×30 |
| 100×60×40 | 100×60×60 | 100×100×25 | 100×100×35 |
| 100×100×40 | 100×100×60 | 100×100×100 | 105×105×12 |
| 105×105×40 | 115×65×45 | 115×115×35 | 120×60×20 |
| 120×60×40 | 120×80×30 | 120×80×40 | 120×120×50 |
| 120×120×100 | 135×135×60 | 140×140×38 | 140×140×45 |
| 140×140×70 | 150×150×30 | 150×150×50 | 150×150×60 |
| 150×150×80 | 155×120×50 | 160×120×35 | 160×120×85 |
| 160×140×120 | 160×160×45 | 180×180×60 | 200×100×25 |
| 200×100×50 | 200×150×200 | 200×200×50 | 200×200×80 |
| 200×200×100 | 225×225×83 | 250×150×80 | 250×250×80 |
| 250×250×100 | 300×60×60 | 300×180×70 | 300×200×80 |
| 330×330×80 | 330×330×120 | 330×330×160 |
