Advanced GPS Vehicle Tracker
Car GPS Tracker For Fleet Management VT-301
Concealed wired tracker that combines car alarm duty with driver ID reporting, no extra RFID kit needed.
View specificationsWired 4G fleet tracker with driver ID, fuel monitoring and remote immobilisation over RS232.
VT-302 is a hard wired fleet tracker that doubles as a car alarm. It reports the driver ID to your tracking platform, so a dispatcher sees which driver moved which vehicle and at what time, and it refuses to let an unidentified driver start the engine. Reader choice is left open: iButton, Bluetooth beacon, fingerprint, passive RFID or the driver's phone acting as the tag.
| Backup battery | 500 mAh lithium |
|---|---|
| Offline storage | 64MB memory, 30,000 position records |
| IO | 2 digital inputs, 1 digital output, 1 analog input |
| Serial port | RS232 transparent transmission |
| Driver ID | iButton, Bluetooth beacon, fingerprint, passive RFID, phone as RFID |
| Protocols | TCP / UDP / HTTP / MQTT |
| Immobiliser condition | Vehicle speed below 30 km/h |
Firmware behaviour can be changed to match your platform and your customer's rules: reporting logic, alarm text, protocol fields and reader type. Housing and packaging can carry your own brand.
Choose VT-302 over VT-301 when you need the RS232 serial port for a third party peripheral. If you do not need serial data, VT-301 covers the same driver ID and anti theft feature set. For camera and WiFi hotspot work, step up to VT-390.
Wire to vehicle power and ACC, connect the chosen reader, register the tags on the platform, then set separate engine on and engine off intervals before handing the vehicle over. Test the immobiliser with the vehicle stationary.
Passive RFID or iButton. Both scale to a large tag list, 500+ ID numbers for passive RFID and 100+ tags for iButton, and neither depends on the driver's phone.
It controls the vehicle through the digital output and immobilises only when speed is below 30 km/h, so the vehicle is not cut at speed.
Positions are written to the 64MB memory, up to 30,000 records, and uploaded once the network returns.
It speaks TCP, UDP, HTTP and MQTT. Send us your protocol requirement with your enquiry and we will confirm before you order.
Yes, through the analog input with a fuel sensor. Both a drop and a refill beyond the set threshold raise their own message.
Dual SIM is an option for international transport.
