Buy 3/4/5 Axles Flatbed Semi Trailer in Bulk
3, 4 and 5 axle flatbeds from 25 to 90 tons with lift or steer axles
Looking for a reliable Flatbed Semi Trailer supplier to enhance the efficiency of your logistics or transportation business? We are an ISO-certified Chinese trailer manufacturer, specializing in providing high-quality flatbed trailers that are structurally robust, have strong load-bearing capacity, and are suitable for long-distance transportation and road leveling. We support factory-direct sales prices and can customize the size, number of shafts, and load configuration according to your needs.
- Size
- 13,000*2,550*1,510MM
- Axle
- FUWA Lift Axle/Steer Axle or Customized
- Tare Weight
- 7,000 KG
- Loading capacity
- 25-90T
Built at SINOHENG Trailer Factory, Jinan, Shandong, China. Exported to 30+ countries across Southeast Asia, Africa, the Middle East and South America.
Operators This Trailer Is Built Around
- Bulk buyers building a flatbed fleet across several payload classes
- Operators carrying containers, heavy equipment and steel coils on the same deck
Problems It Solves
Running a heavy trailer empty wastes fuel
FUWA lift axles can be specified so unused axles come off the road when you run light.
Tight yards need a steering axle
Steer axle options are available where turning circle limits where the trailer can go.
What You Get For the Money
25 to 90 tons loading capacity
A 7,000 kg tare with the size, axle count and load configuration customised to your work.
ISO certified manufacture
Produced by an ISO-certified Chinese manufacturer with factory-direct pricing.
Brand braking and kingpin
WABCO or other brand valves, JOST 50# or 90# kingpin, mechanical or air suspension.
Technical Description
Technical Construction
Our flatbed semi-trailers are widely used in the transportation of bulk goods such as containers, heavy equipment, and steel coils. The vehicle body is made of high-strength steel, with a reinforced main beam design. It is equipped with high-quality axles and tires to ensure that the trailer remains stable and durable under high-intensity working conditions, reducing daily maintenance costs.
Build and Finish
Whether you need a 3-axle 40-foot flatbed trailer or make a large purchase for fleet operations, we offer OEM customization and rapid export support. At present, our products have been exported to many countries and regions such as Africa, Southeast Asia, and South America, and are deeply trusted by customers.
Operating Detail
Contact us immediately to get a quote and start your bulk order!
Manufacturing Notes
SINOHENG Trailer Factory is an enterprise specializing in the production and sales of trailers, dedicated to providing customers with high-quality and high-performance trailer products. We use high-strength steel and optimized design to ensure that the products maintain high load-bearing capacity while being lightweight, meeting customers’ dual demands for transportation efficiency and cost control.
Buy 3/4/5 Axles Flatbed Semi Trailer in Bulk Specification Sheet
Figures below are the published specification for the standard build. Anything not listed is confirmed on the approval drawing before production, and we mark unknowns as TBC rather than estimating them.
| Size | 13,000*2,550*1,510MM |
|---|---|
| Axle | FUWA Lift Axle/Steer Axle or Customized |
| Tare Weight | 7,000 KG |
| Loading capacity | 25-90T |
| Suspension | Mechanical/Air suspension system |
| Brake System | WABCO valve/Other Brand |
| Electrical system | 24V 7 ways |
| Landing Gear | 28 Ton JOST/Other Brand |
| Light | Waterproof LED Light |
| King pin | 50#(2″)/90#(3.5″) JOST/Other Brand |
| Rim | 9.00-22.5 |
| ABS/EBS | Optional |
| Tire | 12R22.5/8.25r20 |
| Accessories | 1. A toolbox 2, with a set of standard trailer tools |
This Build in the Factory
How It Compares
Our 40 ft flatbed trailer is a single fixed specification at a sharp price. This model exists for buyers who need to vary axle count, axle type and capacity across a fleet order.
Operating Notes
- Lower lift axles before loading, not after.
- Secure steel coils in purpose-made coil wells or cradles, never loose on the deck.
- Check air suspension height control at every service if fitted.
Every vehicle ships with an illustrated operation manual covering coupling, braking and turning technique.
Other Builds Worth Comparing
40FT Flatbed Trailer for Sale
40 ft three axle flatbed at 7,700 kg tare carrying 40 tons
View specification →
Best Flatbed Trailer Manufacturer
40, 60 and 80 ton flatbeds with hydraulic lift kingpin and OEM support
View specification →
Reliable Flatbed Trailer Supplier
12.5 m flatbed with 3 mm checkered floor and fully listed running gear
View specification →
Custom Fence Trailer for Sale
Stake side trailer built to your side wall height and axle count
View specification →Questions About This Trailer
When is a lift axle worth it?
When a significant share of your running is empty or part loaded. Lifting an axle reduces tyre wear and rolling resistance; if you always run loaded, it adds cost for nothing.
Do you supply in bulk?
Yes. This model is set up for bulk orders with factory-direct supply, and we can quote mixed configurations within one shipment.
Which ISO certification do you hold?
The original listing states ISO certified manufacture. Ask us for the current certificate copy with your quotation so you have the exact scope and validity date.
Do you ship to my country?
SINOHENG exports in bulk to 30+ countries and regions across Southeast Asia, Africa, the Middle East and South America. Send your destination port with the enquiry and we will quote delivery with the trailer.
Ask for a Drawing Before You Commit
We confirm dimensions, axle loads and coupling height on an approval drawing before any steel is cut, so the trailer is legal and couples to your tractors.
