High-Quality 40Ft Drop Side Truck Trailer for Cargo Transport
40 ft drop side platform with diamond plate floor and three suspension options
Looking for an efficient and reliable cargo transportation trailer? This high-quality 40-foot Drop Side truck trailer is specially designed for various freight scenarios, featuring both durability and ease of loading and unloading. Whether it is the transportation of agricultural products, building materials, or general cargo, it can bring higher efficiency to your transportation business.
- Size
- 12500*2500*1550mm
- Axles
- 13T/16/20T FUWA brand
- Loading
- 30T, 40T, 45T, 50T, 60T
- LandingGears
- JOST brand two-speed, Manual operating, heavy-duty 28-ton
Built at SINOHENG Trailer Factory, Jinan, Shandong, China. Exported to 30+ countries across Southeast Asia, Africa, the Middle East and South America.
Operators This Trailer Is Built Around
- Export fleets running 40-foot platforms on long distance general cargo routes
- Operators who load agricultural produce, building materials and machinery on the same deck
Problems It Solves
A thin floor dents under machinery
Diamond steel plate floor in 3 mm, 4 mm or 6 mm, so you can specify the deck for what actually rolls onto it.
One suspension type cannot cover every road
Bogie, spring and air suspension are all offered against the same 40-foot platform.
What You Get For the Money
30 to 60 tons loading
13, 16 or 20-ton FUWA axles under Q345B main beams with 14 mm upper flange, 8 mm web and 16 mm lower flange.
Side panel height to order
600 mm, 800 mm or 1,000 mm flip-side rails for rapid lateral loading.
WABCO braking
WABCO valve with large brake chambers, specified for a fully loaded 40-foot platform.
Technical Description
Technical Construction
The entire vehicle adopts a 40-foot reinforced platform, equipped with sturdy flip-side rails, supporting rapid lateral loading and unloading, significantly saving manpower and time. The high-strength steel chassis structure ensures that the trailer remains stable in harsh road and weather conditions, adapting to various heavy-load transportation needs.
Build and Finish
As a professional Chinese trailer manufacturer and exporter, we offer factory-direct sales prices, global shipping support, and can customize structures and configurations according to customer needs. Our products comply with ISO international quality standards and come with a complete after-sales service system. Contact us now to get the most favorable quotation!
Operating Detail
SINOHENG Trailer Factory is an enterprise specializing in the production and sales of trailers, dedicated to providing customers with high-quality and high-performance trailer products. We use high-strength steel and optimized design to ensure that the products maintain high load-bearing capacity while being lightweight, meeting customers’ dual demands for transportation efficiency and cost control.
Manufacturing Notes
Our products are not only popular across the country but also exported in bulk to over 30 countries and regions in Southeast Asia, Africa, the Middle East, South America, etc., earning the trust of customers worldwide. Moreover, we offer comprehensive after-sales service to ensure you have no worries. Choosing SINOHENG means choosing quality, choosing professionalism, and choosing peace of mind.
High-Quality 40Ft Drop Side Truck Trailer for Cargo Transport Specification Sheet
Figures below are the published specification for the standard build. Anything not listed is confirmed on the approval drawing before production, and we mark unknowns as TBC rather than estimating them.
| Size | 12500*2500*1550mm |
|---|---|
| Axles | 13T/16/20T FUWA brand |
| Loading | 30T, 40T, 45T, 50T, 60T |
| LandingGears | JOST brand two-speed, Manual operating, heavy-duty 28-ton |
| Floor | 3mm,4mm,6mm diamond steel plate |
| Side panel | Height 600mm, 800mm, 1000mm |
| Material | Main beams Q345B, upper flange:14mm, middle:8mm, down:16mm |
| Brake System | WABCO Valve with a big chamber |
| ElectricalSystem | 24V, 7-core socket, lights according to European standards (suitable for all markets) |
| Suspension | Bogie suspension, spring suspension, and air suspension |
| Other parts | 1 toolbox, 1 spare tire carrier |
This Build in the Factory
How It Compares
Against our 12.4 m dropside manufacturer model, this 40-foot build offers more floor and suspension choices. Against a fence trailer, the lower flip-side rails favour forklift access over cargo volume.
Operating Notes
- Match tie-down points to the load, do not rely on the side panels to restrain cargo.
- Inspect the diamond plate floor for deformation after heavy point loads.
- Drain air tanks regularly in humid climates.
Every vehicle ships with an illustrated operation manual covering coupling, braking and turning technique.
Other Builds Worth Comparing
Buy Drop Side Trailer at Factory Price
Fold-down side panels on a heavy steel deck for mixed construction loads
View specification →
China 40FT Dropside Trailer Manufacturer
12.4 m dropside with 800 mm panels and 40 ton payload at 7.5 ton tare
View specification →
Drop Side Trailer for Sale
Fold-down side trailer rated 40 to 70 tons for fast-paced logistics
View specification →
Durable Side Wall Semi Trailer for Sale
12.5 m side wall trailer with 600 mm panels carrying 50 tons
View specification →Questions About This Trailer
Which floor thickness should I order?
3 mm is adequate for palletised goods. Choose 4 mm or 6 mm if tracked or wheeled plant is driven onto the deck, or if you load steel with sharp edges.
What does bogie suspension change?
Bogie suspension is robust and simple and handles poor roads well. Air suspension protects fragile cargo and gives a better ride. Spring suspension sits between the two on cost.
Can you supply matching spare parts?
Yes. Order spare brake chambers, leaf springs and lamps with the trailer and they ship in the same container.
Do you ship to my country?
SINOHENG exports in bulk to 30+ countries and regions across Southeast Asia, Africa, the Middle East and South America. Send your destination port with the enquiry and we will quote delivery with the trailer.
Ask for a Drawing Before You Commit
We confirm dimensions, axle loads and coupling height on an approval drawing before any steel is cut, so the trailer is legal and couples to your tractors.
