Drop Side Trailer for Sale
Fold-down side trailer rated 40 to 70 tons for fast-paced logistics
Looking for a practical and durable Drop Side trailer ? Our Drop Side Trailer for Sale is specially designed for various transportation needs. Whether it is construction materials, bulk cargo, or general freight, it can handle them easily. The foldable side plate structure makes loading and unloading more efficient and flexible, suitable for various loading scenarios, especially for fast-paced logistics operations.
- Size
- 13000-9000*2500*2200mm
- Axle
- 13T/16T FUWA brand or as customer requirements
- Loading Capacity
- 40T-70T
- Main Beam
- Material Q345B or T700 Beam height 480-520mm
Built at SINOHENG Trailer Factory, Jinan, Shandong, China. Exported to 30+ countries across Southeast Asia, Africa, the Middle East and South America.
Operators This Trailer Is Built Around
- Logistics operators on tight turnaround schedules who load from the side
- Contractors moving construction materials and bulk cargo between depots and sites
Problems It Solves
Turnaround time is lost at the loading bay
The foldable side plate structure suits fast-paced operations where a forklift works both flanks at once.
Heavy loads flex a thin chassis
Q345B or T700 main beam at 480 to 520 mm beam height under a high-strength steel body.
What You Get For the Money
40 to 70 tons loading capacity
13 or 16-ton FUWA axles, or another brand to customer requirement.
2, 3 and 4 axle builds
Customised to the transportation requirement rather than sold as one fixed model.
Dual line pneumatic braking
Supplied complete with hose and connector, on mechanical suspension with 12R22.5 tyres.
Technical Description
Technical Construction
The entire vehicle is made of high-strength steel and is equipped with a robust suspension system, ensuring excellent stability even under heavy loads. It offers various configurations such as 2-axle, 3-axle, and 4-axle, and can be customized according to transportation requirements.
Build and Finish
Whether you are engaged in logistics, transportation, construction projects, or agricultural transportation, this Drop Side trailer can provide you with efficient and reliable transportation solutions. Support factory direct sales prices to help you reduce costs and improve efficiency.
Operating Detail
SINOHENG Trailer Factory is an enterprise specializing in the production and sales of trailers, dedicated to providing customers with high-quality and high-performance trailer products. We use high-strength steel and optimized design to ensure that the products maintain high load-bearing capacity while being lightweight, meeting customers’ dual demands for transportation efficiency and cost control.
Manufacturing Notes
Our products are not only popular across the country but also exported in bulk to over 30 countries and regions in Southeast Asia, Africa, the Middle East, South America, etc., earning the trust of customers worldwide. Moreover, we offer comprehensive after-sales service to ensure you have no worries. Choosing SINOHENG means choosing quality, choosing professionalism, and choosing peace of mind.
Drop Side Trailer for Sale Specification Sheet
Figures below are the published specification for the standard build. Anything not listed is confirmed on the approval drawing before production, and we mark unknowns as TBC rather than estimating them.
| Size | 13000-9000*2500*2200mm |
|---|---|
| Axle | 13T/16T FUWA brand or as customer requirements |
| Loading Capacity | 40T-70T |
| Main Beam | Material Q345B or T700 Beam height 480-520mm |
| Material | Steel |
| Suspension | Mechanical |
| Brake System | Dual line pneumatic brake, with hose and connector |
| Relay Valve | WABCO Valve |
| Kingpin | 2-inch or 3.5-inch |
| Tire | 12R22.5 |
This Build in the Factory
How It Compares
Our 40 ft drop side truck trailer offers a wider range of floor thicknesses and suspension types. This model is the straightforward, well-specified version for operators who do not need those options.
Operating Notes
- Fold and latch panels fully before departure.
- Sheet loose cargo even with the panels up.
- Grease hinges and latch mechanisms monthly in dusty conditions.
Every vehicle ships with an illustrated operation manual covering coupling, braking and turning technique.
Other Builds Worth Comparing
Buy Drop Side Trailer at Factory Price
Fold-down side panels on a heavy steel deck for mixed construction loads
View specification →
China 40FT Dropside Trailer Manufacturer
12.4 m dropside with 800 mm panels and 40 ton payload at 7.5 ton tare
View specification →
Durable Side Wall Semi Trailer for Sale
12.5 m side wall trailer with 600 mm panels carrying 50 tons
View specification →
Heavy Duty 2/3/4 Axles Drop Side Cargo Trailer for Bulk Transport
Detachable side panels and 2, 3 or 4 axles for bulk and general freight
View specification →Questions About This Trailer
Q345B or T700 main beam?
Q345B suits general freight duty. T700 is a higher tensile steel that allows a lighter beam for the same strength, which matters when you are chasing payload.
What kingpin size is fitted?
2 inch or 3.5 inch, matched to your tractor's fifth wheel.
Can the deck be lengthened?
Deck length is set per order. Tell us the length you need and the cargo, and we will confirm feasibility against axle positions.
Do you ship to my country?
SINOHENG exports in bulk to 30+ countries and regions across Southeast Asia, Africa, the Middle East and South America. Send your destination port with the enquiry and we will quote delivery with the trailer.
Ask for a Drawing Before You Commit
We confirm dimensions, axle loads and coupling height on an approval drawing before any steel is cut, so the trailer is legal and couples to your tractors.
