Sinotruk HOWO 8 ton forward dump truck with hydraulic lift body in red, parked on a gravel site

Side view of the HOWO forward dump truck showing the high strength steel body and hydraulic pistons

Front view of the HOWO 4x2 dump truck with power steering and large front wheels

Sinotruk Howo 8 ton forward dump truck for sale swaziland

Name: Sinotruk Howo 8 ton forward dump truck for sale swaziland
Brand: Sinotruk HOWO

The Sinotruk HOWO 8 ton forward dump truck is a 4x2 rigid truck built on a ZZ3168E3415C143 chassis with a 130 HP diesel engine and 8-speed manual gearbox. It is designed for transporting loose materials such as sand, gravel, coal, and dirt in mining, construction, and quarry operations. The forward dump body lifts at the front using hydraulic pistons and has a 7 cubic metre capacity, allowing efficient unloading on uneven or unpaved terrain. The truck is supplied with a high strength steel body and is available in left or right hand drive to match local traffic regulations.

Request A Quote Email Specification

Key Benefits

8 ton payload capacity with a 7 m3 forward dump body for high volume material transport
130 HP YC4D130-33 engine with turbocharging and intercooling for reliable performance
8-speed manual gearbox with PTO for auxiliary equipment operation
Front and rear leaf spring suspension with hydraulic shock absorbers for stability on rough roads
High strength steel tipper body resists wear and deformation under heavy loads
Hydraulic front lift system with robust pistons ensures consistent and controlled dumping
Left or right hand drive chassis available to match local driving conditions
20 day lead time after deposit payment for faster project deployment

Buyer Profile

Who It Is for

Mining and quarry operators sourcing reliable dump trucks for short haul transport
Construction companies managing site logistics in rural or low infrastructure areas
Road and civil engineering contractors in Southern Africa and emerging markets
Government public works departments procuring vehicles for rural infrastructure projects
Private contractors supplying material transport services to remote locations
Equipment rental companies expanding their fleet with cost-effective, durable trucks

Operating Problems

Problems It Solves

Frequent breakdowns from low quality dump trucks in harsh mining and construction environments
Inadequate payload capacity or body volume for efficient material transport
Lack of forward dump design that causes spillage or inefficient unloading on uneven ground
Long lead times delaying project start due to imported truck delivery schedules
Unreliable engines that require frequent overhauls or fail under continuous operation
Inflexible chassis configurations that do not match local driving side or road conditions

Where It Works

Application Scenarios

Quarry and gravel pit operations requiring frequent material transport over rough access roads
Construction sites with limited space where forward dumping avoids obstructions
Mining contractors moving bulk material in remote areas with no dedicated loading equipment
Road maintenance teams transporting sand and gravel for patch repairs and surface work
Small to medium scale infrastructure projects in developing regions with limited access to heavy equipment
Contractors operating in Swaziland and Southern Africa needing durable, low maintenance trucks

Engineering

Technical Features

Forward dump body with hydraulic lift system at the front for controlled unloading
High strength steel body with reinforced edges and wear-resistant plates on the bed
8-speed manual gearbox with PTO for powering auxiliary equipment like compactors or pumps
Power steering with hydraulic assistance for easier handling in tight spaces
Dual circuit air brake system with four-circuit protection valve for safe stopping
Spring energy parking brake on rear wheels for secure holding on slopes
120 litre fuel tank with spare tyre included for extended operation
Wheelbase of 3360+1350 mm for improved stability under load and on rough terrain

Specifications

Technical Data


Chassis Model	ZZ3168E3415C143
Drive Configuration	4x2
Engine	YC4D130-33, 130 HP, Euro III, 4-cylinder in-line, turbocharged, intercooled
Gearbox	8JS85F, 8 forward, 1 reverse, manual with PTO
Front Axle	3200 kg, drum brake
Rear Axle	2x10000 kg, double stage reduction, cast housing
Suspension	Front: 10 leaf springs with hydraulic shock absorbers, Rear: 12 leaf springs with bogie spring
Steering	Power steering with hydraulic assistance
Braking System	Front and rear drum, dual circuit air brake, parking brake spring energy
Tires	9.00R20, 1 spare included
Fuel Tank	120 L
Dead Weight	600 kg
Gross Vehicle Weight	16000 kg
Rated Loading Weight	10000 kg
Overall Dimension	6545 x 2450 x 3200 mm
Wheelbase	3360 + 1350 mm
Cargo Body Size	3850 x 2100 x 800 mm
Cargo Body Volume	7 m3
Body Type	Forward dump, hydraulic lift
Drive Type	Left or Right Hand Drive, optional
Lead Time	20 days after deposit
Shipping Port	China main port
Payment	T/T

Build Materials

Materials

High strength steel for the tipper body with wear-resistant reinforcement on loading edges
Aluminium alloy for hydraulic piston rods and external fittings to resist corrosion
Rubber bushings and seals in suspension and steering systems for vibration damping

How It Is Built

Manufacturing Process

Chassis is received and inspected for correct drive configuration and wheelbase
Tipper body is cut, formed, and welded from high strength steel sheets
Hydraulic lift system is assembled and tested for smooth operation and load capacity
Body is mounted onto the chassis subframe with reinforced mounting brackets
All electrical and hydraulic connections are checked and secured
Truck is driven on the factory apron to test steering, braking, and lifting function
Final inspection includes full body seal check and hydraulic pressure test
Photos and videos of the finished truck are sent to the buyer before balance payment

Testing

Quality Control

Every truck is 100 percent tested before delivery
Hydraulic system tested under full load for 30 minutes without leakage
Braking system tested on incline and under full load to verify stopping distance
Body welds inspected using non-destructive testing methods
Chassis alignment verified using laser measurement tools
All components match the technical drawings and specifications provided by the buyer

Build to Order

Customization Options

Tipper body size and volume can be adjusted to match specific load requirements
Left or right hand drive chassis selected at order stage to match local traffic rules
Body colour and logo applied free of charge upon request
Optional auxiliary systems such as ABS, EVB exhaust brake, or automatic brake gap adjusters can be added
Body can be fitted with side or rear access doors for easier loading
Manufacture to customer supplied technical drawings and specifications

Comparison

How It Compares With the Alternatives

6 ton forward dump truck	Lower payload and volume but better maneuverability in tight urban or site access areas
Side dump truck	Better for one-sided unloading but less stable on uneven ground and harder to align with dump points
Rear dump truck	Simpler design but requires more space to turn and less effective on slopes or uneven terrain

Operating Notes

Use Guide

Confirm left or right hand drive at order stage as it cannot be changed after production
Do not exceed 10000 kg rated loading weight to avoid structural damage
Check hydraulic fluid levels before each shift and inspect hoses for leaks
Use the parking brake when parked on slopes to prevent rollaway
Inspect body welds and wear plates monthly in high abrasion environments
Free operator training is available at the factory before shipment

Buyer Questions About This Truck

What is the lead time for this dump truck?

Generally 20 days after the advance payment is received. The exact date depends on chassis availability and the equipment list you specify.

Can the truck be right hand drive?

Yes. The chassis is available in left or right hand drive. Confirm your preference at order stage as it cannot be changed after production.

What is the payment term?

T/T with 30 percent deposit and 70 percent before delivery. We send photos and videos of the finished truck before you pay the balance.

How is the truck shipped?

By Ro-ro or bulk ship from a China main port. Trade terms can be EXW, FOB, CFR, or CIF.

Can the body be made from stainless steel?

The standard body is high strength carbon steel. Stainless steel is available on request. Let us know your material handling requirements and we will confirm suitability.

What warranty and after sales support do you provide?

The whole vehicle is guaranteed for one year and core parts on some products for two years. Our overseas engineers make regular return visits and provide technical training and manuals before delivery.

Can the hydraulic system be upgraded with ABS or exhaust brake?

Yes. Optional systems such as ABS, EVB exhaust brake, and automatic brake gap adjusters can be added. Specify your requirements at order stage.
