19.50×14.00
19.50×14.00 is a steel rim designed for truck wheel assemblies, suitable for use on medium-duty commercial vehicles. It features a 14.00 inch width and a 19.50 inch diameter, with a 5000kg r
Overview
19.50×14.00 is a steel rim designed for truck wheel assemblies, suitable for use on medium-duty commercial vehicles. It features a 14.00 inch width and a 19.50 inch diameter, with a 5000kg rated load capacity. The rim has a 10-bolt pattern with a 335mm pitch circle diameter and a 0 offset, ensuring compatibility with standard hub configurations. It is built for use without an inner tube and includes a TR575 valve type for secure air retention.
- ISO9001
- ISO/TS16949
- CCC
- E-mark
- DOT
- GSO/GCC
- SONCAP
- INMETRO
- NOM
What 19.50×14.00 Gives the Operator
10-bolt pattern with 335mm PCD ensures secure fitment on standard truck hubs
0 offset design maintains alignment and reduces lateral stress on the wheel assembly
TR575 valve type provides reliable air retention and ease of maintenance
Wind hole type 10-57×32 allows for proper airflow and heat dissipation during operation
Steel construction offers durability and resistance to deformation under heavy loads
Application Scenarios
- Medium-duty trucks operating on paved roads with regular loading and unloading cycles
- Fleet vehicles requiring consistent rim compatibility across multiple vehicle models
- Trucks used in regional distribution where rim reliability and load capacity are critical
Who It Is For
- Importers sourcing steel rims for medium-duty truck fleets
- Distributors needing a standard rim size compatible with common truck models
- Fleet operators replacing rims on vehicles with 19.50×14.00 wheel specifications
What It Is Meant To Fix
Rims that do not match the bolt pattern or offset of the original hub, causing fitment issues
Inadequate load capacity leading to rim deformation under heavy axle loads
Valve type mismatch causing air leakage or difficulty in inflation and pressure checks
Published Data For 19.50×14.00
These are the figures published for this product. Anything not listed here is confirmed in writing before an order.
- Model19.50×14.00
- Rated Load5000kg
- Distributed Circle (PCD)φ335
- Bolt Hole10-φ26
- Center Holeφ281
- Screw Hole Type1×45°
- Offset0
- Wind Hole Type10-57×32
- Valve TypeTR575
Technical Features
- Model: 19.50×14.00 steel rim without inner tube
- Rated load capacity: 5000kg
- Bolt pattern: 10-φ26 with 335mm pitch circle diameter
- Center hole: φ281
- Offset: 0
- Wind hole type: 10-57×32
- Valve type: TR575
- Screw hole type: 1×45° for secure fastening
Customisation
- Rims can be supplied with custom markings or logos upon request
- Packaging can be adjusted for container loading efficiency and handling
- Surface finish options available based on market requirements
Quality Control
- Rim profile verified against dimensional standards during production
- Bolt hole alignment checked for consistency across batches
- Surface finish inspected for defects and corrosion resistance
- Production conducted under ISO9001 and ISO/TS16949 quality systems
How It Compares
- Compared with A 19.50×14.00 rim with positive offsetThis rim's 0 offset ensures better hub alignment and reduces lateral stress on the wheel
- Compared with A rim with inner tube designThis rim is without inner tube, reducing maintenance and improving air retention reliability
Getting the Most Out Of It
- Ensure the hub and bolt pattern match the 10-φ26 and 335mm PCD specifications
- Verify that the offset is 0 to maintain proper wheel alignment
- Use the TR575 valve type for consistent air pressure and leak prevention
- Check wind hole alignment during assembly to ensure proper airflow
19.50×14.00 Questions
What is the bolt pattern for the 19.50×14.00 rim
The bolt pattern is 10-φ26 with a 335mm pitch circle diameter
What is the rated load capacity of this rim
The rated load is 5000kg
Is this rim suitable for use without an inner tube
Yes, it is designed for use without an inner tube
What is the offset of this rim
The offset is 0, which ensures proper alignment with the hub
What valve type is used on this rim
The valve type is TR575
Can this rim be used on trucks with different wheel sizes
It is designed specifically for 19.50×14.00 wheel assemblies and should not be used with mismatched sizes
Get Pricing For 19.50×14.00
Send the sizes and quantity per size. We will confirm availability, the approval marking for your market and a container plan.
