Rubber EVA Foam Mat
Rubber-Blended EVA Tiles for Weight Areas and Anti-Fatigue Workstations
What This Mat Is and Who It Is For
The Rubber EVA Foam Mat blends rubber with EVA foam to produce a denser, harder-wearing tile than our standard lines. At 80 kg/m3 and Shore A 38-45 it takes point loads from racks and machines without permanently denting.
It is the specification to quote when the floor has to survive equipment rather than only bodies - free-weight zones, commercial fitness centres and industrial standing workstations.
- Rubber and EVA foam blend
- 80 kg/m3 density, Shore A 38-45 hardness
- Formamide index below 200 ppm
- Lies flat without curling at the edges
What the Buyer Gets
Rubber-blend surface for extra durability
A floor that holds its shape under equipment rather than taking a permanent impression
Excellent grip under heavy equipment
Grip that keeps racks and benches from walking across the room
Superior wear resistance
Relief for staff standing at a workstation for a full shift
Stable, flat laying without curling
Protection for the slab underneath, which is far more expensive to repair
Who it is for
- Commercial fitness centre and weight-room fit-out suppliers
- Industrial distributors selling anti-fatigue matting
- Gym equipment brands bundling flooring with racks and platforms
- Facility managers protecting concrete and screed floors
Problems it solves
- Dropped weights damage both the floor and the equipment
- Standard foam tiles compress permanently under rack feet
- Standing on concrete all shift causes fatigue and back complaints
- Lighter tiles creep and curl under heavy rolling loads
Application scenarios
- Heavy-duty gym zones
- Weightlifting areas
- Commercial fitness centres
- Industrial anti-fatigue workstations
Technical features
- Rubber and EVA foam blend
- 80 kg/m3 density, Shore A 38-45 hardness
- Formamide index below 200 ppm
- Lies flat without curling at the edges
Rubber EVA Foam Mat Technical Data
Figures below are the factory specification for this line. Anything marked TBC is confirmed per order rather than guessed at.
| Product Name | Rubber EVA Foam Mat |
|---|---|
| Material | EVA foam + rubber |
| Thickness | 1 cm - 4 cm (customizable) |
| Size | 60x60 cm (customizable) |
| Density | 80 kg/m3 |
| Hardness | Shore A 38-45 |
| Formamide Index | < 200 ppm |
| Certificates | REACH, EN71, BSCI, ISO 9001, ISO 14001 |
| Packing | Shrink-wrapped inner + carton outer |
| MOQ | TBC - confirm with sales |
| Lead Time | 30 days for regular orders |
Materials
Closed-cell EVA foam, blended with rubber for extra density and wear resistance. Non-toxic and environmentally friendly EVA and LDPE materials, with every batch tested.
Customization options
Custom sizes, thicknesses, colours, patterns and packaging. OEM and ODM branding available, including retail packaging and inserts.
How we specify a custom mat →Certifications
REACH, EN71, BSCI, ISO 9001 and ISO 14001. Test reports are shared with serious buyers on request.
View the certificates →How This Mat Is Made and Checked
Compounding
EVA resin and additives are weighed and mixed to the density the order calls for - 70-75 kg/m3 for standard lines, 80 kg/m3 for tatami and rubber-blend tiles.
Foaming
The compound is foamed into blocks on our own foaming lines. This is the step that fixes density, hardness and how the mat will behave under load.
Lamination
Printed film or suede surfaces are laminated onto the foam base for the wood-grain, plush and printed puzzle lines.
Die-cutting
Blocks are cut to tile size and the interlocking puzzle teeth are die-cut. Cut accuracy is what decides whether the seams close cleanly on site.
Quality control
Incoming material checks, in-process inspection and final sampling before every shipment.
Packing and shipping
Shrink-wrapped inner packing with a carton outer, loaded close to Shanghai and Qingdao seaports.
How It Compares With Our Other Lines
| Product | Key specification | Best suited to |
|---|---|---|
| Rubber EVA Foam Mat | Rubber blend, 80 kg/m3, Shore A 38-45 | Weight areas and industrial workstations |
| Five Stripes EVA Foam Mat | Standard EVA, 70-75 kg/m3, Shore C 36 | Group fitness and dance floors |
| Tatami Mats | Standard EVA, 80 kg/m3, 100x100 cm | Martial arts throwing areas |
Laying and Maintaining the Floor
Lay the tiles on a clean, level slab; the flatter the base, the better the tile sits.
Run the heaviest equipment over the thickest specification you have quoted.
Keep spare tiles from the same production batch for later replacement.
Sweep grit off the surface before it gets ground in under equipment.
Clean with a damp mop and a mild detergent; avoid solvents.
Sectors This Mat Is Specified For
Guides Related to This Product
EVA Foam Mat Thickness Guide
When buyers search for EVA foam mats, the first spec they ask about is usually thickness . After 20+ years of supplying gyms, schools and home users, we can tell...
Read the guide →
EVA vs Rubber Gym Flooring
Walk into any commercial gym and you will see both: rubber flooring under the free weights, foam-style tiles everywhere else. EVA and rubber gym flooring solve...
Read the guide →
Home Gym Flooring Setup Guide
A home gym floor is a weekend project that pays off for years - if you order the right quantity the first time. The most common mistake we see is not the tile...
Read the guide →Related Products
Cross Pattern EVA Foam Mat
Cross-Textured Interlocking Tiles for Yoga Taekwondo and Home Gyms
View specifications →
Five Stripes EVA Foam Mat
Five-Stripe Textured Floor Tiles for Commercial Gyms and Dance Studios
View specifications →
Pool Grid EVA Foam Mat
Open-Grid Drainage Mats for Pool Surrounds Showers and Wet Rooms
View specifications →Rubber EVA Foam Mat - Buyer Questions
How is this different from your standard EVA mats?
It is a rubber and EVA blend at 80 kg/m3 with Shore A 38-45 hardness, against 70-75 kg/m3 and Shore C 36 for the standard lines. It is denser and harder wearing.
What size does it come in?
60x60 cm is the standard size, and sizes are customizable.
Can it be used under a squat rack?
It is specified for heavy-duty gym zones and weightlifting areas. Send us the equipment loads and we will advise on thickness.
Is it suitable for industrial use?
Yes. Industrial anti-fatigue workstations are one of the listed applications.
What certifications does it hold?
REACH, EN71, BSCI, ISO 9001 and ISO 14001, with a formamide index below 200 ppm.
Get a Quote on the Rubber EVA Foam Mat
Send the size, thickness, colour, packaging and quantity. We reply within 24 hours, Monday to Saturday, and samples go by express with the courier charge refunded on your first bulk order.
