Cross Pattern EVA Foam Mat
Cross-Textured Interlocking Tiles for Yoga Taekwondo and Home Gyms
What This Mat Is and Who It Is For
The Cross Pattern EVA Foam Mat is a solid-colour interlocking floor tile with a cross-embossed surface. It is made for training rooms where people move barefoot or in socks and the floor underneath has to be protected.
The cross texture gives grip without being abrasive, and the interlocking edges let a buyer cover any room size from a single carton of tiles. Standard colours include black, grey and blue, with custom colours available for branded programmes.
- Cross-embossed surface texture on the wear side
- Interlocking puzzle edges on all four sides with straight border strips available
- Closed-cell EVA foam - water does not soak into the tile body
- Solid through-colour, so scuffs do not expose a different colour underneath
What the Buyer Gets
Cross-textured surface for enhanced grip
A room-size training surface that a single person can lay in minutes
High-density EVA resists compression
Consistent cushioning across the whole floor, not just under the mat
Interlocking edges for quick installation
A finished, uniform look in your own brand colours
Easy to clean and water-resistant
Tiles that stack flat, so a container carries more sellable floor area
Who it is for
- Fitness equipment brands and home-gym retailers building an own-label flooring range
- Importers supplying yoga studios, taekwondo schools and community sports halls
- Amazon and e-commerce sellers who need a compact, carton-friendly floor tile
- Distributors replacing loose rubber sheets with a lighter interlocking system
Problems it solves
- Hard training floors bruise knees and elbows during ground work
- Loose mats slide apart and open gaps mid-session
- Rental and residential floors get scratched by equipment and dropped weights
- Shipping bulky gym flooring eats the margin on low-value orders
Application scenarios
- Home gyms and fitness studios
- Yoga, Pilates and aerobics
- Taekwondo and martial arts training
- Garage and workshop flooring
Technical features
- Cross-embossed surface texture on the wear side
- Interlocking puzzle edges on all four sides with straight border strips available
- Closed-cell EVA foam - water does not soak into the tile body
- Solid through-colour, so scuffs do not expose a different colour underneath
Cross Pattern EVA Foam Mat Technical Data
Figures below are the factory specification for this line. Anything marked TBC is confirmed per order rather than guessed at.
| Product Name | Cross Pattern EVA Foam Mat |
|---|---|
| Material | EVA foam |
| Thickness | 1 cm - 4 cm (customizable) |
| Size | 30x30 cm, 50x50 cm, 60x60 cm (customizable) |
| Density | 70-75 kg/m3 |
| Hardness | Shore C 36 |
| Formamide Index | < 200 ppm |
| Certificates | REACH, EN71, BSCI, ISO 9001, ISO 14001 |
| Packing | Shrink-wrapped inner + carton outer |
| MOQ | TBC - confirm with sales |
| Lead Time | 30 days for regular orders |
Materials
Closed-cell EVA foam. Non-toxic and environmentally friendly EVA and LDPE materials, with every batch tested.
Customization options
Custom sizes, thicknesses, colours, patterns and packaging. OEM and ODM branding available, including retail packaging and inserts.
How we specify a custom mat →Certifications
REACH, EN71, BSCI, ISO 9001 and ISO 14001. Test reports are shared with serious buyers on request.
View the certificates →How This Mat Is Made and Checked
Compounding
EVA resin and additives are weighed and mixed to the density the order calls for - 70-75 kg/m3 for standard lines, 80 kg/m3 for tatami and rubber-blend tiles.
Foaming
The compound is foamed into blocks on our own foaming lines. This is the step that fixes density, hardness and how the mat will behave under load.
Lamination
Printed film or suede surfaces are laminated onto the foam base for the wood-grain, plush and printed puzzle lines.
Die-cutting
Blocks are cut to tile size and the interlocking puzzle teeth are die-cut. Cut accuracy is what decides whether the seams close cleanly on site.
Quality control
Incoming material checks, in-process inspection and final sampling before every shipment.
Packing and shipping
Shrink-wrapped inner packing with a carton outer, loaded close to Shanghai and Qingdao seaports.
How It Compares With Our Other Lines
| Product | Key specification | Best suited to |
|---|---|---|
| Cross Pattern EVA Foam Mat | Cross-embossed grip, solid colour, 70-75 kg/m3 | General training and yoga floors |
| Rubber EVA Foam Mat | Rubber-blended surface, 80 kg/m3, Shore A 38-45 | Weight areas and heavy equipment |
| Tatami Mats | Tatami texture, 100x100 cm, 80 kg/m3 | Judo, jiu-jitsu and throwing practice |
Laying and Maintaining the Floor
Let the tiles rest flat at room temperature before laying, so they relax after transport.
Start in one corner and work along two walls, pressing the puzzle teeth together by hand.
Trim the last row with a utility knife and a straight edge.
Fit the straight border strips to hide the puzzle teeth at the room edge.
Clean with a damp mop and a mild detergent. Do not use solvents.
Sectors This Mat Is Specified For
Guides Related to This Product
EVA vs PVC Floor Mats
When buyers source interlocking foam mats for gyms, playrooms, workshops or retail resale, the first question is usually: EVA, PVC or XPE? Each material has a...
Read the guide →
Custom Logo EVA Foam Mats
Gyms want their logo in the center of the floor. Schools want house colors. Brands want a mat that carries their identity into every photo. Custom logo EVA foam...
Read the guide →Wholesale EVA Foam Mats From China
Importing EVA foam mats at wholesale is straightforward once you understand how factories quote, what actually drives the price, and where first-time buyers lose...
Read the guide →Related Products
Five Stripes EVA Foam Mat
Five-Stripe Textured Floor Tiles for Commercial Gyms and Dance Studios
View specifications →
Pool Grid EVA Foam Mat
Open-Grid Drainage Mats for Pool Surrounds Showers and Wet Rooms
View specifications →
Wood Grain EVA Foam Mat
Printed Wood-Grain Foam Tiles for Interiors Showrooms and Event Floors
View specifications →Cross Pattern EVA Foam Mat - Buyer Questions
What thicknesses can I order?
Thickness runs from 1 cm to 4 cm and is customizable. Thinner tiles suit yoga and general training; thicker tiles suit ground work and impact areas.
Can you make the tiles in our brand colours?
Yes. Custom sizes, thicknesses, colours, patterns and packaging are all available under our OEM and ODM programme.
Are the mats tested for safety?
Our mats are tested by TUV against REACH and EN71, and the factory is audited under BSCI and certified to ISO 9001 and ISO 14001.
How do I check the quality before placing a bulk order?
We send samples by express with freight collect, and the courier charge is refunded on your first bulk order.
How long does production take?
Regular orders are delivered within 30 days. We ship up to 150x40'HQ containers per month from Shanghai or Qingdao.
Get a Quote on the Cross Pattern EVA Foam Mat
Send the size, thickness, colour, packaging and quantity. We reply within 24 hours, Monday to Saturday, and samples go by express with the courier charge refunded on your first bulk order.
