AHD HDD SD 1080P 6 Channel Mobile DVR
- H.264 video compression, multi code stream
- Support 6CH 1080P /720P HD real-time video inputs
- 8-36V wide voltage power supply, super low power consumption
- Support a 2T 2.5 -inch HDD and 1 256G SD card storage
OEM and ODM available on this model: branding, firmware, cable length and housing changes are handled by our own engineers.
Specifications
| Video Rate PAL | 100 fps,CCIR625line,50 scenes |
|---|---|
| NTSC | 120 fps,CCIR525line,60 scenes |
| CIF | 256Kbps - 1.5Mbps,8 grades image quality for optional |
| HD1 | 600Kbps - 2.5Mbps,8 grades image quality for optional |
| D1 | 800Kbps - 3Mbps,8 grades image quality for optional |
| 720P | 800Kbps - 4Mbps,8 grades image quality for optional |
| 1080P | 2Mbps-6Mbps,8 grades image quality for optional |
| Power and Consumption Input Voltage DC | +8V - +36V |
Product description for Ahd hdd 1080P 6channel mobile dvr in cctv dvr for school bus security.
Features:
1. H.264 video compression, multi code stream.
2. Support 6CH 1080P /720P HD real-time video inputs. Also, support 6CH analog cameras inputs or compound inputs for 4CH HD cameras and 2CH analog cameras.
3. 1CH VGA output is optional.
4. With exclusive pre-allocated type vehicle file system technology, it solved the file fragmentation problems which caused by overwrite, SD card data loss and SD card couldn’t be found, keep the data completed and stable.
5. 8-36V wide voltage power supply, super low power consumption. With overload/ undervoltage/ shortcircuit/ reversing protection, support all vehicles.
6. Support a 2T 2.5 -inch HDD and 1 256G SD card storage
7. With watchdog abnormal restart protection function, it can better protect the machine and video.
8. Delayed video recording functions when vehicle is shut down (time settings can be up to 24 hours).
9. Various video recording modes to meet different demands, such as automatic recording, manual recording, alarm recording, etc.
10. Support 4CH alarming inputs and 1CH independent alarm input.
11. Optional for 1CH RS232 Serial port or 1CH RS485 extension.
12. Support ministry of communications agreement, support SMS remote configuration and equipment control.
