Automotive Stereo Wire Harness Kit Looms

A stereo wire harness kit loom for vehicle audio fitting, supplied as a short connection loom between the vehicle side and the head unit. The 15 cm build keeps the join tight behind the dash rather than leaving a coil of cable.

15 cm build keeps the connection compact behind the dash aperture
Kit form supplies the fitter with the full connection in one part
Colour-coded circuits follow standard audio wiring conventions
Consistent factory crimps rather than workshop bullet joints

Samples ship within 3 days of confirmation. Bulk lead time is typically 7 to 12 days.

Problems It Solves

Long adapter looms will not fold behind a shallow dash aperture
Bullet joints buzz and work loose behind the head unit
Uncoded wiring slows every install and invites polarity mistakes

Who It Is For

Car audio distributors
Installation workshops
Accessory kit packers

Application Scenarios

Head unit replacement programmes
Audio fitting kits sold through distribution
Vehicle accessory installation bays

Technical Features

Stereo connection loom
15 cm length
Colour-coded audio circuits
Kit packaging

Specifications

Application	Vehicle audio head unit fitting
Length	15 cm
Format	Harness kit loom

Values shown are the standard build. Connector family, conductor gauge, circuit count and finished length are all build options.

Quality Control And Certification

Continuity And Circuit Verification. Verifies the physical arrangement sequence of the harness terminals and the circuit topology between them
Circuit Configuration Verification. Confirms that a complete, uninterrupted current flow path exists within each circuit
Terminal Retention Strength Test. Measures the mechanical reliability of the connection between the terminal and the wire
Ingress Protection Rating Test. Evaluates the dust and water resistance sealing performance of harness connectors

The company is certified to IATF 16949 and UL standards. Samples are confirmed prior to trial or mass production, and the approved sample is the reference for every repeat order.

Customization Options

Connector family and terminal type to your part numbers
Conductor gauge selected from the current per circuit
Finished length and breakout positions to your drawing
Jacket colour, marking and labelling to your scheme
Packing to your instruction, PE bag and carton as standard

Compared With The Alternatives

Long adapter leads

A 15 cm loom folds into shallow dash apertures

Bare wire adapters

Pre-terminated connectors remove the joint that usually buzzes

Use Guide

Disconnect the battery before working behind the dash
Check speaker polarity before refitting the trim
Do not force excess cable behind the unit, it loads the connector bodies

Other Assemblies In Automotive Wiring Harness

ISO Radio Wire Harness Adapter For European Vehicles - Garfour view 1

Automotive Wiring Harness ISO Radio Wire Harness Adapter For European VehiclesISO female radio adapter for Mercedes BMW Audi VW Toyota and Kia stereo systems View Specifications

ISO Standard Amplifier Harness For Automotive Stereo - Garfour view 1

Automotive Wiring Harness ISO Standard Amplifier Harness For Automotive StereoISO standard amplifier harness for car stereo and audio video systems View Specifications

Custom Automotive Wire Harness With Insulated Copper Cable - Garfour view 1

Automotive Wiring Harness Custom Automotive Wire Harness With Insulated Copper CableBuild to print automotive harness assembly in insulated copper cable View Specifications

Car Stereo ISO Amplifier Board Wire Harness - Garfour view 1

Automotive Wiring Harness Car Stereo ISO Amplifier Board Wire HarnessISO amplifier board harness for aftermarket car audio installs View Specifications

Guides That Cover This Build

Buying Guide

How To Specify A Custom Wire Harness For Quotation

What a harness manufacturer actually needs from you before a quotation means anything, and what happens when those details are missing.

Process Guide

Four Tests That Decide Whether A Wire Harness Is Sound

Continuity, circuit configuration, terminal retention and ingress protection, and what each one catches that the others do not.

Buying Guide

What To Check Before Ordering A Standalone Engine Harness

Crank reluctor generation, throttle type and transmission control decide whether a standalone loom will run your engine at all.

Automotive Stereo Wire Harness Kit Looms FAQ

Which vehicles does this suit?

Tell us the vehicle and the head unit and we confirm the matching connector set.

Can you make longer looms?

Yes. 15 cm is this build, and other lengths are made to order.

Where is the factory and can we visit?

Our factory is in Humen Town, Dongguan City, Guangdong Province, a 30 minute drive from Shenzhen International Airport. We welcome visits at any time.

Which markets do you already supply?

We take on client projects each year from the United States, the United Kingdom, Germany, France, Mexico and Japan, with the United States as our core market.

Do you accept small batch orders of Automotive Stereo Wire Harness Kit Looms?

Yes. Small batch orders are accepted and quoted case by case. Our production lines are set up for small batch, multiple variety work rather than only long runs.

Get A Price On Automotive Stereo Wire Harness Kit Looms

Tell us the quantity, the finished length and any change to the connector set. We come back with the price, the lead time and a sample plan.
