Dump Trailers
Tri Axles 40-60 Tons Tipper Semi Trailer
- UseTruckTrailer
- Size8500*2500*1800mm
- ColorOption
Dump Trailers
Low Price Good Quality Rear Dump Tipper Semi Trailer for Sale Dump Trailer
A 3-axle rear dump tipper semi trailer with a 40-60 ton payload capacity, built on a steel Q345 B frame and fitted with a 13-ton Fuwa brand axle set. The 8500 x 2500 x 1800mm cargo bed uses leaf spring suspension and ABS braking, with optional 1200R20 or 12R22.5 tyres. It is designed for bulk material transport in mining, construction and quarry operations where reliable dumping and high load capacity are required.
- Use TruckTrailer
- Size 8500*2500*1800mm
- Color Option
- Suspension LeafSpringSuspension
- Dimensions 8500*2500*1800mm
Stock number held for this listing: 10386
Key Benefits
What This Unit Does Well
- 13-ton Fuwa brand axles are standard on this model, reducing the risk of axle failure under heavy loads
- Leaf spring suspension provides durability on rough terrain and low maintenance compared to air suspension
- ABS braking system improves safety during dumping cycles and on wet or uneven surfaces
- 3-axle configuration spreads load evenly across the chassis, reducing ground pressure and road wear
- 8500mm bed length allows full use of truck trailer coupling range and maximises payload per trip
- ISO CCC certification ensures compliance with export standards in markets requiring third-party verification
Application Scenarios
Where It Is Used
- Coal transport from a mine to a rail loading point on unpaved access roads
- Aggregate hauling between a quarry and a construction site with frequent dumping cycles
- Sand and gravel delivery to roadworks where the trailer must dump quickly and reliably
- Bulk material transport in regions with poor road infrastructure and limited access to repair services
Fit
Who It Is For
- Contractors sourcing dump trailers for mining or quarry operations with tight budget constraints
- Fleet operators replacing older trailers and needing a consistent, low-maintenance model
- Machinery dealers stocking trailers for resale in African, Middle Eastern and Southeast Asian markets
- Government procurement teams requiring certified trailers for infrastructure projects with fixed budgets
Buyer Pain
Problems It Solves
- Trailer breakdowns caused by undersized axles or weak suspension under repeated heavy loads
- Lack of spare parts availability when using non-standard or unbranded axles
- Inconsistent dumping performance due to weak hydraulic systems or untested lift mechanisms
- Export delays caused by missing certification documents or non-compliant materials
- High maintenance costs from using trailers with incompatible or poorly integrated braking systems
Engineering
Technical Features
- Steel Q345 B frame with welded construction for high load-bearing strength
- 3-axle configuration with 13-ton Fuwa brand axles, each with 1200R20 or 12R22.5 tyres
- Leaf spring suspension system for durability and low upkeep on rough terrain
- ABS braking system on all axles to prevent wheel lock during emergency stops
- Rear dump mechanism with hydraulic lift cylinder for controlled and consistent dumping
- Cargo bed dimensions of 8500 x 2500 x 1800mm with reinforced sides and floor for bulk materials
- ISO CCC certification for export compliance in regulated markets
Specification
Specification Table for This Listing
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Use | TruckTrailer |
|---|---|
| Size | 8500*2500*1800mm |
| Color | Option |
| Suspension | LeafSpringSuspension |
| Dimensions | 8500*2500*1800mm |
| Material | Steel |
| Certification | ISOCCC |
| Axle | 13TonFuwaBrand |
| Tyre | 1200R20or12R22.5 |
| Function | DumpSemiTrailer |
| Type | Semi-Trailer |
| Trailer Type | Semi-Trailer |
| Dimensions L x W x H | 8500 x 2500 x 1800 mm |
| Max Payload Capacity | 40-60 Tons |
| Axle Number | 3 |
| Axle Type | 13 Ton Fuwa Brand |
| Brake System | ABS |
| Tyre Size | 1200R20 or 12R22.5 |
| Loading Capacity | 40-60 Tons |
| Place of Origin | Shandong, China (Mainland) |
| OEM Number | 2018101701 |
| Max Payload | 40-60 |
| Tons Place of Origin | Shandong, China (Mainland) |
| Product Name | Cheap Good Quality Rear Dump Tipper Semi |
| Trailer for Sale Axle | 13 |
| Ton Fuwa Brand Function | Dump |
Materials
Materials and Build
- Steel Q345 B for the main frame and cargo bed structure
- Cast steel axles with standard 13-ton load rating
- Leaf springs made from high-tensile steel for long service life
- 1200R20 or 12R22.5 radial tyres on steel rims
- Hydraulic lift cylinder with welded mounting brackets
Process
How an Order Is Handled
- You provide the intended use, payload, and destination country
- We confirm the available stock or build-to-order schedule based on current production
- You approve the final specification including axle, tyre, colour and dumping mechanism
- The trailer is assembled, tested for hydraulic function and inspected before loading
- We arrange bulk or container shipping with a partner agency and issue export documents
Quality Control
Checks Before Loading
- All axles, tyres and suspension components are inspected upon receipt from suppliers
- Welding joints are checked with visual and non-destructive methods before final assembly
- Hydraulic lift system tested under full load before shipping
- ABS system tested for signal integrity and brake response
- Final trailer photographed and video recorded before loading, with full documentation sent
Customisation
What Can Be Changed
- Choice of trailer colour (white, yellow, red, or custom RAL code)
- Tyre size: 1200R20 or 12R22.5, with optional spare wheel
- Adjustment of dump angle or lift cylinder position for site-specific dumping
- Addition of side or rear guards for material containment
- Optional fifth wheel plate or coupling upgrade for compatibility with specific tractor heads
Honest Comparison
How It Compares With the Alternatives
| 2-axle dump trailer | The 3-axle model handles heavier loads without exceeding axle weight limits, but adds cost and weight |
|---|---|
| Air suspension trailer | Leaf spring suspension is more robust and cheaper to maintain in dusty or rough environments |
| Non-branded axle trailer | Fuwa brand axles have consistent quality and spare parts availability, reducing downtime risk |
Use Guide
Using It Well
- Inspect hydraulic hoses and connections before first use; replace any damaged seals
- Check tyre pressure weekly and adjust for load and terrain conditions
- Test the ABS system monthly by driving at low speed and applying brakes firmly
- Keep the dump bed clean after each use to prevent material buildup and corrosion
Photographs
More Views of This Unit
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
Source Specification
Manufacturer Text We Hold for This Listing
Low Price Good Quality Rear Dump Tipper Semi Trailer For Sale Dump Trailer Cheap Good Quality Rear Dump Tipper Semi Trailer For Sale Product Information Product Name Cheap Good Quality Rear Dump Tipper Semi Trailer For Sale Type Semi-Trailer Material Steel Q345 B Certificate ISO CCC Size 8500*2550*1800mm Max Loading Capacity 40-60 Tons Brand Sea Lion Function Dump Semi Trailer Axle 13 Ton Fuwa Brand Axle Number 3 Axles Brake System ABS Tyre 1200R20 or 12R22.5 Origin Shandong, China Suspension Leaf Spring Suspension Accessories Show More Choice Packing & Delivery About Us The factory covers an area of 14,500 square meters, including the plant area of 11,300 square meters, the warehouse area of 900 square meters, and the supporting construction area of 1,200 square meters. We have 160 units advanced large scale equipment, and more than 50 units testing machines. With strong technical force
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
Related Listings
Other Dump Trailers Buyers Compare With This
Dump Trailers
China Made 3 Axles 40-60 Tons Side Dump Semi Trailer for Sale
- UseTruckTrailer
- Size8500*2500*1800mm
- ColorOption
Dump Trailers
China Made 3 Axles 60 Ton Rear Dump Semi Trailer for Sale
- UseTruckTrailer
- Size8500*2500*1800mm
- ColorOption
Dump Trailers
Tri Axles Rear Tipper Semi Trailer Dump Semi Trailer
- UseTruckTrailer
- Size8500*2500*1800mm
- ColorOption
Dump Trailers
Best Quality Best Price 2 Axles / 3 Axles Heavy Duty 40-60 Tons Tipper Trailer
- UseTruckTrailer
- Size13000*2550*1500mm
- ColorOption
Dump Trailers
3 Axle 35/40 CBM Tipper Trailer 60 Tons Dump Semi Trailer for Sale
- UseTruckTrailer
- Size13000*2550*1500mm
- ColorOption
Buyer Questions
Questions About This Unit
Is this trailer new or used
All trailers are new. We do not supply used or reconditioned units. Each trailer is built to order or from current stock.
What is the lead time
15 workdays after prepayment is received. This includes production, testing and preparation for shipment.
Can you supply spare parts later
Yes. We supply Fuwa brand axles, tyres, hydraulic cylinders and ABS components as spare parts. They can be shipped separately or with the trailer.
Do you ship by container or bulk
We ship by bulk for standard trailers. Container shipment is possible but requires lowering the cab or modifying the frame. We quote both options.
What documents do I get for customs
Commercial invoice, packing list, bill of lading, certificate of origin, and ISO CCC certificate are included. Additional inspection certificates can be arranged.
Price This Unit Against Your Port
Send the destination and quantity. A written specification, landed cost and shipping option comes back.
