Electric Trucks
4 Kw Electric Mini Truck/ Pickup with Ce
- ConditionNew
- OthersHeadinglight
- SteeringLeft
Electric Trucks
Chinese 2 Seats Electric Mini Pickup Truck for Sale
A 2-seat electric mini pickup truck with unitary construction body, 72V AC motor rated at 5.0KW and 800W continuous output, designed for short-haul cargo transport in urban and rural environments. The FUDE-B model has a 2400mm wheelbase, 165/70R13 tyres, 1000kg curb weight, 1000kg rated load, and 60km endurance in summer conditions. It is certified under CCC and built for low-speed, low-mileage operations where charging infrastructure is basic.
- Size 4000*1600*1800mm
- Seats 2
- Certification CCC
- Tyre 165/70R13
- Tread 1270mm/1340mm
Stock number held for this listing: 11520
Key Benefits
What This Unit Does Well
- 72V AC motor delivers consistent torque for hill starts and light loading on uneven roads
- Unitary construction body reduces assembly complexity and improves structural rigidity
- 165/70R13 tyres offer a balance between ground clearance and rolling resistance
- 1000kg rated load allows for standard delivery box or small tool container transport
- 8-12 hour charge time fits into overnight charging cycles at depot or warehouse
- CCC certification enables registration in markets requiring Chinese vehicle compliance
Application Scenarios
Where It Is Used
- Daily delivery of spare parts and tools within a factory compound or industrial park
- Short-distance cargo transport between a warehouse and a local market on unpaved access roads
- Last-mile delivery of small packages in urban areas with low speed limits and limited parking
- Utility transport for maintenance crews in mining or construction sites with low-speed zones
Fit
Who It Is For
- Fleet managers replacing petrol-powered micro trucks in low-speed delivery operations
- Contractors needing a compact electric vehicle for site logistics without full vehicle registration
- Parts distributors stocking small electric cargo vehicles for resale in Southeast Asia and Africa
- Government agencies procuring low-emission vehicles for municipal utility or inspection duties
Buyer Pain
Problems It Solves
- High fuel and maintenance cost of small petrol trucks in short-haul urban routes
- Lack of reliable charging points for larger electric vehicles in remote or underdeveloped areas
- Inconsistent part availability for imported micro trucks due to fragmented supply chains
- Difficulty in registering imported small electric vehicles without local certification
Engineering
Technical Features
- Unitary construction body with integrated frame and body shell
- AC 72V 5.0KW motor with continuous output >800W
- Lead acid battery pack: 6 x 12V/150AH (39.5KG total)
- Front disc brake and rear drum brake system with 5m stopping distance
- MacPherson front suspension and plate spring rear suspension
- 2400mm wheelbase with 1270mm front and 1340mm rear tread
- 150mm minimum ground clearance for minor obstacles and uneven terrain
- 35km/h maximum speed suitable for urban and site access roads
- 4500 x 1600 x 1800mm overall dimensions with 3000 x 1600 x 360mm cargo container space
Specification
Specification Table for This Listing
Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.
| Size | 4000*1600*1800mm |
|---|---|
| Seats | 2 |
| Certification | CCC |
| Tyre | 165/70R13 |
| Tread | 1270mm/1340mm |
| Voltage | 72V |
| Power | >800W |
| Model Number | FUDE-B |
| Body Type | Closed |
| Chassis Type | Unitary construction body |
| Overall Dimensions L x W x H | 4500 x 1600 x 1800 mm |
| Wheelbase | 2400 mm |
| Front Tread | 1270 mm |
| Rear Tread | 1340 mm |
| Min Ground Clearance | 150 mm |
| Curb Weight | 1000 kg |
| Rated Load Weight | 1000 kg |
| Max Speed | 35 km/h |
| Motor Power | 5.0 KW (AC) |
| Continuous Output | >800 W |
| Battery Type | Lead acid |
| Battery Capacity | 6 x 12V/150AH |
| Battery Weight | 39.5 KG |
| Charge Time | 8-12 hours |
| Endurance Mileage (Summer) | ≥60 KM |
| Climbing Capacity | <20% |
Materials
Materials and Build
- Galvanised steel body panels with factory paint finish
- Cast steel front and rear axle components
- Lead acid battery cells with sealed casing
- Steel frame and mounting brackets for motor and battery
- Rubber bushings in suspension system
- Plastic trim and interior panels for cabin
Process
How an Order Is Handled
- You confirm the intended use, load type, and operating environment
- We provide the current stock list with chassis numbers and battery condition
- You select the configuration and confirm the final spec sheet including colour and tyre
- We prepare the unit, photograph and video record the battery and motor connections
- We book container shipment and issue export documents including commercial invoice and COO
Quality Control
Checks Before Loading
- Battery voltage and capacity are measured before loading and recorded
- Motor and brake system are tested under load before shipment
- Chassis and body are inspected for shipping damage at the loading port
- All electrical connections are checked for corrosion and tightness
Customisation
What Can Be Changed
- Cab colour other than standard white or grey
- Tyre brand and size change within 165/70R13 specification
- Battery pack upgrade to higher capacity (if available in stock)
- Cargo container modification for different internal dimensions
- Installation of additional lighting or mounting brackets for tools
Honest Comparison
How It Compares With the Alternatives
| Gasoline-powered mini pickup | Lower operating cost and no fuel storage risk, but limited range and slower acceleration |
|---|---|
| Larger electric cargo van | Smaller footprint and lower purchase price, but less cargo space and no air conditioning |
| Higher speed electric quadricycle | Lower speed reduces accident risk in urban zones, but not suitable for highway use |
Use Guide
Using It Well
- Charge the battery fully before first use and avoid deep discharge below 20%
- Check battery water levels monthly if maintenance-free is not confirmed
- Inspect brake pads and tyre pressure every 1000km or monthly
- Use only the supplied charger to prevent battery damage
- Store the vehicle in a dry, shaded area to extend battery life
Photographs
More Views of This Unit
Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.
Source Specification
Manufacturer Text We Hold for This Listing
Chinese 2 seats electric mini pickup truck for sale Product Description Chassis type Unitary construction body Container dimension 3000*1600*360mm Endurance mileage (summer) ≥60KM Climbing capicity <20% Radius of turn circle <5m seats 2 Wheel base 2400mm Brake distant 5m Front tread 1270mm Tyre 165/70R13 Front suspension type MacPhersan type Rear tread 1340mm Min ground clearance 150mm Rear suspension type Plate spring Motor AC72V5.0KW Curb weight 1000kg Battery Lead acid battery 6*12V/150AH (39.5KG) Rate load weight 1000kg Max speed 35KM/H Brake type Front disc/ Rear drum Overall dimension 4500*1600*1800mm Charge time 8-12H Detailed Images Company Information Our company officially establised in 2013, is a comprehensive enterprise devoting himself to the new energy electric quadricycle and electric tricycle' s technology research and development, manufacturing, and marketing services. T
Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
