Dump Trailers

Cheap Good Quality Rear Dump Tipper Semi Trailer for Sale

A 3-axle rear dump semi-trailer with a 8500 x 2500 x 1800mm steel frame, built for 40-60 ton payload capacity. It uses a 13-ton Fuwa-brand axle on leaf spring suspension, 1200R20 or 12R22.5 tyres, and features an ABS brake system. The trailer is designed for bulk material transport where frequent dumping and rugged terrain are expected, with ISO CCC certification and a standardised design for fast export clearance.

Use TruckTrailer
Size 8500*2500*1800mm
Color Option
Suspension LeafSpringSuspension
Dimensions 8500*2500*1800mm

Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 10387

Rear dump semi trailer in white, parked on a yard, front three-quarter view showing 13-ton axles and leaf springs

Key Benefits

What This Unit Does Well

13-ton Fuwa axles are widely available in Asian and African markets, reducing spare part lead time
Leaf spring suspension handles rough terrain and heavy loads without frequent maintenance
ABS brake system improves stopping safety on wet or uneven surfaces
3-axle layout spreads weight across the road surface, meeting regional axle load limits
8500mm length fits standard container shipping and port yard manoeuvring
ISO CCC certification supports customs clearance in most export markets

Application Scenarios

Where It Is Used

Coal transport from mine to rail yard on unpaved access roads with frequent dumping
Aggregate hauling between quarry and construction site where road conditions are poor
Bulk cement or gravel delivery in African and Middle Eastern markets with limited repair infrastructure
Long-haul haulage of sand or stone where trailer must dump at multiple sites without return transport

Fit

Who It Is For

Contractors needing a low-cost, high-capacity dump trailer for short-haul site work
Fleet operators replacing older trailers and seeking a standardised model with shared parts
Machinery dealers stocking semi-trailers for resale in Southeast Asia and Africa
Government procurement teams sourcing durable trailers for infrastructure projects

Buyer Pain

Problems It Solves

Trailer breakdowns caused by weak axles or poor suspension on rough terrain
Long delays in getting spare parts when using non-standard or unbranded axles
Customs rejection due to missing or invalid certification for export markets
Inconsistent trailer dimensions that complicate container loading and transport planning
High maintenance cost from poor welding or substandard material in low-cost trailers

Engineering

Technical Features

Rear dump mechanism with hydraulic lift system for controlled unloading
3-axle configuration with 13-ton Fuwa-brand axles for heavy-duty use
Leaf spring suspension system for durability on unpaved roads
ABS anti-lock braking system for improved stopping on wet or loose surfaces
Steel Q345B frame material for high tensile strength and resistance to deformation
8500 x 2500 x 1800mm external dimensions for standard container and RoRo shipping
1200R20 or 12R22.5 tyre options to match local vehicle fleet standards

Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

Specification of Cheap Good Quality Rear Dump Tipper Semi Trailer for Sale
Use	TruckTrailer
Size	850025001800mm
Color	Option
Suspension	LeafSpringSuspension
Dimensions	850025001800mm
Material	Steel
Certification	ISOCCC
Axle	13TonFuwaBrand
Tyre	1200R20or12R22.5
Function	DumpSemiTrailer
Type	Semi-Trailer
Trailer Type	Semi-Trailer
Dimensions L x W x H	8500 x 2500 x 1800 mm
Max Loading Capacity	40-60 Tons
Axle Number	3
Axle Type	13 Ton Fuwa Brand
Tyre Size	1200R20 or 12R22.5
Brake System	ABS
Place of Origin	Shandong, China (Mainland)
OEM Number	2018101701
Loading Capacity	40-60 Tons
Max Payload	40-60
Tons Place of Origin	Shandong, China (Mainland)
Product Name	Cheap Good Quality Rear Dump Tipper Semi
Trailer for Sale Axle	13
Ton Fuwa Brand Function	Dump

Materials

Materials and Build

Steel Q345B for the main frame and dump body, providing high strength and durability
Cast steel 13-ton Fuwa-brand axles for load-bearing and axle housing integrity
Leaf springs made from high-tensile steel for long service life under heavy loads
1200R20 or 12R22.5 radial tyres on steel rims for off-road and mixed surface use
Welded steel structure with full penetration welds to resist fatigue and impact

Process

How an Order Is Handled

You send your route profile, payload range, and intended trailer use
We confirm availability of the 8500 x 2500 x 1800mm configuration with 13-ton Fuwa axles
You choose tyre size (1200R20 or 12R22.5), colour, and any optional fittings
We prepare the trailer, photograph and video record the final build before loading
We book bulk or container shipment and issue export documents including COO and packing list

Quality Control

Checks Before Loading

Axles, suspension, and tyres are inspected before assembly using in-house testing machines
Weld joints are checked with visual and non-destructive methods to ensure full penetration
Hydraulic lift and dump system tested under load before final packaging
ABS system tested for signal integrity and brake response during final inspection

Customisation

What Can Be Changed

Choice of trailer colour (white, yellow, red, or custom RAL code)
Tyre size: 1200R20 or 12R22.5, with optional spare wheel and mounting kit
Additional tool box, side guards, or lighting package
Custom frame length or width within the 8500mm standard range
Optional rear bumper or side skirt for improved safety and appearance

Honest Comparison

How It Compares With the Alternatives

2-axle dump trailer	The 3-axle model handles heavier payloads and spreads weight better on weak road surfaces, but costs more to ship and maintain
Air suspension trailer	Leaf spring suspension is cheaper and more reliable in dusty or off-road environments, but offers less ride comfort on paved roads
Non-ISO CCC trailer	ISO CCC certification ensures compliance with export regulations in most markets, avoiding customs delays or rejection

Use Guide

Using It Well

Use 12R22.5 tyres if operating on paved roads with higher speeds; 1200R20 for off-road or heavy load use
Keep the ABS sensor clean and free from mud to prevent false activation during braking
Order spare tyres, axle seals, and hydraulic hoses with the trailer to avoid downtime

Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Side view of the trailer showing the 8500mm length, 1200R20 tyres, and leaf spring suspension

Rear view of the trailer with the hydraulic dump mechanism raised and mud flaps in place

Interior of the trailer bed with steel Q345B frame and reinforced corners

Close-up of the ABS brake system and axle housing on the rear axle

Source Specification

Manufacturer Text We Hold for This Listing

Cheap Good Quality Rear Dump Tipper Semi Trailer For Sale Cheap Good Quality Rear Dump Tipper Semi Trailer For Sale Product Information Product Name Cheap Good Quality Rear Dump Tipper Semi Trailer For Sale Type Semi-Trailer Material Steel Q345 B Certificate ISO CCC Size 8500*2550*1800mm Max Loading Capacity 40-60 Tons Brand Sea Lion Function Dump Semi Trailer Axle 13 Ton Fuwa Brand Axle Number 3 Axles Brake System ABS Tyre 1200R20 or 12R22.5 Origin Shandong, China Suspension Leaf Spring Suspension Accessories Show More Choice Packing & Delivery About Us The factory covers an area of 14,500 square meters, including the plant area of 11,300 square meters, the warehouse area of 900 square meters, and the supporting construction area of 1,200 square meters. We have 160 units advanced large scale equipment, and more than 50 units testing machines. With strong technical force and advanced man

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
