3 Axle 40ft China Manufacturer Rear Tipper Truck Semi Trailer

A 3 axle 40ft rear tipper semi-trailer with a 10500mm x 2500mm x 3500mm body. The chassis uses high tensile Q235 steel, and the trailer features a FUDA 13T axle with drum brakes. It is designed for 60T payloads and is suitable for construction material, mining, and aggregate transport where a robust tipping solution is needed.

Chassis optingforhightensilest
Kingpin JOSTbrand3.5"bolt-inki
Use TruckTrailer
Size 10500mm*2500mm*3500mm
Suspension Mechanicalsuspensionor

Ask for a Price on WhatsApp Email the Specification

Stock number held for this listing: 10513

Rear view of a 3 axle 40ft tipper trailer

Key Benefits

What This Unit Does Well

Q235 high tensile steel chassis offers durability for demanding construction and mining sites
FUDA 13T axles with drum brakes provide reliable stopping power for loaded transport
JOST 3.5" bolt-in king pin ensures compatibility with most tractor units
8mm floor and 6mm side walls withstand abrasive materials and repeated tipping cycles
Hydraulic system from China brand or HYVA offers lifting power for efficient unloading

Application Scenarios

Where It Is Used

Transporting aggregates from a quarry to a construction site
Hauling mining ore and overburden on steep grades
Delivering bulk cement to a concrete plant
Moving demolition debris from a site to a recycling facility
Transporting road construction materials like asphalt and gravel

Fit

Who It Is For

Construction companies needing to move materials between sites
Mining operations requiring a robust tipper trailer
Aggregate suppliers delivering materials to customers
Logistics companies specialising in bulk material transport
Rental companies providing trailers to construction and mining contractors

Buyer Pain

Problems It Solves

Damage to trailers from abrasive materials and rough terrain
Downtime caused by unreliable tipping mechanisms
Difficulty finding compatible king pins for different tractor units
High maintenance costs associated with low-quality trailers
Inability to efficiently unload materials at the delivery site

Engineering

Technical Features

Heavy-duty I-beam chassis constructed from Q235 high tensile steel
Three FUDA 13T axles with drum brakes for reliable stopping power
Mechanical or Air suspension options to suit road conditions
Hydraulic system with 214 oil cylinder for tipping operation
JOST 3.5" bolt-in king pin for universal tractor compatibility
WABCO RE6 relay valve and ABS KEMI 4S/2M braking system

Specification

Specification Table for This Listing

Taken from the supplier specification we hold. Anything not listed here is confirmed in writing before order rather than assumed.

Specification of 3 Axle 40ft China Manufacturer Rear Tipper Truck Semi Trailer
Chassis	optingforhightensilesteelQ235
Kingpin	JOSTbrand3.5"bolt-inkingpin90#
Use	TruckTrailer
Size	10500mm2500mm3500mm
Suspension	MechanicalsuspensionorAirsuspension
Material	Steel
Certification	CCC,ISO9001,BV
Axle	3axleFUDAbrand13T(B2)(16TDrumbrake)
Type	Semi-Trailer
Trailer Type	Semi-Trailer
Dimensions L x W x H	10500mm2500mm3500mm
Payload	60T
Chassis Material	Q235 Steel
Hydraulic System	China brand or HYVA
Braking System	WABCO RE6 relay valve; ABS KEMI 4S/2M
Wheel Rim	8.0-20 China brand
SEA Lion Max Payload	60T
Place of Origin	Shandong,
China (Mainland) Axle	3 axle FUDA brand 13T (B2) (16T
Drum Brake) Chassis	opting for high tensile steel Q235
Air Suspension Kingpin	JOST brand 3.5′′ bolt-in king pin 90#

Materials

Materials and Build

High tensile steel Q235 for the chassis construction
Steel floor plate 8mm thick for durability
Steel side walls 6mm thick for load containment
Cast steel FUDA axle components

Process

How an Order Is Handled

You specify the material to be hauled and the route profile
We confirm the axle configuration and suspension type based on your needs
You approve the final specification sheet including the hydraulic system brand
The trailer is prepared, photographed and video recorded before loading
We arrange shipment and provide export documents for customs clearance

Quality Control

Checks Before Loading

Chassis serial number and axle codes are verified against your order
Hydraulic system operation is tested before loading
Paint finish and weld quality are inspected for defects
Loading and lashing are documented with photographs before departure

Customisation

What Can Be Changed

Hydraulic system brand (China brand or HYVA)
Suspension type (Mechanical or Air)
Tyre brand and quantity
Landing gear type
Painting colour and logo application

Honest Comparison

How It Compares With the Alternatives

2 axle tipper trailer	The 3 axle distributes weight better for heavier loads and improves stability
Air suspension	Mechanical suspension is lower cost and simpler to maintain, but air suspension offers a smoother ride
HYVA hydraulic system	China brand hydraulic systems are more economical, but HYVA is a recognised premium brand

Use Guide

Using It Well

Grease the wheel bearings and kingpin regularly
Inspect the tyre pressure before each trip
Check the hydraulic lines for leaks and damage
Ensure the load is evenly distributed within the trailer
Follow the manufacturer's recommended maintenance schedule

Photographs

More Views of This Unit

Photographs held for this listing. Current yard photographs of the specific unit you shortlist are taken fresh before any balance is paid.

Side view of the tipper trailer showing the hydraulic cylinder

Close-up of the FUDA axle and drum brakes

The chassis construction of the tipper trailer

Front view of the trailer with the kingpin

The hydraulic system of the tipper trailer

Source Specification

Manufacturer Text We Hold for This Listing

3 axle 40ft China Manufacturer Rear Tipper Truck Semi Trailer DIMENSIONS Size 10500 mm*2500mm* 35 00mm Capacity (m3) 50m3 Payload 60T Chassis Heavy duty and extra durability designed I beam; opting for high tensile steel Q235, welded by automatic submerged-Arc processes. Top flange 18mm,width140mm;Middle Flange 14mm height 500mm;bottom flange20mm,width 140mm Axle 3 axle FU DA brand 13T (B2) (16T Drum brake) Suspension Mechanical suspension china brand Leaf spring Leaf spring 12 pcs Thicken spring 13mm F loor 8mm plate.side wall 6mm Tire 11.00 R20 Triangle brand 13 pcs (with one spar tire) Wheel rim 8.0-20 China brand 13 pcs Kingpin JOST brand 3.5 " bolt-in king pin 90# Hydraulic system 214 oil cylinder(8130 length) China brand or HYVA Landing gear JOST brand two-speed, manual operating,heavy duty landing gear 2 8 T Braking system WABCO RE6 relay valve;T30/30 spring brake chamber;40L air

Reproduced from the supplier specification. Figures are confirmed in writing on the proforma invoice before any deposit.
