Solar Panel Z Mount 100 mm Set of 4
Four 100 mm aluminium Z-bracket feet with stainless hardware — universal fit for any aluminium-framed panel.
- Universal fit — any solar electric panel with an aluminium frame
- 100 mm height gives generous airflow and working clearance
- Aluminium mounts with stainless hardware included for the panel side
- Simple design that is quick to fit and needs no maintenance
Product overview
What It Is and What It Does
A set of four Z-bracket type mounting feet at 100 mm, universal in the real sense: they fit any solar electric panel with an aluminium frame, and the hardware for fastening the mounts to the panel is included. Designed for caravans and motorhomes, but equally at home on other surfaces.
The taller 100 mm foot buys you airflow and clearance. On a curved or ribbed roof it also gives you room to get a spanner in, which matters more than it sounds when you are working single-handed on a roof. The kit will fit virtually any framed solar panel including BP, Suntech Power, GE and Kyocera panels.
Who it is for
- Caravan and motorhome owners wanting maximum airflow under the panel
- Installers working on ribbed or curved roofs that need clearance
- Cabin, shed and outbuilding installations on timber or metal
- Retailers needing one bracket set that fits almost any framed panel
Problems it solves
- Low-profile mounts leave no room to work on a ribbed or curved roof
- Panels mounted tight to a surface run hot and lose yield
- Brand-specific brackets strand a distributor with dead stock
- Plated steel brackets rust out in coastal and road-salt conditions
Key benefits and features
Why Buyers Choose BS09002-100
Benefits
- Universal fit — any solar electric panel with an aluminium frame
- 100 mm height gives generous airflow and working clearance
- Aluminium mounts with stainless hardware included for the panel side
- Simple design that is quick to fit and needs no maintenance
Technical features
- Set of 4 aluminium Z-bracket mounting feet, 100 mm
- Hardware included for fastening the mounts to the solar panel
- Fits BP, Suntech Power, GE, Kyocera and other framed panels
- Made of aluminium with stainless steel screws
- Designed for caravans and motorhomes, usable on other surfaces
- Maintenance free and easy to install
| Product number | BS09002 |
|---|---|
| Height | 100 mm |
| Set contents | 4 Z mounts |
| Material | Aluminium with stainless steel screws |
| Hardware included | Fixings for attaching mounts to the panel |
| Panel compatibility | Any panel with an aluminium frame, including BP, Suntech Power, GE and Kyocera |
| Maintenance | Maintenance free |
| Applications | Caravan, motorhome, RV flush mounting and other surfaces |
| Not included | Surface fasteners and roof sealant |
Materials and manufacture
What It Is Made From
Aluminium with stainless steel screws. Anodised aluminium against an anodised panel frame with stainless fasteners is the standard combination for outdoor mounting hardware, and it is why these brackets can sit on a roof for years without attention.
Quality and certification
Everything in the BS09002-100 table above is taken from our own product documentation — a 100 mm foot and 4 Z mounts. Nothing on this page is estimated or rounded up to make a better headline. If a tender needs a written certification or test statement, tell us which standard it names and we will say what we can supply.
Customisation
For a different pack quantity, a printed carton, or z-style brackets under your own label, tell us the annual volume you are planning and we will come back on what is possible and what it changes on price.
Comparison
How It Compares
Against the 38 mm Z mount
Same family. 100 mm for airflow and access, 38 mm for a low, tidy profile.
Against the L-feet packs
L feet are simpler and cheaper per panel; the Z foot gives more height and a more even load path across the frame.
Against ABS bonded mounts
The ABS route avoids drilling entirely. Choose Z feet when the surface can safely take a fastener.
Use guide
How to Fit It
Step 1
Attach the Z feet to the panel frame with the supplied hardware.
Step 2
Set the panel on the roof and mark the fixing positions.
Step 3
Select surface fasteners to suit the roof construction.
Step 4
Bed each foot on roof sealant and seal under the fastener heads.
Step 5
Tighten evenly and check the panel is not being twisted by an uneven roof.
Questions
Frequently Asked Questions
Which panels does it fit?
Virtually any framed solar panel with an aluminium frame, including BP, Suntech Power, GE and Kyocera modules.
Does it come with roof fixings?
No. Hardware for fastening the mounts to the panel is included; the fasteners that go into your roof are chosen to suit the surface and are not supplied.
How many sets do I need per panel?
One set of four for a small square module. For larger rectangular panels our RV guidance is six feet per module, with an extra set in the middle of the frame rail.
38 mm or 100 mm?
100 mm if you want airflow and room to work; 38 mm if you want the panel sitting as low as possible.
Related products
Often Ordered With This
BS09002-38Solar Panel Z Mount 38 mm Set of 4
A flush mounting kit of four 38 mm aluminium Z feet with stainless bolts, washers and serrated flange nuts.
View details →
BS09002Z Mount RV Solar Panel Mounts
Z-shaped aluminium feet for fixed-flat module installation on flat or curved RV roofs.
View details →
BS09003-SAluminium Solar Bracket 6 Pack
Six anodised aluminium feet with 316 stainless screws, for larger panels that need mid-rail support.
View details →
BS09002-FKSolar Panel Flush Mount Kit
A boxed set of four aluminium feet that gives a discreet flush mount for one panel on an RV, caravan or camper.
View details →Further reading
Notes and Guides for This Product
Ready to Order BS09002-100
Tell us how many BS09002-100 you need and which port they are going to. We will confirm the pack quantity for the Solar Panel Z Mount 100 mm Set of 4, quote freight and give you a lead time.
