Large Caliber Hydrogen Reduction Furnace
The Large Caliber Hydrogen Reduction Furnace is designed for sample preparation of various materials under a clean environment in a reducing atmosphere. The product utilizes a annular distributed heating uniformly positioned outside a high-purity quartz vacuum chamber, ensuring high thermal efficiency, rapid heating,...
Introduction
The Large Caliber Hydrogen Reduction Furnace is designed for sample preparation of various materials under a clean environment in a reducing atmosphere. The product utilizes a annular distributed heating uniformly positioned outside a high-purity quartz vacuum chamber, ensuring high thermal efficiency, rapid heating, and excellent temperature uniformity. The protective atmosphere circulates evenly inside, with ingress and egress for optimal performance. All sealing components feature high-temperature-resistant sealing rings, and the system employs a water-cooled stainless steel sealing system, ensuring safety and reliability.
The equipment is equipped with a comprehensive touchscreen interface for automated operation and includes alarm functions for over-temperature, disconnection, and low water pressure, enhancing user safety.
Key Features of Hydrogen Reduction Furnace
1.Double-layer insulation structure with air-cooled intermediate layer;
2. High-purity Al2O3 fiber refractory insulation material, maximizing energy savings;
3.High-purity alumina coating on the refractory furnace chamber for extended lifespan;
4.High-purity quartz furnace plug facilitates the establishment of custom temperature gradients within the tube.
5.Comprehensive over-temperature, short-circuit, and rapid cooling water protection measures for worry-free safety!
6.Temperature measurement holes and observation windows are interchangeable (selectable).
Read Our Blog for More Content
Key Equipment for Crystalline Hydrogen Reduction Processes
The Critical Role of Hydrogen Purge Reduction Furnaces in Semiconductor Material Synthesis
Advanced High-Temperature Furnaces for Hydrogen Furnace Steel Research
Specifications
Figures below are the manufacturer data for this model. Anything not listed is confirmed in writing with the quotation rather than estimated here.
| Equipment Name | Large Caliber Hydrogen Reduction Furnace |
|---|---|
| Model | VAH1200 |
| Power Supply | 220V 50Hz |
| Rated Power | 3.5KW |
| Maximum Temperature (Tmax) | 1200℃ |
| Working Temperature | RT- 1150℃ |
| Recommended Heating Rate | ≤10℃/min |
| Heating Element | Annular heating Mo-doped Fe-Cr-Al high quality alloy heating element ensures uniform and reliable temperature distribution. |
| Control System | 1. Sintering Process Curve Setting: Dynamic display of set curves. Multiple sintering process curves can be pre-stored, with each curve freely configurable. 2. Scheduled Sintering: Enables unattended operation by pre-setting the sintering process. 3. Real-time Data Monitoring & Recording: Displays and records sintering power, voltage, and other parameters. Supports data export for paperless recording. 4. Remote Operation: Allows real-time monitoring and remote control of the equipment. 5. Temperature Correction: Non-linear correction of the temperature difference between the main control temperature and the sample temperature throughout the sintering process. |
| Temperature Control Accuracy | ±1℃ |
| Sensor Type | K-type Thermocouple Φ1×500mm |
| Effective Heating Zone of Quartz Vacuum Chamber | Φ190×220mm |
| Double-layer Quartz Plate Dimensions | 110×228×5mm, 187×228×5mm Show as below(Perforated plate for a more uniform atmospheric environment): Optional quartz holder: Quartz Wafer Handling Holder |
| Sealing System | Stainless steel vacuum flange Vacuum level：5-10Pa(Mechanical Pump) |
| Gas Supply System and Pressure Measurement | Utilizing a mechanical pressure gauge with shock-absorbing oil and a high-precision float flowmeter with a small flow rate. (can customized high-precision MFC) |
| Rotameter Flow Range | 20-200ml/min |
| Furnace Dimensions | L820×H1240×D640mm |
| Weight | Approx. 110kg |
| Precautions for Use | 1. Cooling System Requirement: When conducting high-temperature sintering, a water chiller must be connected to prevent the high-temperature silicone sealing ring from melting. 2. Material Compatibility Warning: Avoid sintering materials containing alkaline ions, as they may cause crystallization damage to the chamber. |
| Service Support | Two-year limited warranty with lifetime support (The warranty does not cover consumable parts such as the quartz chamber and O-rings). |
