The Sinotruk HOWO 4 ton mini fire truck is a 4x2 light-duty fire fighting vehicle built on a HOWO chassis with a 160 HP diesel engine and 5 speed manual gearbox. It is designed for urban fire brigades, industrial sites, and remote locations where access is limited and a full-sized fire engine cannot operate. The truck carries 3000 to 4000 litres of water in a carbon steel tank and is equipped with a CB10/40 fire pump and PS40 monitor, enabling a 40 litre per second stream at 1.0 MPa. It is used for initial attack on small to medium fires in confined spaces, including residential areas, warehouses, and industrial facilities with narrow access roads.
| Chassis | HOWO (ZZ1127G4715C1), 4x2 left hand drive |
|---|---|
| Engine | YC4FA160-33, 160 HP diesel |
| Gearbox | 5 speed manual |
| Overall Size | 8700 x 2500 x 3580 mm |
| GVW Weight | 12000 kg |
| Water Tank Capacity | 3000-4000 L |
| Tank Thickness | 4/3/3 mm |
| Fire Pump | CB10/40 normal pressure |
| Water Monitor | PS40, 40 l/s, throw distance suitable for building entry |
| Cab Seat | 2+3 |
| Air Conditioner | Optional |
| Max Speed | 90 km/h |
| Tyre Specification | 10.00R20 |
| Tyre No. | 6+1 |
| Paint | Red |
| Lead Time | 30 days |
| Shipping Port | China main port |
| Payment | T/T |
| 6x4 water tender with a 10000 L tank | Carries more water but requires more space and has higher operating costs |
|---|---|
| Foam and dry powder tender | Better on flammable liquid fires but cannot sustain a water attack on solid fuel fires |
| Water tanker truck with a fire pump added | Cheaper per litre but lacks GB7965 compliant layout and integrated fire fighting systems |
Generally 30 days after the advance payment is received. The exact date depends on chassis availability and the equipment list you specify.
T/T with 30 percent as deposit and 70 percent before delivery. We send photos and videos of the finished truck before you pay the balance.
Yes. The chassis is ordered in left or right hand drive to match your traffic regulations. Confirm this at order stage because it cannot be changed later.
By Ro-ro or bulk ship from a China main port. Trade terms can be EXW FOB CFR or CIF.
The whole vehicle is guaranteed for one year and core parts on some products for two years. Our overseas engineers make regular return visits and provide technical training and manuals before delivery.
Yes. Send us your inventory list of hoses, branches, nozzles, and breathing apparatus and the lockers will be laid out to suit it.
Send us your destination port and we will quote price, lead time and freight.
