The Sinotruk Hohan 15 ton refrigerated vehicle is a 15000 kg capacity box truck built on a 4x2 chassis for transporting perishable goods at controlled temperatures. It is designed for food, meat, and pharmaceutical logistics operators in tropical and subtropical climates where temperature stability is critical during long hauls. The truck features a 280-310 HP Sinotruk Howo engine, 10-speed manual gearbox, and a fully insulated van with 80-100 mm urethane foam core. It can maintain temperatures from +20°C down to -25°C depending on the refrigeration unit installed.
| Chassis | Sinotruk Hohan 4x2 left or right hand drive |
|---|---|
| Payload Capacity | 15000 kg |
| Engine | 4-stroke direct injection, 6-cylinder in-line, turbocharged, inter-cooled, water cooled |
| Horse Power | 280-310 HP |
| Emission Standard | Euro 2/3/4/5 |
| Gearbox | 10 forward, 2 reverse |
| Clutch | Reinforced diaphragm, 430 mm diameter |
| Steering Gear | ZF 8098, power steering with hydraulic assistance |
| Fuel Tank | 300 L |
| Tires | 12.00R20, 12.00R24, 12R22.5 |
| Brakes | Dual circuit compressed air service, spring energy parking on rear wheels, engine exhaust valve auxiliary brake |
| Overall Dimensions | 9500 x 2500 x 3900 mm |
| Wheelbase | 5200 mm |
| Wheel Track | 1160/1375 mm |
| Approach Angle | 20° |
| Departure Angle | 25° |
| Van Length | 4.5 to 9.4 m as required |
| Insulation Thickness | 80 mm ester urethane |
| Inside Material | 2.2 mm FRP |
| Outside Material | Stainless steel plate |
| Floor Material | FRP, aluminium skid plate, or stainless steel skid plate |
| Refrigeration Unit | Optional domestic, imported, independent, or non-independent brand |
| Temperature Range | +20°C to -25°C |
| Lead Time | 20 days after deposit |
| Shipping Port | China main port |
| Payment | T/T |
| 10 ton reefer truck with 4x2 chassis | Lower payload and smaller capacity but better suited for narrow city streets and tight turns |
|---|---|
| Refrigerated truck with fixed 6.5 m van | Less flexible for varying load sizes and warehouse access, but lower cost per unit |
| Used reefer truck from Europe | Higher risk of mechanical failure and no local spare parts support after 5 years |
Generally 20 days after the advance payment is received. The exact time depends on refrigeration unit availability and final configuration.
Yes. The van length can be set between 4.5 and 9.4 meters to match your cargo volume and loading dock dimensions.
Options include domestic, imported, independent, and non-independent brands. We can provide a list based on your service network.
Yes. The chassis is ordered in left or right hand drive to match your local traffic regulations. Confirm this at order stage.
By Ro-ro or bulk ship from a China main port. Trade terms are EXW, FOB, CFR, or CIF.
The whole vehicle is guaranteed for one year and core parts for two years. We provide 15 years of spare parts and technical support.
Yes. Choose from FRP, aluminium skid plate, or stainless steel skid plate based on load type and wear resistance needs.
Send us your destination port and we will quote price, lead time and freight.
