Home/ All Trucks/ Sinotruk Fire Water Truck/10 wheel Sinotruk Howo 5000 gallons fire department truck Senegal

Rear pump room of the HOWO fire water tanker showing gauges and control switches

Aluminium alloy roller shutter lockers open on the side of the HOWO fire tender

Front view of the HOWO 6x4 fire department truck with 12.00R20 tyres and forward control cab

10 wheel Sinotruk Howo 5000 gallons fire department truck Senegal

Name: 10 wheel Sinotruk Howo 5000 gallons fire department truck Senegal
Brand: Sinotruk HOWO

The 10 wheel Sinotruk HOWO 5000 gallons fire department truck is a 20 cubic metre water tender built on a 6x4 HOWO chassis with a 371 HP diesel engine and 10 speed manual gearbox. It is designed for fire brigades and industrial safety teams that need to reach remote or rural fire incidents where hydrants are unavailable and must sustain a continuous water stream for at least 15 minutes. The truck is fully custom-built to meet the operational and environmental demands of fire services in West Africa, including Senegal, where road conditions are unpaved and access is limited.

Request A Quote Email Specification

Key Benefits

20 cubic metre carbon steel tank holds enough water to sustain a 60 l/s stream for over 15 minutes without refill
HOWO 6x4 heavy-duty chassis with 371 HP engine and 10 speed manual gearbox handles unpaved roads and steep gradients
Sandwich PTO allows pump and roll operation while moving, reducing response time in emergency situations
Aluminium alloy roller shutter lockers keep hoses and nozzles sealed against dust, moisture, and corrosion
Tank with 5 mm thickness and special anti-corrosion treatment extends service life in high humidity and salt-laden environments

Buyer Profile

Who It Is for

National and city fire brigades in West Africa and emerging markets
Industrial safety departments in mining, quarrying, and oil and gas operations
Government procurement agencies equipping new fire stations in remote regions
Private fire protection contractors supplying services to industrial estates
Logistics and transport operators maintaining fire response fleets for cargo depots

Operating Problems

Problems It Solves

Hydrant networks that are absent or too weak to support a continuous attack line
Small water tankers that run dry before a large fire is under control
Fixed monitors that force crews too close to radiant heat and flashover zones
Long resupply cycles when the nearest water source is more than 50 kilometres away
Imported fire trucks with spare parts and technical support arriving months after failure
Lack of local technical training and on-site support for new fire appliance operators

Where It Works

Application Scenarios

Municipal fire departments in Senegal and West Africa operating in areas with no hydrant infrastructure
Industrial parks and refineries in remote zones requiring rapid first response with sustained water delivery
Rural fire units covering large agricultural or forested areas with poor road access
Ports and construction sites where a fire must be contained before a water shuttle arrives
Emergency response fleets for mining and quarry operations in off-grid locations
National fire services procuring turnkey fire fighting vehicles under public tender

Engineering

Technical Features

Priming completes in under 50 seconds at 7 metres suction depth
Pump room mounted rear or centre with all gauges and switches on one panel
Water level indicator, overflow valve, air breather valve, and drain outlet on the tank
Carriage built from steel and aluminium embossed sheet for corrosion resistance
HOWO 6x4 chassis with 371 HP diesel engine and 10 speed manual gearbox
Dual circuit compressed air brake system with spring energy parking brake on rear wheels
ZF8098 steering system with front axle HF9 and rear axle HC16 for stability on rough terrain

Specifications

Technical Data


Chassis	SINOTRUK HOWO 6x4 left hand drive
Engine	371 HP diesel, WD615.69, Steyr technology, turbocharged and intercooled
Gearbox	10 shift manual, HW19710
Overall Size	10500 x 2500 x 3400 mm
Water Tank Capacity	20 cbm
Cab Colour	Red, tank colour and logo free of charge
Lead Time	30 days
Shipping Port	China main port
Payment	T/T
Max Speed	90 km/h
Curb Weight	12450 kg
Loading Weight	12400 kg
Wheelbase	4300+1350 mm
Approach Angle	13.5°
Departure Angle	11.5°
Tyre Size	12.00R20
Fuel Type	Diesel
Emission Standard	EURO II
Battery	2X12V/165Ah
Alternator	28V-1500kw
Starter	7.5kW/24V
Cab Type	HOWO76, all-steel forward control, 55º hydraulically tiltable

Build Materials

Materials

Aluminium embossed sheet carriage panels for corrosion resistance
Aluminium alloy roller shutter doors with sealing strip and one lock set
HOWO 6x4 heavy-duty chassis frame with Sinotruk engine and gearbox
Stainless steel available on request for water quality or storage duration requirements

How It Is Built

Manufacturing Process

Chassis is received from Sinotruk and wheelbase is confirmed against the tank drawing
Tank shell is cut, rolled, and clapboards are welded in to control surge during emergency braking
Tank is pressure tested and leak tested before leaving the welding shop
Pump pipework and sandwich PTO are fitted and aligned to the driveline
Carriage lockers, roller shutters, and monitor platform are assembled onto the subframe
Body is shot blasted, primed, and finished in fire service red
Pump flow, monitor throw, and priming time are tested on the factory apron before shipment

Testing

Quality Control

Vehicle is built to GB7965 performance requirements and test methods for fire fighting vehicles
Tank complies with GB39.5 general specification for fire fighting vehicles
Every truck is 100 percent tested before delivery
Photos and videos of the finished truck are sent to the buyer before the balance payment
Pressure and non-destructive testing available in house for pressure vessel projects

Build to Order

Customization Options

Water tank capacity can be adjusted from 20 cbm to other volumes based on customer requirement
Tank material can be changed from carbon steel to stainless steel upon request
Left or right hand drive chassis to match local traffic regulations
Tank colour and brigade logo applied free of charge
Fire fighting accessory and equipment package built to the buyer's inventory list
Manufacture to customer supplied technical drawings and specifications

Comparison

How It Compares With the Alternatives

6x4 water tender with a 12000 L tank	Carries less water and refills sooner but is easier to turn in dense city streets
Foam and dry powder tender	Better on flammable liquid fires but cannot sustain a plain water attack on a large solid fuel fire
Water tanker truck with a fire pump added	Cheaper per litre carried but has no monitor lockers or GB7965 compliant fire fighting layout

Operating Notes

Use Guide

Confirm the chassis drive configuration and hand of drive against local registration rules before order
Fill only through the manhole or the pump inlet and keep the air breather valve clear
Prime the pump at no more than 7 metres suction lift and expect draft within 50 seconds
Engage the sandwich PTO before moving if pump and roll operation is required
Drain the tank and pump after use in freezing conditions
Free operator training is available at the factory before shipment

Buyer Questions About This Truck

How long is the lead time for this fire truck?

Generally 30 days after the advance payment is received. The exact date depends on chassis availability and the equipment list you specify.

What are your payment terms?

T/T with 30 percent as deposit and 70 percent before delivery. We send photos and videos of the finished truck before you pay the balance.

Do you supply right hand drive?

Yes. The chassis is ordered in left or right hand drive to match your traffic regulations. Confirm this at order stage because it cannot be changed later.

How is the truck shipped?

By Ro-ro or bulk ship from a China main port. Trade terms can be EXW, FOB, CFR, or CIF.

What warranty and after sales support do you provide?

The whole vehicle is guaranteed for one year and core parts on some products for two years. Our overseas engineers make regular return visits and provide technical training and manuals before delivery.

Can the fire fighting equipment package be changed?

Yes. Send us your inventory list of hoses, branches, nozzles, and breathing apparatus and the lockers will be laid out to suit it.
