Fiber Flying Laser Printer

Name: Fiber Flying Laser Printer
Brand: Dotcoding

This 30W Fiber Flying Laser Printer is specifically designed for high-speed, on-line printing on beer bottle caps, PVC pipes, and rigid plastics. It features anti-counterfeiting capabilities, causes no damage to the material substrate, and is environmentally friendly and pollution-free.

Request This Model Email the model name

Product gallery

Key benefits

Published laser source: Fiber laser source.
Published power: ≥30W.
Published speed: 0- 15 0m/min.
Published weight: 28 Kg(host) / 29.2Kg(stand).
Cooling: Air cooled.
Controller: USB/Serial & Ethernet communication.

Who it is for

Food, beverage and pharmaceutical packagers coding film, bottles and cartons on a moving line
Plants that want to drop ink or ribbon consumables on high-speed conveyors

Problems it takes off the line

Inkjet dates that smear or peel in cold, wet or high-speed plants
Ribbon and solvent cost on TTO and CIJ stations
Heat damage on thin film when the wrong laser wavelength is used

Published technical points

Body material: All aluminum structure
Laser source: Fiber laser source
Power supply: 100~240V / 50~60Hz AC
Laser Power: ≥30W
Total power: ≤700W Laser wavelength: 1064nm
File format: BMP/DXF/JPEG/PLT
Marking speed: ≤ 10 000mm/s
Graphics file format: PLT format vector file input/output

Specifications from the original listing

Body material	All aluminum structure
Laser source	Fiber laser source
Power supply	100~240V / 50~60Hz AC
Laser Power	≥30W
Total power	≤700W Laser wavelength: 1064nm
File format	BMP/DXF/JPEG/PLT
Marking speed	≤ 10 000mm/s
Graphics file format	PLT format vector file input/output
Marking line width	0.0 1 -0.1mm
Peripheral interface	USB/Serial & Ethernet communication
Marking depth	0.01-0.03mm
Screen	10.2 inch HD screen Marking range: 110mm x 110 mm (Standard)
Product line speed	0- 15 0m/min
Marking accuracy	≤0.01mm
Repeat accuracy	≤0.01mm
Font type	Single-line font/double-line font/bit matrix font M arking lines: Edit freely within the marking range
Cooling method	Air cooled
Positioning mode	Red light focus, red light auxiliary preview
Marking line type	dot matrix, vector
Laser working life	10 0,000 hours
Protection degree	IP54
Environmental	-10°C-45°C(no freezing)/10%-85%(non-condensing)
Net weight	28 Kg(host) / 29.2Kg(stand)
Package Size	96cm46cm47cm(host) / 133cm35cm27cm(stand)
Print content	variable data(Serial number, date, counter, shift), graphic element(Point, Line, Arc Text, Rectangle, Circle)
System language	Chinese, English, Spanish, Russian, Arabic, Portuguese, French, Thai, Japanese, Korean, ec

Substrates named on the source pages

Bottles, cartons and glass
Metals and rigid plastics

How plants put it to work

Mount or hold the head at the published working distance, load the code on the controller, and trigger from the line sensor where listed.
