CO2 Flying Laser Printer

Name: CO2 Flying Laser Printer
Brand: Dotcoding

The 40W CO2 flying laser printer is used for high-speed online printing of mineral water bottles, food bags, cartons, and glass.Anti-counterfeiting, non-damaging material, environmentally friendly。

Request This Model Email the model name

Product gallery

Key benefits

Published laser source: CO2 laser source.
Published power: ≤40W.
Published speed: 0-280m/min.
Published weight: 28Kg(host) / 29.2Kg(stand).
Cooling: Air cooled.
Controller: USB/Serial & Ethernet communication.

Who it is for

Food, beverage and pharmaceutical packagers coding film, bottles and cartons on a moving line
Plants that want to drop ink or ribbon consumables on high-speed conveyors

Problems it takes off the line

Inkjet dates that smear or peel in cold, wet or high-speed plants
Ribbon and solvent cost on TTO and CIJ stations
Heat damage on thin film when the wrong laser wavelength is used

Published technical points

Body material: All aluminum structure
Laser source: CO2 laser source
Power supply: 100~240V / 50~60Hz AC
Laser Power: ≤40W
Total power: ≤700W Laser wavelength: 10.6um(standard)/10.2um/9.3um
File format: BMP/DXF/JPEG/PLT
Marking speed: ≤7000mm/s
Graphics file format: PLT format vector file input/output

Specifications from the original listing

Body material	All aluminum structure
Laser source	CO2 laser source
Power supply	100~240V / 50~60Hz AC
Laser Power	≤40W
Total power	≤700W Laser wavelength: 10.6um(standard)/10.2um/9.3um
File format	BMP/DXF/JPEG/PLT
Marking speed	≤7000mm/s
Graphics file format	PLT format vector file input/output
Marking line width	0.03-0.1mm
Peripheral interface	USB/Serial & Ethernet communication
Marking depth	0.01-0.03mm
Screen	10.2 inch HD screen Marking range: 110mm x 110 mm (Standard)
Product line speed	0-280m/min
Marking accuracy	≤0.01mm
Repeat accuracy	≤0.01mm
Font type	Single-line font/double-line font/bit matrix font
Marking lines	Edit freely within the marking range
Cooling method	Air cooled
Positioning mode	Red light focus, red light auxiliary preview
Marking line type	dot matrix, vector
Laser working life	30,000 hours
Protection degree	IP54
Environmental	-10°C-45°C(no freezing)/10%-85%(non-condensing)
Net weight	28Kg(host) / 29.2Kg(stand)
Package Size	96cm46cm47cm(host) / 133cm35cm27cm(stand)
Print content	variable data(Serial number, date, counter, shift), graphic element(Point, Line, Arc Text, Rectangle, Circle)
System language	Chinese, English, Spanish, Russian, Arabic, Portuguese, French, Thai, Japanese, Korean, ec

Substrates named on the source pages

Food film and pouches
Bottles, cartons and glass
Wood and cartons

How plants put it to work

Mount or hold the head at the published working distance, load the code on the controller, and trigger from the line sensor where listed.

Related machines

Flying Laser Printer

MINI UV TTO Laser Marking System

355nm cold UV laser coding technology, designed specifically for the food and beverage industry, suitable for use in a wide range of confine

Flying Laser Printer

Fiber Flying Laser Printer

This 30W Fiber Flying Laser Printer is specifically designed for high-speed, on-line printing on beer bottle caps, PVC pipes, and rigid plas

Flying Laser Printer

UV Flying Laser Printer

This 5W UV laser printer is suitable for printing various items such as food bags, pharmaceutical packaging, stretch films, and 3C electroni

Questions Buyers Ask

What laser source does the CO2 Flying Laser Printer use?

The published listing gives CO2 laser source and ≤40W.

How fast can the CO2 Flying Laser Printer mark?

Published speed is ≤7000mm/s.

What does the CO2 Flying Laser Printer weigh?

Published machine weight is 28Kg(host) / 29.2Kg(stand).

Talk to Hangzhou about CO2 Flying Laser Printer

Include pack material, code content and target speed. Unpublished numbers will not be guessed on this page.
